Mindman MPG-60 Series Quick Start Manual

For your safety, please read the following before using.
Do not use corrosive or flammable gas or liquid with this product.
1
Please use within the rated pressure range. Do not apply pressure
2
beyond recommended maximum withstand pressure, permanent
damage to the pressure gage may occur.
Do not drop, hit or allow excessive shock. Even if pressure gage
3
body appears undamaged, internal components may be broken and
can cause malfunction.
Do not use in environment containing steam or oil vapor.
4
This product is not explosion-proof rated. Do not use in atmosphere
5
containing flammable or explosive gases.
Using filter can extend pressure gage's service life.
6
A.
SPECIFICATIONS
TYPE
MPG-60V-
Rated pressure range
Display pressure range
Withstand pressure
Applicable fluid
kPa
MPa
k
gf/cm
Pressure 2
resolution
bar
psi
mmHg
Battery
Back light
Battery life
(5 times/day)
Low-power indicator
Battery replaceable
Turn-on interval
Sampling rate
Pressure unit
Repeatability
Display
Indicator accuracy
Enclosure
Ambient temp. range
Environment
Ambient humidity range
Vibration
Shock
Temperature characteristic
Port size
Weight
*1. When the pressure is -0.1MPa, LCD displays
*2. Air tube must be installed to maintain IP65. (See section K)
B.
ORDERING INFORMATION
M P G - 6 0 P L - F 1
Pressure Range
V : Vacuum (10 ~ -101kPa)
P : Positive (-0.100 ~ 1.000MPa)
Back Light
Blank : Back light unavailable
L : Back light available
Optional Parts
MP-A5 : Mounting bracket (BT-5)
MP-A6 : Mounting bracket (BT-6)
MP-B2 : Panel adapter (PA-C)
MP-C2 : Panel adapter + Front protective lid (PA-D)
PR-0246D 2021/11 Printing We reserve the right to change the specification without prior notice.
MPG-60 Series
(Vacuum)
MPG-60VL- MPG-60P-
0 ~ -101kPa 0.000 ~ 1.000MPa
-0.100 ~ 1.000MPa *1
10 ~ -101kPa
300kPa
Filtered air, incombustible and non-corrosive gases
1
-
-
0.01
0.1
1
CR 2032 lithium
No Yes No
3 years 1 year 3 years
(5 times/day) (5 times/day)
Yes
Yes
Display turn off after 60 sec.
2 Hz (2 times/sec.)
psi, bar, mmHg and kPa psi, bar, kgf/cm
user selectable user selectable
± 1 % F.S. ±1digit ±0.2% F.S. ±1digit
3 ½ digital, 7 segment LCD display ( Black )
±2% F.S. ±1 digit (ambient temperature: 25 ±3 °C)
IP 65 *2
Operation: 0 ~ 50 ºC, storage: -10 ~ 60 ºC
( No condensation or freezing)
Operation/Storage: 35 ~ 85% RH ( No condensation)
Total amplitude 1.5mm or 10G, 10Hz-55Hz-10Hz scan
for 1 minute, two hours each direction of X, Y and Z
100m/s (10G), 3 times each in direction of X, Y and Z
2
±2% F.S. of detected pressure (25°C) at temp.
range of 0~50°C
F1:R1/8", M5; F2:NPT1/8", #10-32 UNF; F3:G1/8"(BSPP), M5
F4:R1/4", M5; F5:NPT1/4", #10-32 UNF; F6:G1/4"(BSPP), M5
Approx. 40g
MPa.
Pressure Port
F1 : R1/8", M5
F2 : NPT1/8", #10-32 UNF
F3 : G1/8"(BSPP), M5
F4 : R1/4", M5
F5 : NPT1/4", #10-32 UNF
F6 : G1/4"(BSPP), M5
C.
PANEL DESCRIPTION
Pressure Unit
Display Section
Battery Meter
Pressure Display
Setting Button
D.
DIMENSIONS
(Positive)
MPG-60PL-
1.5MPa
-
0.001
0.01
0.01
15.5
0.1 22.5
-
Yes
1 year
(5 times/day)
and MPa
2
E.
BATTERY STATUS / INSTALLATION
FOLLOW THE STEPS BELOW
● Using a flat screwdriver size 1.4 ~ 3.0 mm insert into the back of the
pressure gage as pictured. (See figure
● Turn the screwdriver horizontally 90° t o separate the case and the base.
Repeat this process again for the other side. (See figure
● Carefully remove the outer cover (See figure
below to replace battery and reassembly. Polarity must be observed,
incorrect battery installation will cause malfunction.
1
4
7
(Vacuum)
psi bar mmHg kPa
20
9
6
37
30
21.8
30
2
2
5
Ø 2mm MAX
8
(Positive)
psi bar kgf MPa
20
F1 : R1/8", M5
F2 : NPT1/8", #10-32 UNF
F3 : G1/8"(BSPP), M5
F4 : R1/4", M5
F5 : NPT1/4", #10-32 UNF
F6 : G1/4"(BSPP), M5
F1~F3:Hex flat:12
F4~F6:Hex flat:14
Unit:mm
)
)
3
), and follow the diagrams
4
3
"+"
6
"-"
