- Page 2 A2O Pure, UTS-800 Use and installation manual...
-
Page 3: Table Of Contents
List of included components Installation scheme How to install Operating instructions Replacement of cartridges Maintenance For the most updated installation manuals in more languages, go to Aquaporin.com/installation or contact the store where you bought your machine. A2O Pure, UTS-800 Use and installation manual... -
Page 4: Control Via App
A2O purifier by allowing tracking of your water usage. Monitor filter lifetime, next maintenance, and the effectiveness of the purification of the purifier. Access information Access manuals, installation guides, and useful information about water. A2O Pure, UTS-800 Use and installation manual... -
Page 5: About A2O Pure
About A2O Pure The A2O Pure is a direct flow water filtration The Aquaporin Inside® Drinking Water system with Aquaporin Inside® technology. Membrane (DWRO®) uses unique “made by The system can be used wherever traditional nature” proprietary membrane technology to... - Page 6 The system is influenced by feedwater conditions such as pressure, temperature, TDS levels, and hardness. The better these incoming conditions, the better performance. Depending on local water quality and use environment, the lifetime of the filters, flow rate, recovery rate and salt retention rate will vary. A2O Pure, UTS-800 Use and installation manual...
- Page 7 General Information Warranty and disclaimer The manual contains important instructions Observe: The information and for safe and efficient use of the A2O Pure, instructions contained in the UTS-800. This manual is part of the device manual were compiled based on...
- Page 8 Rinse the water pipe sufficiently before reconnecting the Danger: Always disconnect the device. power supply of the unit by removing the plug or fuse if hard wired during any maintenance and electrical work. A2O Pure, UTS-800 Use and installation manual...
-
Page 9: Dimensions And Weight
Dimensions and weight 315 mm 315 mm 203 mm Net weight: 8.57 kg A2O Pure, UTS-800 Use and installation manual... -
Page 10: List Of Included Components
Plastic nut 1× 1× gasket gasket 1× 1× 1× Tools required for installation 11 mm key Flat and Pincer Electrical drilling or flexible Phillips machine (6 mm spanner screwdriver and 12 mm drill) A2O Pure, UTS-800 Use and installation manual... -
Page 11: Installation Scheme
Installation scheme Faucet Pure Drain Wastewater water pipe Inlet water (tap water) Water Inlet water Pure water source The pressure reducer Wastewater including check valve for backflow prevention must be applied. A2O Pure, UTS-800 Use and installation manual... -
Page 12: How To Install
1. Use a flat device, e.g. a screwdriver to push connections. down the grey release collar. 2. You can now pull the plug upwards with your fingers. Note that there might be a release of air when removing the plugs. A2O Pure, UTS-800 Use and installation manual... - Page 13 Gasket Insert the 1/4″ PE pipe so that approximately Tighten the clamp with the 2 cm will be going into your drain pipe. Phillips screwdriver. ~ 2 cm A2O Pure, UTS-800 Use and installation manual...
- Page 14 Cut the 1/4″ PE pipe to fit the installation and insert it into the wastewater connection on the machine. Wastewater A2O Pure, UTS-800 Use and installation manual...
- Page 15 Insert the 3/8″ pipe onto the ball valve. Unscrew the nut from the ball valve. Tighten the nut with a Connect the T-piece flexible spanner. with ball valve on your cold water pipe. Cold water pipe A2O Pure, UTS-800 Use and installation manual...
- Page 16 A2O (away from the inlet water ball valve). Cut the length of the 3/8″ PE pipe to fit your installation. Insert the 3/8″ mm PE pipe to “inlet water” on A2O. Inlet water A2O Pure, UTS-800 Use and installation manual...
- Page 17 Faucet installation Drill ø 12 mm Drill a hole adjacent to your regular faucet. Assemble Remove the rubber cover from and tighten with the faucet. your hands (no use of tools). Rubber cover A2O Pure, UTS-800 Use and installation manual...
- Page 18 Insert a new piece of the 1/4″ PE pipe in the Cut the length of the 1/4″ PE pipe to fit your other end of the push-in fitting. installation and insert it into the pure water connection on the machine. Pure water A2O Pure, UTS-800 Use and installation manual...
- Page 19 Connect power Turn on the water. Connect A2O Pure to your power supply WARNING: Check for leakages before proceeding. TURN A2O Pure, UTS-800 Use and installation manual...
- Page 20 Once the lights on the top panel stop blinking, open your faucet and check for leakages. After installing your A2O Pure or replacing the cartridges, the system must be flushed before consuming the water – note that the first water coming out will be black.
-
Page 21: Operating Instructions
Operating instructions User interface overview Water-making WIFI Fault indicator light indicator indicator Rinse button Select/reset Pre-filter Post-filter DWRO® membrane life indicator life indicator life indicator A2O Pure, UTS-800 Use and installation manual... - Page 22 30 seconds. function of the clean button is invalid in the water-making mode. Manual flushing: in standby mode, press the “Clean” button, and the buzzer will beep once for 1 minute. A2O Pure, UTS-800 Use and installation manual...
- Page 23 WiFi icon is steady, the device has been configured successfully. If you cannot connect, please check your WiFi connection, or restart your A2O Pure. If still not working, please go to www.aquaporin.com or contact your local reseller.
-
Page 24: Replacement Of Cartridges
Filter cartridges Number Name Material Lifetime Pre-filter PP cotton + Activated carbon 12 months or 4,500 L Post-filter Activated carbon 12 months or 4,500 L DWRO® Aquaporin Inside® membrane 24 months or 7,000 L A2O Pure, UTS-800 Use and installation manual... - Page 25 Remove the cover and identify the cartridge Take out the cartridge that you are replacing. that needs to be replaced. Insert the new cartridge and tighten to the mark position. CLICK! Pre-filter Post-filter DWRO® membrane A2O Pure, UTS-800 Use and installation manual...
- Page 26 3 seconds. It will beep once, and the indicator flushing times at www.aquaporin.com or light corresponding to the selected filter contact your local dealer. element will blink 3 times and turn blue. Exit mode, press "Clean" or wait for 10 seconds. A2O Pure, UTS-800 Use and installation manual...
-
Page 27: Maintenance
- You can clean your system using a moist Observe the applicable national cloth and a mild cleaning agent. To protect regulations on disposal of electric the surfaces of the unit, do not use any devices. bleach, solvent, or alcohols. A2O Pure, UTS-800 Use and installation manual... - Page 28 Aquaporin A/S VAT No.: DK28315694 Nymøllevej 78 Tel: +45 82 30 30 82 2800 Kongens Lyngby sales@aquaporin.com Denmark aquaporin.com A2O Pure UTS-800-installation-manual-EN | Version 1.0 | Revised: 14 October 2022...
