Operation

a. Once all connections are made the following LED's should be lit:
1. Power LED will be constant lit green on bottom edge of face plate
2. Battery LED will be constant lit either red(low level charge), yellow(mid level charge) or
green (full charge on bottom edge of face plate)
b. Initiate a call to a Phone
1. Lift handset on the SmartRescue
2. Press the yellow "Talk" button corresponding to the Phone you wish to call into
3. Green LED will light next to that button
4. You should have 2 way communication to that Phone
5. You can place the Phone on hold by pressing the black "Hold" button. To resume
communication, press the Talk button again
Note: You can talk to all phone(s) connected to the SmartRescue at the same time or individually as
needed.
c. Activate a Phone
1. You will hear an alternating audible tone at the SmartRescue indicating a call has been initiated by
one of the phone(s)
2. Depending on the phone activated, the corresponding green LED will light on the
SmartRescue unit
3. The Rescue Service's LED, located on upper edge of face plate, will also be lit indicating that the
outside line is active
4. Lift the handset on the SmartRescue to join the conversation. If the phones(s) were programmed to
call the SmartRescue unit, after lifting the handset you must press the Rescue
Service's button to disconnect the outside line. If the phone(s) were programmed to dial standard
numbers follow the directions listed below
5. To talk to Rescue Service's only, place the phone(s) on hold by pressing the corresponding
Hold button. To bring them back into the conversation, press the Talk button
6. To disconnect Rescue Service's, press the red button at the top edge of the face plate. The Rescue
Service's LED will go off and leave you communicating only with the phone(s)
7. If you wish to leave Rescue Service's speaking with the phone(s) just return handset to the cradle
