Assembling The Stand; Mounting The Saw To The Stand - Bosch GTA570 Operating/Safety Instructions Manual

(Fig. 2)
1. Each of the Legs is marked ("A," "B,"
"C," and "D"), and there are matching
markings on the corners of the Stand
Subassembly 1. Slide each Leg into the
matching locations on the Stand Subas-
sembly 1.
Note: The stand's legs are not interchange-
able.
Fig. 2
(Fig. 3, Fig. 4, Fig. 5)
1. Unfold the stand to the open position
2. Slide the table saw onto the stand so that
the Rear of the Base 2 slides under the
stand's Retainer Tabs 3
saw is centered on and located inside the
L-Shaped Brackets 4 on the front of the
stand.

Assembling the Stand

Mounting the Saw to the Stand

. Make sure the
2. Align the Holes in Each Leg with the Holes
in the Stand Subassembly.
3. Insert the Phillips head screws through
each of the legs, and tighten securely
with the hex lock nuts. Make sure that the
heads of the Phillips head screws are on
the outside of the stand assembly.
D
A
3. Once the rear of the Table Saw Base 2 is
fully aligned under the stand's Retainer
Tabs 3, latch the Wire Hook 5 of the
.
Clamp 6 on the front of the stand onto the
tube of the Saw Base 2
Clamp 6 into place
Note: To remove the saw from the stand, re-
verse the procedure above.
-4-
1
C
B
, and lock the
.
