  • Page 1 STEAM BOX PRO USER INSTRUCTION...
  • Page 2 STEAM BOX PROFESSIONAL Pag. 2 TECNOVAP 06/15...
  • Page 3 STEAM…. BURNING DANGER ATTENTION!! READ THE OPERATING MANUAL OPERATING MANUAL; OPERATING INSTRUCTIONS BURNING DANGER!! IT IS COMPULSORY TO USE PROTECTIVE GLOVES. EQUIPMENT WITH SOUND PRESSURE LEVEL > 85db IT IS COMPULSORY TO USE EARS PROTECTIVE SHROUDS. Pag. 3 TECNOVAP 06/15...
  • Page 4 MUST NOT BE LEFT IN THE ENVIRONMENT AND MUST BE RECYCLED IN THE PROPER RECYCLING CENTERS ACCORDING TO THE ENVIRONMENTAL REGULATIONS. The user might return the unit for disposal also to the retailer when purchasing a new equivalent device on a one to one ratio. Pag. 4 TECNOVAP 06/15...

  • Page 5: Table Of Contents

    ▪ MUD DRAIN FROM THE BOILER The unit automatically indicates the necessity to proceed with the mud drain; the notice C A L C will be displayed alternatively to the current visualization on the panel. Pag. 5 TECNOVAP 06/15...
  • Page 6 ▪ When using detergent (make sure it’s non-foaming) please follow the specific instructions: 1 liter of detergent for every 10 liters of water (detergent percentage about 10%), making sure to fill in first the detergent to obtain a better mixing. Pag. 6 TECNOVAP 06/15...

  • Page 7: Connection To The Water Net

    (fittings, tubes, gaskets, reductions etc.) for a new connection. Being a movable device, the connection hose to the water net is not supplied due to the unknown distance from the water connection point. Pag. 7 TECNOVAP 06/15...

  • Page 8: Preface

    This product is equipped with a dependable stainless steel boiler with automatic refilling system which allows it to produce a powerful and continuous supply of steam (24/24 hours). STEAM BOX PROFESSIONAL offers the overheated water function and is also equipped with a separate detergent tank which allows the injection of detergent up to 90-160°C.

  • Page 9: Technical Characteristics

    FACTORY: TECNOVAP SRL VIA DEI SASSI 1A 37026 PESCANTINA VERONA ITALY Model Steam Box Professional 4W07010 - 4W06010 - 4W05010 - 4W04010 - 4W0401M Code 4W07A10 - 4W06A10 - 4W05A10 - 4W04A10 - 4W04A1M 4W07T10 - 4W06T10 - 4W05T10 - 4W04T10 - 4W04T1M...
  • Page 10 STEAM BOX PROFESSIONAL Model Steam Box Professional Bacchus 4007060 – 4006060 – 4005060 – 4004060 – 400406M Code Rated Voltage 230/400 Current type 50/60 3~ 10,8 – 14,4 – 21,6 – 28,8 – 36,0 Rated Power Boiler 11,0 – 14,8 – 22,0 – 29,2 – 36,4...

  • Page 11: Nomenclature

    STEAM BOX PROFESSIONAL NOMENCLATURE Steam Box Professional 01) Power cord 35B) Hot water switch 02) Water inlet for direct water feed 36) 37) Steam regulation switches 03) Water inlet valve filter 38) Vacuum switch 04) General power switch 40) Locking latches for accessories...

  • Page 12: Technical Drawings

    STEAM BOX PROFESSIONAL TECHNICAL DRAWINGS STEAM BOX PROFESSIONAL SINGLE POWER Steam Box Professional AD40010 MULTI POWER Steam Box Professional AD4401M Pag. 12 TECNOVAP 06/15...
  • Page 13 STEAM BOX PROFESSIONAL STEAM BOX PROFESSIONAL WITH VACUUM CLEANER SINGLE POWER Steam Box Industrial AD50010 MULTI POWER Steam Box Industrial AD5301M kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga kvglircis mlòerga Pag.
  • Page 14 STEAM BOX PROFESSIONAL STEAM BOX PROFESSIONAL WITH STEAM BOX PROFESSIONAL INTERGRATED VACUUM CLEANER CON ASPIRATORE INTEGRATO SINGLE POWER Steam Box Professional AD40010 MULTI POWER Steam Box Professional AD4401M Pag. 14 TECNOVAP 06/15...
  • Page 15 STEAM BOX PROFESSIONAL STEAM BOX PROFESSIONAL BACCHUS SINGLE POWER Steam Box Bacchus AD40060 MULTI POWER Steam Box Bacchus AD4406M Pag. 15 TECNOVAP 06/15...
  • Page 16 STEAM BOX PROFESSIONAL Pag. 16 TECNOVAP 06/15...
  • Page 17 STEAM BOX PROFESSIONAL JULY 10bar ACCESSORIES ONLY FOR MODELS 10.8 kW e 14.4 kW KIT GEYSER 10 bar Pag. 17 TECNOVAP 06/15...
  • Page 18 Detergent discharging switch and temperature / pressure display. Total working hours (C1) (hour counter / totalizer). Partial working hours; this hour counter is resettable by the user. Clock set-up switch (the current time is displayed only when the machine is in stand-by mode). Pag. 18 TECNOVAP 06/15...
  • Page 19 Temperature / pressure display. Total working hours (C1) (hour counter / totalizer). Partial working hours; this hour counter is resettable by the user. Clock set-up switch (the current time is displayed only when the machine is in stand-by mode). Pag. 19 TECNOVAP 06/15...

