- Page 1 Subsystems for the UAS intergration into the airspace Omni-directional Ground Station with BLE/Wi-Fi Technology Data sheet & User manual...
- Page 2 Technology Introduction OGS station is an ADS-B and BLE/Wi-Fi RemoteID Omni-directional receiver station with multi-constellation GNSS sensor to provide best accuracy. LTE connectivity which simple setup of the MQTT broker allows usage in all LTE/4G rich environments without the need for any additional cabling to send data. It has been designed to allow quick and easy assemble enclosed in IP67 case for high weather condition resistance.
-
Page 3: Table Of Contents
......... . . 11 Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact: support@aerobits.pl... -
Page 4: Technical Parameters
Sensitivity (Wi-Fi ) Integrated GNSS Multi-GNSS for precise time stamp LTE Cat. 1 Data transport layer (global bands) Table 1: General technical parameters. Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact: support@aerobits.pl... -
Page 5: Electrical Specification
Standard USB connector (programming and power supply) Power consumption 1.5 W Power supply 100 - 240 VAC Table 2: Power supply of OGS-BLE Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact: support@aerobits.pl... -
Page 6: Mechanical Specification
170 x 170 x 100 mm 0.5 kg (Module without cables and antennas) Weight 2.5 kg (With cables, arm and antennas) Table 3: Mechanical parameters of OGS-BLE Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact:... -
Page 7: Quick Start
Figure 1: OGS-BLE equipment kit Installation process 4.2.1 Mounting 1. Take the OGS out of the box and place facing down - as shown on the picture. Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact:... - Page 8 Omni-directional Ground Station with BLE/Wi-Fi Technology Datasheet 2. Place the arm on the OGS case (without installed antennas). NOTE: Please observe correct direction. Front of the arm and front of the case have to face the same direction. Rotate OGS as shown on the picture below.
- Page 9 4. After installing the arm, attach the antennas. Loosen the screws on both sides of the arm and tighten them after inserting antennas. It is recommended to install antennas one by one to avoid damaging them. Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact: support@aerobits.pl...
- Page 10 5. After the mechanical part of installation, connect the antennas to the device and the device to the power supply as shown below. Do not use both power sources at the same time. 6. Correct mounting shown below. Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact: support@aerobits.pl...
-
Page 11: Power Supply Connection
Datasheet 4.2.2 Power supply connection NOTE: Do not use both power sources at the same time. Please disconnect power supply cable (100-240 VAC) before programming OGS via USB cable. Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact:... -
Page 12: Inserting A Sim/Chip Card
Insert SIM card into slot visible on the picture above. A simple way to do it is to grab SIM with tweezers and push it carefully directly into slot. Then attach the device back (if unmounted) and mount the cover. Date: 2022-12-20 Document ref: 23ob-v1.0.15 This document is subject to change without notice. For technical questions, contact: support@aerobits.pl... - Page 13 If any part of this document refers to any third party products or services, it shall not be deemed a license granted by Aerobits for use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering use, in any manner whatsoever, of such third party products or services or any intellectual property contained therein.
