Download
Share
Print this page
  1. Manuals
  2. Brands
  3. Sensor Electronics Manuals
  4. Measuring Instruments
  5. AirDistSys 5000
  6. Operator's manual

Sensor Electronics AirDistSys 5000 Operator's Manual

Air distribution measuring system
Hide thumbs Also See for AirDistSys 5000:

Advertisement

Quick Links

Download this manual
A
i
A
i
MAILING ADDRESS
Ul. Odlewników 18
PL-44-100 Gliwice
Poland
r
D
i
s
t
r
i
b
u
t
i
r
D
i
s
t
r
i
b
u
t
i
A
i
r
D
A
i
r
D
O
p
e
r
a
O
p
e
r
a
WEB SITE
www.sensor-electronic.pl
o
n
M
e
a
s
u
r
i
o
n
M
e
a
s
u
r
i
i
s
t
S
y
s
5
0
0
0
i
s
t
S
y
s
5
0
0
0
'
'
t
o
r
s
M
a
n
t
o
r
s
M
a
n
n
g
S
y
s
t
e
m
n
g
S
y
s
t
e
m
u
a
l
u
a
l
E-MAIL
office@sensor-electronic.pl
Edition 19.4

Advertisement

loading
Need help?

Need help?

Do you have a question about the AirDistSys 5000 and is the answer not in the manual?

Questions and answers

Related Manuals for Sensor Electronics AirDistSys 5000

Summary of Contents for Sensor Electronics AirDistSys 5000

  • Page 1 Edition 19.4 ’ ’ MAILING ADDRESS WEB SITE E-MAIL Ul. Odlewników 18 www.sensor-electronic.pl office@sensor-electronic.pl PL-44-100 Gliwice Poland...
  • Page 2 2 – Operator’s Manual AirDistSys 5000 The AirDistSys5000 enables air temperature and low air speed measurements at several points in spaces, as well as for measurement of flow characteristics in jets from air thermal devices. The AirDistSys5000 is wire-less system which makes it convenient for field and laboratory measurements. Many years experience with manufacturing of low velocity thermal anemometers and the latest development in the field of electronic equipment were used in designing of the system.
  • Page 3 3 – Operator’s Manual AirDistSys 5000 > > max. 8 SensoCable 56__ max. 500m SensoConnect USB interface e l e c t r on i c e l e c t r on i c e l e c t r on i c...

  • Page 4: E L E M E N T S O F T H E S Y S T Em

    4 – Operator’s Manual AirDistSys 5000 max. 8 max. 8 SensoBee USB receiver e l e c t r on i c e l e c t r on i c e l e c t r on i c...
  • Page 5 5 – Operator’s Manual AirDistSys 5000 Directional sensitivity vs yaw angle Directional sensitivity vs roll angle (reference mean velocity of 0.2m/s) (reference mean velocity of 0.2 m/s) f=90 w=90 f=120 f=60 w=120 w=60 f=150 f=30 w=150 w=30 f=180 f=0 w=180...
  • Page 6 6 – Operator’s Manual AirDistSys 5000 Preparation for measurement: 1. First install the measurement transducer or probe on a tripod. 2. Check if the openwork basket (4) is on the shielding tube (3). If not put openwork basket (4) on the shielding tube (3). Be particularly careful not to damage the speed sensor (1).
  • Page 7 7 – Operator’s Manual AirDistSys 5000  max analog output resistance: 100 Ohm  power supply: 3.3…9 VDC  power consumption: typ.60mA, peak. 110mA, economy mode 6mA The error of directional sensitivity occurs when the direction of air flow is other than during the calibration of the probe.
  • Page 8 8 – Operator’s Manual AirDistSys 5000 Example of conection to the anemo transducer: analog output (temp, vel - linear) SensoAnemo SensoDACon 5400 5100LSF converter SensoCable 57xx (max 2m for voltage output) SensoCable 56xx (max length 50m) Power Supply adapter Optionally the system may be equipped with...
  • Page 9 9 – Operator’s Manual AirDistSys 5000 The SensoConnect USB interface enables data transmission to a computer through the USB port. It is being powered from the USB port of computer, therefore doesn't require external power supply adapter. The power socket located on the side of the casing allows the user to connect an external power supply adapter used to power the transducer.
  • Page 10 10 – Operator’s Manual AirDistSys 5000 Technical Data:  indoor (urban) range: up to 60m  outdoor line-of-sight range: up to 100m  transmit power output: 100mW (20dB) EIRP  operating frequency: 2.4GHz  RF data rate: 250 kbps  power supply: 5…9 VDC/1A...
  • Page 11 11 – Operator’s Manual AirDistSys 5000 PowerBank is a high performance external battery pack with latch for DIN rail. The latch allows for easy installation of the device on a tripod along with other parts of the measuring system. Includes a white charging cable (USB to micro USB) and spiral power cable (USB-plug DC) with a length of 30-100 cm.
  • Page 12 12 – Operator’s Manual AirDistSys 5000 Measurement system can be equipped with a fold-out tripod adapted to mount several measuring transducers with accessories. The tripod consists of a fold-out base and 3 re-screwable vertical pipe D1-D3 60cm long, its max height is 180cm.
  • Page 13 13 – Operator’s Manual AirDistSys 5000 The rail-mounted grip enables to mount the devices equipped with latch for DIN rail, so as: SensoBar transducer, SensoBee wire-less receiver, SensoBox adapter or PowerBank. You can mount it on a tripod in two...

  • Page 14: D E S C R I P T I O N O F T H E P R O G R Am

     try to reassign COM port to a unused port number  click OK when finished.  The AirDistSys 5000 program makes possible for: automatic scanning of the configuration of the measuring system calculating average temperature, average and standard deviation of air speed, turbulence intensity,...
  • Page 15 15 – Operator’s Manual AirDistSys 5000  The program contains the Context Help window which displays a description when the user moves the cursor over the property. Updating the program and newest version of the instruction are available from the menu bar.
  • Page 16 16 – Operator’s Manual AirDistSys 5000  The data logging and statistical analyzing procedure used is made clear in the following figure. An example of settings with Interval Time of 1 min, Averaging Time of 3 min and Logging Time of 6 min.
  • Page 17 17 – Operator’s Manual AirDistSys 5000 select ‘  The default TCP port number is 5000. In order to change the TCP port number ’ from the menu item ‘Data Communication…’ on the menu bar on front panel. connection  The frequency of data transfer for TCP connection is specified by the Interval Time.
  • Page 18 18 – Operator’s Manual AirDistSys 5000 Results calculated Results calculated Sent to a computer in a transducers in a computer every 2s          – instantaneous temperature – average temperature in any averaging time –...
  • Page 19 19 – Operator’s Manual AirDistSys 5000  The built-in TCP/IP connection enables to communicate between different computers by the networks. TCP/IP routes data from server (AirDistSys 5000 program) to client. ‘ ’  The default TCP port number is 5000. In order to change the TCP port number select TCP connection from the menu item ‘Data Communication…’...
