- Page 1 CYCLONE PRO SENSOR Wind Speed Rain Readings Solar Panel Now with dual tipper for Assisted Power improved accuracy Wind Direction Easy-to-Install LTV-WSDR1 Mounting Bracket...
-
Page 2: Initial Setup
Installing the Wind Cups (if needed) 2. Align the flat edges and place the Wind 1. Remove the Cyclone Pro Sensor, Wind Cups on top of the Cyclone Pro Sensor. Cups, and Mini Screwdriver from the package. Take note of the flat edges located on the head of the Sensor and underside of the Wind Cups. - Page 3 Powerup Install 3-AA Batteries Insert 3-AA batteries into the bottom of the Cyclone Pro Sensor according to polarity. Adding Your Sensor to the La Crosse View App 1. Open your La Crosse View app. On the Main Menu, Bottom of Cyclone Sensor ⊲ scroll to ADD/EDIT and select DEVICES.
-
Page 4: Sensor Placement & Mounting
• Ideally, the Cyclone Pro Sensor should be mounted on the tallest object in your area. Avoid positioning the sensor parallel or below eaves, roof lines, trees, or other objects that may obstruct wind and rain readings. - Page 5 Sensor Placement & Mounting Check the integrated Bubble Level or use your own Secure the Cyclone Sensor to the Mast by tightening across the Rain Funnel to ensure the sensor is level. the screws on the side. After screws are tightened, double check the sensor has remained level through the installation process.
-
Page 6: Cleaning The Rain Sensor
Cyclone Pro Sensor Mounting Advanced Installation Some advanced installation options include tripods, wall mounts, chimney mounts, and many others. Any of these can be combined with U-bolts for attachment onto a tall cylindrical conduit using our Adjustable Base. These options will require additional equipment and possibly professional help for best results. -
Page 7: Specifications
Lock/Unlock Line. clockwise until secure. Tip: Remove the Cyclone Pro Sensor’s batteries before cleaning to avoid accidental rain readings. 5.18” Specifications 13.15cm 9.12”... -
Page 8: Warranty
Phone: 1.844.200.8752 Warranty California Residents CA WARNING: This product can expose La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product, relating to you to chemicals including acrylonitrile, manufacturing defects in materials and workmanship. -
Page 9: Battery Replacement
Battery Replacement Battery Replacement Instructions When batteries of different brand or type are used together, or new and old batteries are used together, some batteries may be over-discharged due to a difference of voltage or capacity. This can result in venting, leakage, and rupture and may cause personal injury.
