- Page 1 SmartRescue Installation & Operations Manual RP8500001 N56 W24720 N. Corporate Circle Sussex, WI 53089 Ver. 3 Made in the USA 800-451-1460 262-246-4828 (fax) 3 Year Warranty 04/10...
-
Page 2: Table Of Contents
Welcome to Rath. We take great pride in not only our products, but also our service and support. Our #1 mission is customer satisfaction, and if at any time you feel we are not living up to your definition, do not hesitate to give us a call. -
Page 3: Pre-Installation Requirements
SmartRescue 5 & 10 Pre-Installation Requirements: ‡ )RU HDFK 3KRQH \RX PXVW UXQ D WZLVWHG VKLHOGHG WR JDXJH ZLUH VHW GRZQ WR WKH 6PDUW5HVFXH XQLW SUHIHUDEO\ &$7 RU EHWWHU 0DNH VXUH WR FRQQHFW WKH VDPH FRORU ZLUH DW SLQ RQ WKH 5- MDFN RU VSDGH FRQQHFWRU DW WKH 3KRQH DV SLQ RQ WKH 5- MDFN DW WKH 6PDUW5HVFXH DQG VR RQ IRU SLQ¶V ... -
Page 4: Wiring Diagram
SmartRescue System Wiring Diagram 120 vac 0 vac Transformer 2100-_____ Phone Ground Note: If the phone is powered from a 24 vac/vdc supply, a step down transformer is not included. Connect (2) black power leads from phone directly to the 24 vac/vdc supply Wiring requirements for each Phone 1) 22-24 awg, 2 pair, twisted, shielded wire with RJ11 or spade connector at the phone and RJ11 connector at the SmartRescue... -
Page 5: Programming Options
Programming Options for Phone(s): a. To program Phone(s) in “consolidator” mode 1. Programming steps a. Press Enter to get into program mode b. Press 7, Enter c. For Phone(s) 1-5; Press *, 1-5 d. For Phone(s) 6-10; Press #, 1-5 e. -
Page 6: Operation
Operation a. Once all connections are made the following LED’s should be lit: 1. Power LED will be constant lit green on bottom edge of face plate 2. Battery LED will be constant lit either red(low level charge), yellow(mid level charge) or green (full charge on bottom edge of face plate) b. -
Page 7: Standard Mounting Diagram
12.4 in SmartRescue Mounting Dimensions (Standard Surface Mount) 4.00 in 13.85 in Front 13.75 in in 12.27 in 9.27 in 2.9 in Ø0.87 0.69 in 0.69 in 1.95 13.75 in Side 6.67 in 0.3 in 5.87 in Back Ø0.8 pg. 6... -
Page 8: Cabinet Mounting Diagram
11.87 in SmartRescue Mounting Dimensions (Cabinent Mount) 6.125 in Front 12.00 in 10.382 in 7.002 in 1.622 in Back 1.002 in 0.220 in Side 6.00 in 6.00 in 0.220 in pg. 7... -
Page 9: Flush/Panel Mounting Diagram
11.87 in SmartRescue Mounting Dimensions (Flush/Panel Mount) 2.29 in 2.30 in 4.43 in Front 2.14 2.29 in 11.87 in 11.62 in 0.25 in 11.37 in Optional Back Box Cut Out Area Side Back pg. 8... -
Page 10: Troubleshooting
Troubleshooting Problem Possible Cause & Fixes Power LED is not ‡ &KHFN WR PDNH VXUH WKH WUDQVIRUPHU LV FRQQHFWHG WR D JRRG YDF SRZHU illuminated: VRXUFH ,I YDFYGF SRZHUHG FKHFN WKH SRZHU VRXUFH ‡ 0DNH VXUH SRZHU FRQQHFWLRQ RQ WKH FLUFXLW ERDUG LV VHFXUH Battery LED is not ‡...
