Model 933 UV Analyzer
Operator's Guide
With Essential Health and Safety Requirements
Canada
A DIVISION OF AMETEK PROCESS & ANALYTICAL INSTRUMENTS
Western Research
PN 903-8735, Rev. G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 933 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Metek 933

Summary of Contents for Metek 933

  • Page 1 Model 933 UV Analyzer Operator’s Guide With Essential Health and Safety Requirements Canada A DIVISION OF AMETEK PROCESS & ANALYTICAL INSTRUMENTS Western Research PN 903-8735, Rev. G...

  • Page 2: Offices

    Printed in Canada This manual is a guide for the use of the Model 933 UV Analyzer. Data herein has been verified and validated and is believed adequate for the intended use of this instrument. If the instrument or procedures are used for purposes over and above the capabilities specified herein, confirmation of their validity and suitability should be obtained;...

  • Page 3: Table Of Contents

    Contents Offices ..........................ii Safety Notes ........................viii Electrical Safety ........................viii Grounding ........................viii Personnel and Equipment Safety Information ............. ix Warnings ........................ix Cautions ........................x Warning Labels ........................xi Environmental Information .................... xi UV Source Lamps Disposal ..................... xi Electromagnetic Compatibility (EMC) ................xii Special Warnings and Information ................
  • Page 4 North American Installation ................3-20 System 200 Configurator Software Installation ............3-22 Minimum PC Requirements for Configurator Software ........3-22 Installing the Configurator Software ..............3-23 Removing the Configurator Software ..............3-24 Start-Up and Verification ..................... 3-25 iv | Model 933 UV Analyzer...
  • Page 5 Powering Up the Analyzer ..................3-25 Start-Up Diagnostic Checklist ................3-34 Sample System Leak Check ..................3-36 Sample Conditioning System Optimization ............. 3-39 Column Switch Time Optimization ..............3-39 Hold Time Optimization ..................3-44 CHAPTER 4 CONTROLLER / USER INTERFACE ............. 4-1 System 200 Configurator Software Overview –...
  • Page 6 AMETEK SERVICE and AFTERMARKET SALES SUPPORT ......7-3 Recommended Preventive Maintenance Spare Parts ..........7-4 Optical Bench/Sample System Spare Parts ............7-4 Spare Analyzer Fuses ....................7-6 Replacement Boards....................7-7 Ordering a Hard Copy of the Analyzer Operator’s Guide ....... 7-7 vi | Model 933 UV Analyzer...
  • Page 7 APPENDIX A – DRAWINGS ....................A-1 Block Diagram, North American Style (WX-933NA-1) ..........A-2 Block Diagram, European Style (WX-933ATEX-1) ............ A-3 Sample Flow Diagram (Plumbing Schematic), North American Style (WX-933NA-2) ......................... A-4 Backpan Dimensions, North American Style (WX-933NA-3) ......... A-5 Backpan Component Layout, North American Style (WX-933NA-3A) ....A-6 Conduit Entries, I/O and AC Power Connection Locations, North American Style (WX-933NA-3B) .....................

  • Page 8: Safety Notes

    Grounding Instrument grounding is mandatory. Performance specifications and safety protection are void if instrument is operated from an improperly grounded power source. Verify ground continuity of all equipment before applying power. CAUTION viii | Model 933 UV Analyzer...

  • Page 9: Personnel And Equipment Safety Information

    Personnel and Equipment Safety Information This section describes important safety information to avoid personal injury and damage to the equipment while installing, operating, maintaining, or servicing the equipment. All safety regu- lations, standards, and procedures at the analyzer location must be followed. All personnel involved with the installation, start-up, operation, maintenance, service, or trou- bleshooting of the analyzer must review and follow these Warnings and Cautions.

  • Page 10: Cautions

    • Systems without Filterblock Assembly: 20 700 KPAG (3000 PSIG). If the analyzer is equipped with the Environmental Purge option, clean air or nitrogen can be supplied to the inlet flame arrester at a pressure of 7–70 KPAG (1–10 PSIG). CAUTION x | Model 933 UV Analyzer...

  • Page 11: Warning Labels

    Warning Labels These symbols may appear on the instrument in order to alert you of existing conditions. Protective Conductor Terminal (BORNIER DE L’ECRAN DE PROTECTION) Schutzerde Caution – Risk of electric shock (ATTENTION – RISQUE DE DÉCHARGE ÉLECTRIQUE) Achtung – Hochspannung Lebensgefahr Caution –...