  • Page 20: Operating Instructions

    This situation is recognizable thanks to the blinking LED light on the “boiler switch” . The system can intervene also after the boiler refilling once performed the mud drain during the maintenance process. Pag. 20 TECNOVAP 06/15...
  • Page 21 In case of complete obstruction of the vacuum inlet, a safety system will automatically block the appliance after one minute. To reactivate the integrated vacuum cleaner switch the appliance off by turning the general power switch (4), wait 10 seconds before switching it on again. Pag. 21 TECNOVAP 06/15...
  • Page 22 STEAM BOX PROFESSIONAL 8.1. OPERATING OF STEAM BOX PROFESSIONAL WITH KIT RADAMES Attention!! It is recommended to switch the steam generator off before connecting the steam hose to the steam outlet (9). Insert the vacuum male hose (30) into the vacuum hose female outlet (21) located on the vacuum cleaner and the steam plug (32) into the steam outlet (9) on the machine and activate the locking lever.
  • Page 23 STEAM BOX PROFESSIONAL 8.2. OPERATING OF STEAM BOX PROFESSIONAL WITH KIT JULY (only for models 10,8 kW and 14,4 kW) Attention!! It is recommended to switch the steam generator off before connecting the steam hose to the steam outlet (9).
  • Page 24 STEAM BOX PROFESSIONAL 8.3. OPERATING OF STEAM BOX PROFESSIONAL WITH KIT GEYSER Attention!! It is recommended to switch the steam generator off before connecting the steam hose to the steam outlet (9). Insert the steam plug (81) into the steam outlet (9) on the machine and activate the locking lever.
  • Page 25 The system will activate the appliance at the previously set time for 2 hours, afterwards it will be switched off. Just press any button within the above indicated period of time in order to deactivate the system of automatic switch off. Pag. 25 TECNOVAP 06/15...

  • Page 26: Maintenance

    Radames or 83 on Geyser) to allow the outlet of the air remained in the empty boiler. Wait until the refilling system has finished (approx. 3 minutes). The maintenance of the boiler is completed; proceed with the using instructions as described in the paragraph (h) of the chapter 8. Pag. 26 TECNOVAP 06/15...
  • Page 27 3) Detergent has been trigged and the machine is now ready for use. 9.3. MAINTENANCE OF THE FILTERS Remove the filter inside the water connection valve (2) by grasping with a pliers the proper tang located in the center of the filter; clean it and reposition it. Pag. 27 TECNOVAP 06/15...
  • Page 28 STEAM BOX PROFESSIONAL 9.3. MAINTENANCE OF THE TOOLS Grease occasionally joints on the extension tubes and on the accessories. PG5123 OR 29.82x2.62 PG5106 OR 9.25x1.78 PG5116 OR 6.75x1.78 Pag. 28 TECNOVAP 06/15...

  • Page 29: Before Referring To The Technical Service

    Blinking light Protection water net control activated. Control the presence of pressure and water into the valve (2). Remove and clean the filter (3) of the water net valve. Pag. 29 TECNOVAP 06/15...
  • Page 30 Accessories do not fit perfectly. There is dirt build up in the joints and locking Clean and lubricate the joints. latches. Pag. 30 TECNOVAP 06/15...

  • Page 31: Declaration Of Conformity

    PROFESSIONAL 11. DECLARATION OF CONFORMITY DICHIARAZIONE DI CONFORMITA’ CE (EC DECLARATION OF CONFORMITY) TECNOVAP S.R.L. con la presente dichiara che: la macchina per pulizia a vapore modello: (Certifies that the steam cleaning machine model): Steam Box Professional Risulta conforme alle specifiche delle direttive...
  • Page 32 STEAM BOX PROFESSIONAL Ordinary maintenance procedures Generator working Frequency of Notes hours intervention Pag. 32 TECNOVAP 06/15...
  • Page 33 STEAM BOX PROFESSIONAL Extraordinary maintenance procedures Generator Date of working intervention Intervention description, replaced components etc. hours Pag. 33 TECNOVAP 06/15...
  • Page 34 STEAM BOX PROFESSIONAL NOTES Pag. 34 TECNOVAP 06/15...
  • Page 35 STEAM BOX PROFESSIONAL Pag. 35 TECNOVAP 06/15...
  • Page 36 STEAM BOX PROFESSIONAL THE MANUFACTURER RESERVES THE RIGHT TO BRING TECHNICAL AND STRUCTURAL IMPROVEMENTS WITHOUT PRIOR NOTICE. Pag. 36 TECNOVAP 06/15...
