- Page 1 Replaces existing: AQUA/LAMP ® POOL LIGHTS...
-
Page 2: Table Of Contents
CONTENTS READ THIS FIRST / PRODUCT WARNINGS TOOLS REQUIRED / WINTERIZATION INCLUDED PARTS BEFORE YOU START EXISTING LIGHT REMOVAL / CABLE PREPERATION CABLE JOINER INSTALLATION LIGHT INSTALLATION LIGHT REMOVAL / WINTERIZATION ELECTRICAL GROUNDING / FCC COMPLIANCE PRODUCT SUPPORT & INFORMATION CANADA INTERNATIONAL Select Pool Products... - Page 3 Minimum power source wattage requirement - 15 Watts per light. WARNING The ATOM Retro Series EM Light must be water cooled at all times. DO NOT switch the light on until installation is complete and the light is fully submerged in water.
-
Page 4: Tools Required / Winterization
TOOLS REQUIRED Small flat-blade screwdriver (supplied) 24mm / 29mm wrench (supplied) Side cutters / Pliers IMPORTANT NOTES • The use of power tools during installation is not recommended as these devices can cause faults and damage to light components. • All installation steps should be carried out with manual tools only. •... -
Page 5: Included Parts
INCLUDED PARTS 1 X RETRO LIGHT ADAPTOR PLATE ® (To suit existing AQUA/LAMP 18” OF 18AWG CABLE PLUG CONNECTION TERMINAL UNDERWATER COVER FOR PREASSEMBLED CABLE JOINER WINTERIZATION SCREW DRIVER WRENCH... -
Page 6: Before You Start
BEFORE YOU START ISOLATE POOL LIGHTS ENSURE SYSTEM IS SAFELY ISOLATED DURING THE INSTALLATION PROCESS. IF IN DOUBT; CONTACT YOUR ELECTRICAL CONTRACTOR FOR ASSISTANCE. CHECK TRANSFORMER EXISTING TRANSFORMER MUST 12V AC POWER SUPPLY/POWER SOURCE INTENDED FOR SWIMMING POOL USE MIN. 15 WATT (PER LIGHT) IN GOOD WORKING ORDER EXISTING TRANSFORMER MUST NOT... - Page 7 REMOVAL OF EXISTING LIGHT REMOVE EXISTING LIGHT REMOVE EXISTING POOL LIGHT FROM POOL WALL BY ROTATING CENTRE LIGHT FITTING COUNTER-CLOCKWISE. PREPARING EXISTING CABLE DISCONNECT CABLE TO EXISTING POOL LIGHT, ENSURING ENOUGH CABLE LENGTH REMAINS IN THE NICHE ABOVE THE NOMINAL WATER LEVEL TO ENSURE SERVICE ACCESS.
- Page 8 LOOSEN OUTER CABLE GLAND NUTS. LOOSEN AND REMOVE BOTH THREADED HEX NUTS USING 29mm WRENCH. CONNECT RETRO LIGHT CABLE CONNECT WIRES TO PLACE CABLE GLAND NUT TERMINAL BLOCK USING AND THREADED HEX NUT FLAT BLADE SCREW OVER RETRO LIGHT CABLE.
- Page 9 INSTALLING CABLE JOINER SLIDE THREADED HEX NUT OVER TERMINAL BLOCK. ENSURING CABLE SHEATH EXTENDS INSIDE THE ASSEMBLY. TIGHTEN CABLE GLAND NUT USING 24mm WRENCH. ATTACH MAIN BODY AND TIGHTEN USING 29mm WRENCH.
- Page 10 INSTALLING CABLE JOINER CONNECTING TO EXISTING CABLE PLACE CABLE GLAND NUT AND THREADED HEX NUT OVER EXISTING LIGHT CABLE. CONNECT WIRES TO TERMINAL BLOCK USING FLAT BLADE SCREW DRIVER. SLIDE THREADED HEX NUT OVER TERMINAL BLOCK AND TIGHTEN ONTO MAIN BODY USING 29mm WRENCH. TIGHTEN CABLE GLAND NUT USING 29mm WRENCH.
-
Page 11: Light Installation
LIGHT INSTALLATION COIL CABLE INTO NICHE ATTACH LIGHT FITTING TO NICHE ALIGN ADAPTOR PLATE WITH EXISTING MOUNTING TABS. TWIST LIGHT ASSEMBLY (INCLUDING ADAPTER PLATE) CLOCKWISE TO ENGAGE MOUNTING TABS AND LOCK INTO POSITION. - Page 12 INSTALLATION COMPLETE TURN POWER INSTALLATION IS NOW COMPLETE. TURN POWER ON TO CONFIRM OPERATION. WINTERIZATION REMOVE LIGHT FROM NICHE TWIST LIGHT ASSEMBLY (INCLUDING ADAPTER PLATE) COUNTER-CLOCK- WISE TO RELEASE FROM NICHE.
- Page 13 REMOVE PLUG FROM LIGHT UNSCREW 3x FASTENERS USING NO.2 PHILLIPS HEAD SCREWDRIVER ASSEMBLE TERMINAL COVER TO PLUG & STORE IN NICHE ASSEMBLE RED TERMINAL COVER TO PLUG USING NO.2 PHILLIPS HEAD SCREWDRIVER [RECOMMENDED] STORE PLUG AND CABLE WITHIN NICHE DURING WINTER PERIOD STORE LIGHT HEAD WITH ATTACHED ADAPTER PLATE IN A DRY AND SAFE...
-
Page 14: Spa Electrics
Do not make any changes or modifications to the equipment unless otherwise specified in the manual. AQUA/LAMP® is registered trademark of Consolidated Pool & Spa Industries Inc Canada. Spa Electrics Export Pty Ltd Australia and it’s ATOM and RETRO brands are not affiliated or endorsed by these companies and/or their brands. -
Page 16: Www.spaelectrics.com
NOTE PLEASE STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE www.spaelectrics.com COPYRIGHT 2020 SPA ELECTRICS PTY. LTD. ALL RIGHTS RESERVED CA 20211103...