  • Page 12: Electromagnetic Compatibility (Emc)

    CAUTION The various configurations of the Model 933 Analyzer should not produce, or fall victim to, elec- tromagnetic disturbances as specified in the European Union’s EMC Directive. Strict compliance to the EMC Directive requires that certain installation techniques and wiring practices are used to prevent or minimize erratic behavior of the Analyzer or its electronic neighbors.

  • Page 13: Special Warnings And Information

    Special Warnings and Information Equipment Used in Class I, Division 2 Hazardous Locations Refer to Chapter 2 – Specifications for details about the suitability of this equipment in hazard- ous locations. EXPLOSION HAZARD – DO NOT DISCONNECT EQUIPMENT UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.

  • Page 14: Eu Declaration Of Conformity

    – Part 1: General requirements. Pressure Equipment Directive 2014/68/EU Article 4, Paragraph 3 Canada A DIVISION OF AMETEK PROCESS & ANALYTICAL INSTRUMENTS Western Research Page 1 of 2 PN 903-8595 Rev N xiv | Model 933 UV Analyzer...
  • Page 15 EU Declaration of Conformity The object of the declaration described [herein] is in conformity with the relevant Union harmonization legislation (Directive 2014/34/EU): EN 60079-0:2012 + A11:2013 General requirements EN 60079-1:2014 Flameproof Enclosures ‘d’ Certificate Number: KEMA 02ATEX2247 X Notified Body: DEKRA Certification B.V. 0344 Meander 1051, 6825 MJ Arnhem The Netherlands ____________________________ Randy Meads...

  • Page 16: Warranty And Claims

    SOLD SEPARATELY OR IN CONJUNCTION WITH EQUIPMENT OF OUR MANUFACTURE. WE DO NOT US ANY LIABILITY IN CON- AUTHORIZE ANY REPRESENTATIVE OR OTHER PERSON TO ASSUME FOR NECTION WITH EQUIPMENT, OR ANY PART THEREOF, COVERED BY THIS WARRANTY. xvi | Model 933 UV Analyzer...

  • Page 17: Chapter 1 Overview

    This system separates and eliminates interfer- ing species to ensure an accurate analysis of the gas. The microprocessor- based Model 933 Analyzer minimizes the complexity of these tasks and simplifies operation of the analyzer system. Overview | 1-1...

  • Page 18: About The Analyzer

    About the Analyzer The Model 933 Analyzer is comprised of (see Figure 1-1): • Two ultraviolet light sources (source lamps) • Chopper Wheel (Filter Wheel) containing up to six interference filters • Beam Splitter • Front-surfaced mirrors • Gas Measuring Cell •...
  • Page 19 Figure 1-2. Sample flow diagram REFERENCE: CERTIFICATE NO: KEMA 02ATEX2247 X CERTIFICATE NO: IECEx DEK12.0035X (Plumbing Schematic).  Figure 1-2 illustrates a Sample Flow Diagram (plumbing schematic) for a typical European style analyzer. See Appendix A for a North NOTE American style drawing (or Final “As-Built”...

  • Page 20: About The Analyzer Sample System

    About the Analyzer Sample System The sample system is mounted to the Model 933 Analyzer backpan. The purpose of the system is to maintain constant pressure and temperature, and to condition the sample to obtain correct analysis. The sample system consists of (see Figures 1-2 and 1-3):...
  • Page 21 RISK OF ELECTRIC SHOCK ATTENTION: CONSULT USER MANUAL 62.78 0344 II 2 G Western Research Model 933 Analyzer Certificate No: KEMA 02ATEX2247 X, Ex d IIB T3 Gb (T amb. 0°C...50°C) IECEx DEK12.0035X Year. _______ Serial No. __________________ Caution Do not open when an explosive gas atmosphere is present.

  • Page 22: Working In This Manual

    While working with the software, use these navigational aids to quickly access Example: software screens. See example at left, and see “Navigating in the Software” in Setup (tab)Gas Calibration Chapter 4 for more information. 1-6 | Model 933 UV Analyzer...

