SB-10044446-7231
Value n mot on
SERVICE BULLETIN
TS35-U06

Advertisement

loading
Need help?

Need help?

Do you have a question about the TS35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Temsa TS35

Summary of Contents for Temsa TS35

  • Page 1 SB-10044446-7231 Value n mot on SERVICE BULLETIN TS35-U06...
  • Page 2 Contents Foreword ........................................ 2 Bulletin Information ..................................4 Tools ......................................... 5 Parts List ......................................... 6 Technical Instructions ..................................7 How to Claim over CATS ................................18 TS35-U06 / Rev. 00 / 22.06.12 TS35 | 1...
  • Page 3 00 Foreword General Precautions ..................................3 Symbol List ......................................3 Before Start of Work ..................................3 Mechanical Requested Dress Code 3.1..............................3 Protect Seats when Mechanics Start Working 3.2..........................3 2|TS35 TS35-U06 / Rev. 00 / 22.06.12...

  • Page 4: Visual Inspection

    Dress correctly to avoid injury and damage to the vehicle. 3.2. Protect Seats When Mechanics Start Working 1. Seats, trimming, upholstery stuff and car- peting should be protected with appropri- ate coverings. TS35 |3 TS35-U06 / Rev. 00 / 22.06.12...
  • Page 5 2-Flasher buzzer sound is changed by installing a new relay under dashboard....Prepared by Metin Şengüneş ....Approved by Osman Dündar ....Published by Beytullah Onat Distribution to: Dealer/Retailer TEMSA After Sales Team Authorised Service Centre TS35-U06 / Rev. 00 / 22.06.12 4 | TS35...
  • Page 6 In case of long hair use hairnet. • Tool list below is a recommended list. It is not a must to use the exact same tools. 2. Tools (Recommended) PLASTIC HAMMER HAMMER PHILIPS SCREW DRIVER Screw Driver TS35-U06 / Rev. 00 / 22.06.12 TS35 | 5...

  • Page 7: Parts List

    03 Parts List Installed Part List Part No Part Name Qty. RP254305Y FRONT BODY MODIFICATION HARNESS (DOOR SW) TS35-U06 / Rev. 00 / 22.06.12 6 | TS35...

  • Page 8: Technical Instructions

    04 Technical Instructions 1. Turn off battery main switch and ignition key switch. 2. Remove hazard switch. Photo 1 Photo 2 Photo 3 TS35-U06 / Rev. 00 / 22.06.12 TS35 | 7...
  • Page 9 Photo 4 Photo 5 3. Dismantle and cut terminal of red 13-01 cable which is available in 3 and pin of hazard switch. Photo 6 Photo 7 TS35-U06 / Rev. 00 / 22.06.12 8 | TS35...
  • Page 10 4.Put together two red 13-001 cables in a terminal (from hazard connector and modification harness) and connect these cables to 3nd pin of hazard switch. Photo 8 Photo 9 Photo 10 TS35-U06 / Rev. 00 / 22.06.12 TS35 | 9...
  • Page 11 33-04 and other 33-04 together in a terminal (other 33-04 which is available in modification harness) and then connect this terminal into 17th pin of hazard switch. Photo 12 Photo 13 TS35-U06 / Rev. 00 / 22.06.12 10 | TS35...
  • Page 12 10th pin of hazard switch and blue cable with resistor available in hazard switch and then connect this terminal to 10th pin of hazard switch. cut here Photo 15 Photo 16 TS35-U06 / Rev. 00 / 22.06.12 TS35 | 11...
  • Page 13 Photo 17 Resistor Stays Here Photo 18 Photo 19 TS35-U06 / Rev. 00 / 22.06.12 12 | TS35...
  • Page 14 7.Modification harness cables and relay should be laid over vehicle harness with cable bands. Photo 20 Photo 21 8.Remove door control switch from its place. Photo 22 Photo 23 TS35-U06 / Rev. 00 / 22.06.12 TS35 | 13...
  • Page 15 Photo 25 10.Dismantle and isolate white cable which is available in 2nd pin of hazard switch connect 13-01 (instep-7) to this pin (2nd pin of hazard switch) Photo 26 Photo 27 TS35-U06 / Rev. 00 / 22.06.12 14 | TS35...
  • Page 16 11.Dismantle MOKI D connector from rear side of MOKI to reach and dismantle moki connector first dismantle cover just above throttle pedal as shown pictures. Photo 29 Photo 30 Photo 31 TS35-U06 / Rev. 00 / 22.06.12 TS35 | 15...
  • Page 17 Photo 32 Photo 33 12.Dismantle the 33-05 cable in MOKI pin D5. Photo 34 Photo 35 TS35-U06 / Rev. 00 / 22.06.12 16 | TS35...
  • Page 18 14.Connect MOKI D connector to MOKI. Photo 37 15.Load BS_02_18 program to vehicle. 16.Check if door control button is working ignition on positon and ignition off position. 17.Then mount switches and covers to their places. TS35-U06 / Rev. 00 / 22.06.12 TS35 | 17...
  • Page 19 Automatic Hazard Emergency Stop Switch Hazard Warning Signal Switch Front Door Control Switch Warning Signals Relay 11S002 Instrument Cluster 02S009 02S001 Emergency Stop Kl15 Cut-Off Relay 07A001/ MOKI SOCKET D-2 02K003 01S004 01S004 01S001 06A002 01S001 01S002 (E-17) KL 31 KL 31 KL 58 KL 58...
  • Page 20 1. Under CATS tab click on “Work Order” to create the work order. 2. Enter the related chassis number, work order type, failure, repair dates and vehicle milage in order to create work order. TS35-U06 / Rev. 00 / 22.06.12 18 | TS35...
  • Page 21 3. Select the applied bulletin. 4. Please add your additional comments if necessary and click on “Send to Temsa” to complete your work order. TS35-U06 / Rev. 00 / 22.06.12 TS35|19...
