Summary of Contents for Thuraya SpaceCom IP221
- Page 1 Thuraya Telecommunications Company Installation Manual SpaceCom IP221 Vehicle Antenna for Thuraya IP terminal L10-10058-3...
-
Page 2: Table Of Contents
Package Contents ....................... 6 Installation ......................... 7 Correct Placement of the Antenna..................7 Placement of Power Supply, AS03951 ................. 7 Connecting to the Thuraya IP terminal ................. 8 Operating the Antenna ..................... 10 Satellite Acquisition ......................10 6.1.1 Blocking of the Satellite ....................10 Satellite choice ........................ -
Page 3: Introduction
The stabilized SpaceCom IP221 Vehicle Antenna is designed for use with ThurayaIP terminals. The SpaceCom IP221 Vehicle Antenna is a 2-axis antenna designed for vehicular use. It is an autonomous satellite tracking antenna using a patented beam squint technology and built-in control software to acquire the satellite and stabilize the antenna using a tracking beacon from the Thuraya satellites. -
Page 4: Specifications
3. Specifications Physical Characteristics Size of radome: 115x275mm (hxd) (excluding Dimensions mag. mount) 2.1 kg (excluding cable, mag. mount and Power Weight Supply, AS03951) RF Connector TNC on radome Cable 4mts Electrical Antenna Gain 10dBi approx LNA Gain 12dB ±1 (excluding cable loss) TX Gain 10dBi ±1 (including cable loss) Polarisation... -
Page 5: Limits Of Normal Operation
Limits of Normal Operation The antenna is designed to perform optimally within these operational limits: Random vibration 1.05 g rms with the following spectral density 5-20 Hz………….0.02G2/Hz 20-150 Hz……….-3dB/octave Single frequency vibration 5-10 Hz with amplitude 2.54 mm 10-15 Hz with amplitude 0.76mm 15-25 Hz with amplitude 0.40mm 25-33 Hz with amplitude 0.23mm Absolute Maximum Limits... -
Page 6: Package Contents
3. 1 red/black DC cable for the Power Supply, AS03951 5. External GPS antenna for use with the ThurayaIP terminal. 6. One Installation Manual (this document) Figure 2. SpaceCom IP221 Vehicle Antenna package contents. Numbers refer to the contents list. -
Page 7: Installation
• The external GPS antenna required for the Thuraya IP terminal should be placed at least 1 meter from the SpaceCom IP221 Vehicle Antenna and other interfering signal sources or receivers. -
Page 8: Connecting To The Thuraya Ip Terminal
The cable carries “receive and transmit” L-band signals as well as DC power to the antenna. A separate coax cable is connected between the Thuraya IP terminal and the Power Supply, AS03951. See picture showing the SpaceCom IP221 Vehicle Antenna... - Page 9 • Connect the 1m coax cable from the Power Supply, AS03951 to Thuraya IP terminal “active external antenna” connector (see Figure 4). The Thuraya IP terminal will automatically detect and use the SpaceCom IP221 Vehicle Antenna. Figure 4. Connecting the SpaceCom IP221 Vehicle Antenna to the “active external antenna”...
-
Page 10: Operating The Antenna
In certain areas both satellites are visible and therefore the antenna can track either of them, but only one of them will allow the Thuraya IP to connect to the network. The area with both satellites visible is from longitude 60° East to 110° East. -
Page 11: Appendices
7.2 System fault finding If for some reason the system can not connect to the Thuraya network the following things must be checked with respect to the antenna installation. For fault finding on the Thuraya IP terminal, refer to its manual. - Page 12 Figure 5. Thuraya IP terminal web interface. Check for antenna type.
-
Page 13: Warranty
8. Warranty SpaceCom Limited Warranty Statement SpaceCom warrants that SpaceCom stabilized vehicular antenna for the Thuraya IP terminals, accessories and software will be free from defects in materials and workmanship after the date of production for a period of 18 months.