  • Page 23: Supplemental Information - Where Can I Find It

    Supplemental Information – Where Can I Find It? Some analyzers are configured with optional equipment that may require supplementary information. The analyzer Operator’s Guide and this ad- ditional information (not part of the main manual) – collectively known as the Documentation Package – is included on the Documentation Package CD shipped with the analyzer.
  • Page 24 This page intentionally left blank. 1-8 | Model 933 UV Analyzer...

  • Page 25: Chapter 2 Specifications

    SPECIFICATIONS Methodology Non-dispersive ultraviolet analysis for measurement of hydrogen sulfide S), carbonyl sulfide (COS), and methyl mercaptan (MeSH) in sales quality (pipeline quality) natural gas. Frontal elution chromatography is used to remove interfering species from the sample gas. Full-Scale Ranges The standard customer range is defined as full-scale ranges that fall with- in the minimum and maximum allowable for a given Measuring Cell.

  • Page 26: Response Time

    Calibration gases in nitrogen or methane. Linearity ± 2.0 % full-scale of standard ranges to a minimum of: ± 0.25 PPM COS: ± 1 PPM MeSH: ± 0.75 PPM Stability Noise: 1.0 % of standard ranges (excluding cross-talk effects). 2-2 | Model 933 UV Analyzer...

  • Page 27: Sensitivity

    Sensitivity 0.5 % of standard ranges Cross-Talk S concentration measurement: < 2 % of the sum of COS and MeSH concentrations.  Cross-talk adjustments should be made by factory-trained service personnel only. NOTE Temperature Drift 2 PPM / (Cell length) / °C COS: 12 PPM / (Cell length) / °C MeSH:...

  • Page 28: Customer Connections

    , 50/60 Hz, 1.5 A Maximum CSA: 104~132 V , 50/60 Hz, 3 A Maximum 208~264 V , 50/60 Hz, 2 A Maximum Sample Gas Flow Rate Maximum 20 NLM (42.4 SCFH) for the High Pressure/Low Range Kit. 2-4 | Model 933 UV Analyzer...

  • Page 29: Zero Gas

    Zero Gas Instrument zero purity Carbon Dioxide, UHP Nitrogen, or UHP Methane. Recommended Auto-Zero interval is once per 24 hours. More frequent Auto-Zeroing can be used to reduce temperature drift in installations with widely varying ambient temperatures. Ambient Limits Temperature From 0 °C to 50 °C (32 °F to 122 °F).

  • Page 30: Sample Stream Compatibility

    Approximately 100 kg (220.5 lb), entire system and backpan only (may vary, depending on system). Options • Other measuring ranges • Carbonyl sulfide (COS) and methyl mercaptan (MeSH) measurement • Pressure compensation • Up to 4 V/I outputs 2-6 | Model 933 UV Analyzer...

  • Page 31: Approvals And Certifications

    Approvals and Certifications The Model 933 Analyzer is certified for indoor use only, Installation Cat- egory II (local level transients, less than those found at power distribution level), and Pollution Degree 2 (normally nonconductive environmental pollution occurs with occasional condensation). Complies with all relevant European Directives.

  • Page 32: Atex And Iecex Certificates And Analyzer Markings

    ATEX and IECEx Certificates and Analyzer Markings For installation sites with potentially explosive atmospheres that require ATEX and IECEx certification, AMETEK’s ATEX and IECEx certificates for the Model 933 Analyzers are included in the following pages. 2-8 | Model 933 UV Analyzer...
  • Page 33 Specifications | 2-9...
  • Page 34 2-10 | Model 933 UV Analyzer...
  • Page 35 Specifications | 2-11...
  • Page 36 2-12 | Model 933 UV Analyzer...
  • Page 37 Specifications | 2-13...
  • Page 38 2-14 | Model 933 UV Analyzer...
  • Page 39 ATEX- and IECEx-certified Model 933 Analyzers are marked with this label: 0344 II 2 G Western Research Model 933 Analyzer Certificate Nos.: KEMA 02ATEX2247 X, IECEx DEK12.0035X Ex db IIB+H2 T3 Gb (T amb. 0°C...50°C) Year: _______ Serial No.: __________________ Caution Do not open when an explosive gas atmosphere is present.

