- Page 1 User Manual PM 3200 User Manual: Handling mobile Alley PM 3200 P a g e...
-
Page 2: Table Of Contents
User Manual PM 3200 Content : Manufacturer Safety instructions Machine maintenance Technical features Pictograms Explanations of the controls Working position Road position Production part operation Maintenance P a g e... -
Page 3: Manufacturer
User Manual PM 3200 Manufacturer: Maréchalle Pesage 130 C Avenue Jean Jaurès 02300 CHAUNY France Tel: +33 (0)3 23 40 22 80 Email: contact@marechalle-pesage.fr Website: www.marechalle-pesage.fr P a g e... -
Page 4: Safety Instructions
User Manual PM 3200 Safety Instructions: For safe use of the machine, be sure to follow the instructions below: • The machine must be lifted from below. • It is not recommended to transport animals inside the product. • Pay attention to the height of the product when cleaning the interior. -
Page 5: Technical Features
User Manual PM 3200 Technical Features: PM 3200 Units Dimensions: Length 7.80 Meter Width 1.77 Meter Height over wheel 2.25 Meter Ground height 1.93 Meter Weight 1 600 Kilogram Hydraulic: Tank quantity Liter Oil type UNIVIS HV 32 Voir Annexe... -
Page 6: Pictograms
User Manual PM 3200 Pictograms: Pictogram Description Location ➢ Warning plate ➢ At barriers’ level ➢ Information plate ➢ Front frame P a g e... - Page 7 User Manual PM 3200 Explications des commandes : Handle Scroll wheel Hydraulic pump Hydraulic pump: Use the handle to operate the pump. It's up to you to go back and forth to activate it. Turn the scroll wheel to lower the axle.
-
Page 8: Working Position
User Manual PM 3200 Working position: 1- Lift the crutch, remove the hitch from its housing. 2- Lower the crutch. 3- Remove the hitch to work. If the hitch does not bother you, remove the crutch to avoid damage. 4- Remove the rear license plate holder. -
Page 9: Road Position
User Manual PM 3200 Road position: 1- Activate the axle control. Raise the axle until the axle enters the housing. Axle 2- Insert the axle on each side, do not forget the pin! 3- Position the plate support. Plate support 4- Rise the crutch. -
Page 10: Production Part Operation
User Manual PM 3200 Production part operation: Safery basket control Front door control Reducer control Panels support Rear door control Hitch Electrical connection plug Crutch Side access door Man access Sectional sliding door Hydraulic control Directional wall Ramp of traffic lights... -
Page 11: Maintenance
User Manual PM 3200 Maintenance: Oil level Periodic Cleaning the electrical plugs Periodic Wheel tightening Periodic Lubrication points Periodic 11 | P a g e...
