目录 Minx X301 Subwoofer ..........................................Introduction ............................................... What's included with the Minx X301? ....................................... Front panel ..............................................Rear panel ..............................................Unboxing your Minx X301 ......................................... Installation instructions ..........................................Connecting a second subwoofer ......................................Technical specifications ........................................... Frequently asked questions ........................................
Last updated: 一月 19, 2023 05:58. Revision #8500 Thank you for purchasing this Cambridge Audio Minx X301 subwoofer. Installed and used properly the subwoofer will deliver astonishing sound quality, whether playing music or movies, whatever the listening environment. Please read this guide carefully, as it contains essential information in getting the very best from your subwoofer.
What's included with the Minx X301? Last updated: 一月 19, 2023 05:58. Revision #8501 1. Minx X301 Subwoofer. 2. Installation guide. 3. Safety guide. 4. UK mains lead (depending on where the X301 was purchased) EU mains lead (depending on where the X301 was purchased)
Rear panel Last updated: 一月 19, 2023 05:58. Revision #8503 1. AC power socket. 2. Mains power switch – Switch the subwoofer between on and off. 3. Standby switch - Switch between ‘Force On’ (no standby), and ‘Audio Detect’. In audio detect mode the X301 will switch on when it detects an incoming signal.
Unboxing your Minx X301 Last updated: 一月 19, 2023 05:58. Revision #8504 Follow the diagram and take care when unboxing your Minx X301 so not to damage the speaker cone.
1. If you are using a two-channel hi-fi system, then use the left and right line input connections to connect your Minx X301. 2. If you are using a receiver, or amplifier with a dedicated sub out then connect the Minx X301 using the left channel (LFE/Sub) input.
Page 10
4. Use the crossover frequency, phase, and volume controls to adjust the subwoofer output to fit with the rest of your system, and your requirements.
Last updated: 一月 19, 2023 05:59. Revision #8506 If you wish to connect a second subwoofer to your setup, this can be done using the line out connections on the rear of your Minx X301. Connect the line out of your X301 to the line in of a secondary subwoofer and adjust the controls accordingly to achieve your desired sound.
Technical specifications Last updated: 一月 19, 2023 05:59. Revision #8507 Power output 300W Drivers 1 x 8" subwoofer 1 x 8" passive radiator Speaker dimensions (H x W x D) 311 x 266 x 278mm (12.4 x 10.5 x 11”) Weight 7.5kg (16.5lbs)
Frequently asked questions Last updated: 一月 19, 2023 05:59. Revision #8508 What is meant by speaker sensitivity? Speaker sensitivity is the level produced by the speaker at one meter, when supplied with one watt of power from an amplifier. It’s a way of describing how well the speaker produces acoustic energy, based on a given input.
Troubleshooting Last updated: 一月 19, 2023 05:59. Revision #8509 No sound through subwoofer. • Check that the amplifier is turned on. • Ensure that the correct input source is selected on the amplifier. • Check that the subwoofer is turned on. •...