  • Page 40: Csa Certificate And Analyzer Marking

    CSA Certificate and Analyzer Marking For installation sites that require CSA certification, AMETEK’s CSA certifi- cate for the Model 933 Analyzer is included in the following pages. Certificate of Compliance Certificate: 1031027 Master Contract: 164369 (048179_0_000) Project: 70097231097231 Date Issued:...
  • Page 41 Certificate: 1031027 Master Contract: 164369 Project: 70097231 Date Issued: 2017-02-24 Process Analyzer, Model 93X, rated at 104~132 VAC / 208~264 VAC, 3.0 / 2.0 A, <500 Watts, 50/60 Hz, ° ° Operating Temperature Ambient 0 C to 50 Note: 1. The Suffix “X” represents option which is application specific to different gases, concentrations and pressures.
  • Page 42 (16b) Caution Warnings “FOR GAS GROUPS B, C, & D and GROUP IIB+H2 A SEAL SHALL BE INSTALLED WITHIN 10 inches OF THE ENCLOSURE” And/or “UN SCELLEMENT DOIT ETRE INSTALLE A MOINS DE 254 MM DU BOITIER” DQD 507 Rev. 2016-02-18 Page 3 2-18 | Model 933 UV Analyzer...
  • Page 43 Supplement to Certificate of Compliance Certificate: Master Contract: 164369 (048179_0_000) 1031027 The products listed, including the latest revision described below, are eligible to be marked in accordance with the referenced Certificate. Product Certification History Project Date Description Updates to Report 1031027 for use with alternate potting material for Communications port based on Report and Test Data provided by 70097231 2017-02-24...
  • Page 44 CSA-certified Model 933 Analyzers are marked with this label:  PROCESS INSTRUMENTS Western Research Analyzer Model: ___104-132Vac, 3A ___208-264 Vac, 2A, 50/60 Hz, <500W CLASS I, DIVISION 1 GROUPS B, C & D CLASS I ZONE 1 Ex d IIB+H2 T3, AEx d IIB+H2 T3 Tamb.

  • Page 45: Chapter 3 Installation And Start-Up

    INSTALLATION and START-UP This chapter describes how to install and start up the Model 933 Analyzer, including: • Safety requirements to consider before working on the analyzer. • Uncrating, inspecting, and storing the analyzer prior to installation. • Installing the mechanical components and making the electrical con- nections.

  • Page 46: Safety Considerations

    Recommended storage conditions include: Temperature: 0 °C to 50 °C (32 °F to 122 °F) Relative Humidity: < 70 % Failure to comply with these storage conditions will void your warranty. 3-2 | Model 933 UV Analyzer...

  • Page 47: Uncrating And Inspecting The Analyzer

    Uncrating and Inspecting the Analyzer The analyzer and its associated sample system is shipped pre-mounted on a backpan, either alone in a crate or in a crated weatherproof shelter. Upon receiving the analyzer system, remove the shipping crates and check the exterior of the shelter and/or analyzer for damage. Open the shelter and verify its internal components are secure and there is no phys- ical damage.

  • Page 48: General Installation Information

    (breaker) must be connected to and mounted near the ana- lyzer, in an easily accessible area. The switch (breaker) must be clearly labeled (e.g., “AMETEK Model 933 Analyzer Main AC Power Discon- nect Switch”). For safety reasons during maintenance, this switch allows the main AC power to be disconnected from the analyzer prior to performing service on the analyzer.

  • Page 49: Installing The Mechanical Components

    Documentation Package. Location and Environment The Model 933 Analyzer is designed for indoor operation (Pollution Degree 2). In all cases, the analyzer system must be installed indoors to ensure it is shielded from harsh environmental elements. The entire ana- lyzer system (and its backpan) can be mounted directly on a wall inside a building, in a specially designed cabinet, or in a custom-built shelter.
  • Page 50 Figure 3-1. Analyzer backpan dimensions (European). 3-6 | Model 933 UV Analyzer...

  • Page 51: Installing The Optical Bench Assembly

    Installing the Optical Bench Assembly The Optical Bench Assembly – shipped in a separate box – must be in- stalled in the analyzer’s Upper Enclosure after the analyzer has been installed. All electrical connections to the Optical Bench are made via pre-wired connector plugs.
  • Page 52 • Optional: If your analyzer has a Cell Heater, connect the Heater Cartridge wire (marked ‘N’) to J200 (Terminal 2) and the Overtemp Switch wire (marked ‘L’) to J200 (Terminal 1). Figure 3-2. Upper Enclosure layout and Cam Pin locations. 3-8 | Model 933 UV Analyzer...

