G.hn to Gigabit Ethernet Bridge
Quick Installation Guide
G1002-C / G1002-C+

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G1002-C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Positron G1002-C

  • Page 1 G.hn to Gigabit Ethernet Bridge Quick Installation Guide G1002-C / G1002-C+...
  • Page 2 Product names, other than Positron's, mentioned herein may be trademarks and/or registered trademarks their respective companies. Disclaimer Notice Although Positron Access Solutions has made every effort to ensure the accuracy of the information contained herein, this document is subject to change. Positron Access Solutions...
  • Page 3: Table Of Contents

    G1002-C LED Definition ....................6 G1002-C+ (Coax) Endpoint....................7 G1002-C+ LED Definition .................... 8 G1002-C / G1002-C+ Gigabit Ethernet Ports ..............8 Physical Mounting of the G1002-C / G1002-C+ ............... 8 ............................10 Technical and Regulatory Specifications .................. 10 G1002-C Technical Specifications .................. 10 G1002-C+ Technical Specifications ................
  • Page 4: About The G1002-C / G1002-C

    While each of these devices perform a similar function, here is a summary of the unique features of each model: • G1002-C: this coaxial G.hn Endpoint is locally powered and offers two (2) Gigabit Ethernet ports (RJ-45). The 1 Ethernet Port can be configured as a VLAN Trunk port when there is a need to support a large number of VLANs.
  • Page 5 G1002-C Quick Installation Guide an Ethernet-like technology that is highly scalable without some of the inherent complexity of DSL-related technologies. With G.hn, Operators deliver advanced services such as Gigabit High Speed Residential Internet and 4K IPTV without the high capital and operational expenses associated with a fiber retrofit. Each G.hn subscriber port supports up to 1.7 Gbps of dynamically allocated bandwidth for...
  • Page 6: G1002-C (Coax) Endpoint

    G1002-C Quick Installation Guide G1002-C (COAX) Endpoint The G1002-C (coax) G.hn Bridge to Gigabit Ethernet comes with two (2) Gigabit Ethernet port to connect the Residential Gateway (RG). 2 x Gigabit Ethernet (RJ-45) G1002-C Status LEDs/ Figure 1: G1002-C Gigabit Ethernet Port and Status LEDs...
  • Page 7: G1002-C+ (Coax) Endpoint

    Figure 3: G1002-C LED definition G1002-C+ (Coax) Endpoint The G1002-C+ (coax) G.hn Bridge to Gigabit Ethernet comes with two (2) Gigabit Ethernet port to connect the Residential Gateway (RG). The Gigabit Ethernet Port labelled as GE1 supports POE / POE+ to power an external device.
  • Page 8: G1002-C+ Led Definition

    Please note that port GE1 can be configured in VLAN Trunk mode (via the GAM) if required for your application. The GE1 port of the G1002-C+ supports Power Over Ethernet to power an external device. When locally powered, the G1002-C+ can provide up to 30W of power as per the IEEE 802.3at standard.
  • Page 9 G1002-C Quick Installation Guide 2. Use the G1002-C enclosure as a guide to determine where you need to install the two (2) mounting screws. 3. Install the lower screw into the wall but do no tighten completely. Use a wall plug if inserting the screws into a dry wall.
  • Page 10: Technical And Regulatory Specifications

    16 G1002-C per G.hn port Ease of Operation Automatic firmware and configuration management via the Positron GAM AES-128 encryption with individual keys for each end-node under the control of Encryption the Positron GAM acting as the Master Node...
  • Page 11: G1002-C+ Technical Specifications

    16 G1002-C per G.hn port Ease of Operation Automatic firmware and configuration management via the Positron GAM AES-128 encryption with individual keys for each end-node under the control of Encryption the Positron GAM acting as the Master Node...
  • Page 12: Regulatory Compliance

    • Consult the dealer or an experienced radio/TV technician for help. Safety Information The G1002-C is a highly sophisticated electronic device. To get the most out of it, be sure to read the following text about product care, safety and efficient use.
  • Page 13 Approved for use in an indoor location only Power Supply • Ensure that a suitable AC power outlet is located near the G1002-C or G1002-C+ and easily accessible. • Connect the power supply cord only to the AC power outlet that meets the specifications marked on the AC power adapter and connect the DC...
  • Page 14 G1002-C Quick Installation Guide The manufacturer declares that this product (G1002-C, G1002-C+) is in conformity with the requirements and other relevant provisions of the following Canadian standards: • CAN ICES-3 (B)/NMB-3(B) Environmental Conditions Maximum environmental values during use: • Temperature: 0°C to +40°C (32° to 104° F) •...
  • Page 15: Warranty And Customer Service

    ______________________________________ Warranty and Customer Service Positron Access Solutions will replace or repair this product within the warranty period if it does not meet its published specifications or fails while in service. Warranty information can be found in your Positron Access customer web portal: http://www.positronaccess.com/Portal.php...
