G1002-C Status LEDs
2 x Gigabit Ethernet (RJ-45)
12Vdc Jack
G.hn Port (F-type)
G1002-C Port and LED Definition
Troubleshooting
The G1002-C has three (3) Status LEDs:
•
PWR: it will be ON when connected to
a local power source. If it is OFF, please
verify you have connected the 12V wall
adapter to a working power jack.
•
STA: it will be yellow while the G1002-C
is booting and then will be OFF.
•
G.hn: it will be ON (green) to indicate
that the link to the Internet is UP. It will
be OFF in the link is DOWN. It will blink
ON and OFF to indicate a bad link. You
can restart the G1002-C if you see a
blinking G.hn LED. If this does not solve
the problem, please reach out to your
Operator for assistance.
WWW.POSITRONACCESS.COM
© Positron Access Solutions
5101 Buchan Street, Suite 220,
Montreal, QC H4P 2R9 Canada
info@positronaccess.com
G1002-C
Self-installation Guide
Document 180-0221-001-R01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Positron G1002-C
Summary of Contents for Positron G1002-C
- Page 1 12V wall WWW.POSITRONACCESS.COM adapter to a working power jack. • STA: it will be yellow while the G1002-C is booting and then will be OFF. © Positron Access Solutions • G.hn: it will be ON (green) to indicate that the link to the Internet is UP.
- Page 2 Step 2 12V wall adapter Step 4. Connect the port labeled as GE1 (on the opposite end of the G1002-C) to your Residential Gateway using a standard Ethernet cable (usually provided with your Residential Gateway). Port GE1 is capable of being configured in VLAN Trunk Mode (over 4000 VLANs).