  • Page 53: Installing The Sample System

    5. Optional: If using the Optical Bench Purge, connect the purge line (black tube) to the Purge Fitting on the Optical Bench. After the Optical Bench has been installed, use a soft, nonabrasive cloth to gently clean the joining areas (flamepath) of the Upper Enclo- CAUTION sure and its door.
  • Page 54 Backpan component CERTIFICATE NO: KEMA 02ATEX2247 X layout (European). CERTIFICATE NO: IECEx DEK12.0035X  See Appendix A for a North American style drawing (or Final “As- Built” drawings in the analyzer Documentation Package). NOTE 3-10 | Model 933 UV Analyzer...

  • Page 55: Installing The Zero Gas Line

    Installing the Zero Gas Line The Zero gas line is supplied by the customer. The Zero gas connection (1/4" Swagelok fitting) is located on the Solenoid Block (Figure 3-3). The recommended Zero gas is UHP Nitrogen, UHP Methane, or zero purity Carbon Dioxide.

  • Page 56: Electrical Connections

    J108 of the Customer I/O board (Part No. 100-1758). • One isolated current output. • Minimum 250 Ohm impedance in series of the analog loop (up to a maximum 1000 Ohm load). 3-12 | Model 933 UV Analyzer...

  • Page 57: Digital Communication

    The analog input/output (and alarm relay) terminations are made on the Customer I/O board (Figure 3-4) in the Lower Enclosure. European Installations only: Signal wires, contained within cable that is approved locally for the haz- ardous area, enter the Ex d Lower Enclosure through one of the Signal Cable Entries on the bottom of the enclosure.
  • Page 58 REFERENCE: CERTIFICATE NO: REFERENCE: CERTIFICATE NO: KEMA 02ATEX2247 X IECEx DEK12.0035X (European).  See Appendix A for a North American style drawing (or Final “As- Built” drawings in the analyzer Documentation Package). NOTE 3-14 | Model 933 UV Analyzer...
  • Page 59 To configure either port, refer to “Remote Service Port/Local Service Port Configurations” (and “Remote Service Port RS-485, Full/Half Duplex,” if using the Remote Service Port) or “Customer Data Acquisition Port RS-485, Full/Half Duplex” below. The jumpers for these service ports are located on the Host Controller board (see Figures 3-4/3-5).
  • Page 60 Use a soft, nonabrasive cloth to gently clean the joining areas (flame- path) of the Upper and Lower Enclosures before closing them. CAUTION 3-16 | Model 933 UV Analyzer...

  • Page 61: Multiple-Analyzer (Multi-Drop) System Configuration

    2- or 4-wire line is used, and the transmission line conditions (length of cable, or termination and biasing on the other end of the cable).  Figures 3-5 and 3-6 apply only to Model 933 Analyzers with Host Controller board, Rev. B and newer. NOTE...
  • Page 62 Figure 3-6. Various RS-485 port terminations and bias options (Host Controller board, P/N 100-1757). 3-18 | Model 933 UV Analyzer...

  • Page 63: Ac Power Connection And Fusing

    AC Power Connection and Fusing Both the North American and European versions of the Model 933 Analyzer require a power-disconnect switch (breaker), rated for at CAUTION least 250 V , 3 A and certified for the hazardous location (to satisfy local electrical codes, the switch must be certified by the local author- ity for the appropriate hazardous location).

  • Page 64: European Installation

    The AC power connections are made at the terminals designated “H”, “N”, and “G” (at TB1) on the AC Terminal Strip (see North American Style drawing WX-933NA-3B in Appendix A, or Final “As-Built” drawings in the analyzer Documentation Package). 3-20 | Model 933 UV Analyzer...
  • Page 65 LOWER ENCLOSURE DETAIL A REFERENCE: CERTIFICATE NO: KEMA 02ATEX2247 X CERTIFICATE NO: IECEx DEK12.0035X Figure 3-7. Conduit entries and AC power connection locations, Lower Enclosure (European). Installation and Start-Up | 3-21...

