- Page 1 Thuraya Telecommunications Company Installation Manual SpaceCom IP321 Maritime Antenna for Thuraya IP terminal L10-10059-3...
-
Page 2: Table Of Contents
5.3.1 Pole Mount Kit Contents .................. 8 5.3.2 Pole Mount Component Description ..............8 Connecting to the Thuraya IP Terminal ..............10 Bending Radius of the Coax Cables ..............12 Operating the Antenna ....................13 Satellite Acquisition ....................13 6.1.1 Blocking of the Satellite .................. -
Page 3: Introduction
Introduction The stabilized SpaceCom IP321 Maritime Antenna is designed for use with the Thuraya IP terminal. The SpaceCom IP321 Maritime Antenna is a 3-axis constant gain antenna designed for maritime use. It is an autonomous satellite tracking antenna using a patented beam squint technology and built-in control software to acquire the satellite and stabilize the antenna using a tracking beacon from the Thuraya satellites. -
Page 4: Specifications
3. Specifications Physical Characteristics Dimensions Size of radome: 265x270mm (hxd) 3 kg (excluding cable and Power Supply, Weight AS03951) RF Connector N type Cable 15m RG223 or 25m LMR240 Electrical Antenna Gain 10dBi approx LNA Gain 32dB ±3 (excluding cable loss) TX Gain 35.5dBi ±1 (excluding cable loss) Polarisation... -
Page 5: Limits Of Normal Operation
Limits of Normal Operation The antenna is designed to perform optimally within these operational limits: Random vibration 1.05 g rms with the following spectral density 5-20 Hz………….0.02G2/Hz 20-150 Hz……….-3dB/octave Single frequency vibration 5-10 Hz with amplitude 2.54 mm 10-15 Hz with amplitude 0.76mm 15-25 Hz with amplitude 0.40mm 25-33 Hz with amplitude 0.23mm Absolute Maximum Limits... -
Page 6: Package Contents
2. 1 meter coax interface cable with SMA and SMC connectors 3. 1 red/black DC cable for the Power Supply, AS03951 5. External GPS antenna 6. One Installation Manual (this document) Figure 2. SpaceCom IP321 Maritime Antenna package contents. Numbers refer to the contents list. -
Page 7: Installation
• The external GPS antenna required for the Thuraya IP terminal should be placed at least 1 meter from the SpaceCom IP321 Maritime Antenna and other interfering signal sources or receivers (see the Thuraya IP manual for details on the external GPS antenna). -
Page 8: Pole Mount Kit Contents
Installation of the SpaceCom IP321 Maritime Antenna on a post is done according to Figure 3. The diameter of the post should preferably be between 35 and 50mm using the standard U-bolt supplied in the kit. Notice the TORQUES for bolts and nuts. - Page 9 8. Nuts, Part No. SPAC-M90-10008, are M5 nut used for the u-bolts, SPAC-M01616, refer to Figure 3. Nuts are to be tightened to 5Nm. Remember to use the washers M90-10128 as shown in Figure 3. 9. Screw, M4*22, Part No. SPAC-M90-10068, is used to secure the plug. 10.
-
Page 10: Connecting To The Thuraya Ip Terminal
N male connector at each end. The cable carries receive and transmit L-band signals as well as DC power to the antenna. A separate coax cable is connected between the Thuraya IP terminal and the Power Supply, AS03951. Figure 4 shows the connections. - Page 11 To terminal active external antenna connector Figure 4. Connecting the SpaceCom IP321 Maritime Antenna to the Thuraya IP terminal via the Power Supply, AS03951. Connect the 1 meter coax cable from the Power Supply, AS03951 to the terminal active external antenna connector (see Figure 5). Remember to tighten the connecter in both...
-
Page 12: Bending Radius Of The Coax Cables
Figure 5. Connecting to the Thuraya IP terminal via the active external antenna connector. The DC cable of the Power Supply, AS03951 is connected to the vessels power supply with specifications defined in Section 3. Ensure that the polarity is correct. The DC step-up converter in the Power Supply, AS03951 is isolated from the vessel’s 0V. -
Page 13: Operating The Antenna
In certain areas both satellites are visible and therefore the antenna can track either of them, but only one of them will allow the Thuraya IP to connect to the network. The area with both satellites visible is from longitude 60° East to 110° East. - Page 14 AS03951. This will redirect the antenna to track the beacon of the other satellite visible. It is not necessary to power off the Thuraya IP terminal.
-
Page 15: Appendices
7.2 System fault finding If for some reason the system can not connect to the Thuraya network the following things must be checked with respect to the antenna installation. For fault finding on the Thuraya IP terminal, refer to its manual. - Page 16 Figure 6. Thuraya IP terminal web interface. Check for antenna type.
-
Page 17: Warranty
Warranty 8.1 SpaceCom limited warranty statement. SpaceCom warrants that SpaceCom stabilized maritime antenna for ThurayaIP, accessories and software will be free from defects in materials and workmanship after the date of production for a period of 18 months. If SpaceCom receives notice of such defects during the warranty period, SpaceCom will, at its option, either repair or replace products which prove to be defective.