  • Page 66: System 200 Configurator Software Installation

    • Windows 7 Professional Edition and later. The System 200 Configura- tor Software is not certified to operate with Windows Home Editions. • 800 x 600 resolution or higher recommended. • 256-color display, 32767 colors (HiColor, 16-bit) recommended. 3-22 | Model 933 UV Analyzer...

  • Page 67: Installing The Configurator Software

    Installing the Configurator Software To install the Configurator Software on your computer: 1. Insert the System 200 Configurator Software DVD in the DVD drive. The auto-setup program will run and begin the installation. The Wel- come to the InstallShield Wizard screen will appear. ...

  • Page 68: Removing The Configurator Software

    Software immediately, enable Launch the program and click Finish. You can also start the software by clicking M933 Configurator from the Start\Programs\AMETEK\933 Configurator menu or by clicking the M933 Configurator icon on the desktop (created during installa- tion). For details about using the Configurator Software to communicate with the analyzer, see “Starting the Configurator Software and Es-...

  • Page 69: Start-Up And Verification

    Start-Up and Verification This section describes equipment and controls on the analyzer system that require adjustments and settings before, during, and after power-up. See Figure 3-3 for the locations of analyzer equipment or controls that require adjustments. Powering Up the Analyzer When powering up the analyzer, certain checks should be performed to ensure the analyzer is operating properly.
  • Page 70 “Fault Column Temp Lo” and “Warning Bench Temp” alarm, respectively. Verify the alarms on the Status tab (Figure 3-14).  These green LEDs D404 (Fault Relay) and D405 (Warning Re- Status (tab) <<Error Condition>> lay) will be OFF in this case. 3-26 | Model 933 UV Analyzer...
  • Page 71 b. Upon power-up, all solenoids will remain de-energized for at least five minutes. Verify this by viewing the red LEDs D409 (Column A Solenoid), D410 (Column B Solenoid), and D411 (Zero Solenoid) on the Customer I/O board. These LEDs should be OFF. c.
  • Page 72 Microcontroller board (Figure 3-11). Both LEDs should be pulsing in unison once per second. e. Check the UV lamps to ensure they are firing (flashing). Figure 3-11. Microcontroller board (P/N 100-1781). LED D201 LED D200 3-28 | Model 933 UV Analyzer...
  • Page 73 The Optical Bench heater will turn on to heat up the Optical Bench. You can verify this by observing that the red LED201 on the Micro-Interface board is ON steady or pulsing. LED201 (Optical Bench Heater) Figure 3-12. Micro-Interface board (P/N 100-2231).
  • Page 74 From the Temperature Control dialog box, verify the Setpoint, Too  Hot, and Too Cold setpoint temperatures for each zone are correct. Setup (tab) Temp Control See also “Temperature Control” in Chapter 4. Figure 3-14. Temperature Control dialog box. 3-30 | Model 933 UV Analyzer...
  • Page 75 From the Status tab, check for alarms (under Error Condition). Tem- perature-related alarms should correct themselves after the analyzer has warmed up to normal operating temperature. After all alarms have cleared, recheck the temperature of each zone. Compare the current temperatures to their respective Set- point values and their start-up values.
  • Page 76 (see “Sample System Leak Check” in this chapter). Then, return to this section and complete the remaining steps. 3-32 | Model 933 UV Analyzer...
  • Page 77 5. After all of these checks have been made and verified, close the Up- per/Lower Enclosures and tighten all M10 screws (9 ±1 Nm (80 in-lb)). The sample gas should remain blocked in. Use a soft, nonabrasive cloth to gently clean the joining areas (flame- path) of the Upper and Lower Enclosures before closing them.

  • Page 78: Start-Up Diagnostic Checklist

    Check the Over-Temp Switch on the Optical Bench Assembly (see Fig- ure 3-2). If the plunger has popped out, press it to reset it. • Check for proper wiring terminations for the appropriate temperature zone. 3-34 | Model 933 UV Analyzer...
  • Page 79 Problem Encountered  A temperature zone value is equal to or greater than the maximum tempera- Setup (tab) ture range being used (view the Temperature Control dialog box to check the Temp Control range). A high temperature value may indicate a faulty RTD for the related temperature zone.

  • Page 80: Sample System Leak Check

    (outlet) side of CAUTION the Filterblock. Pressure differentials of more than 210 KPA (30 PSI) from the inlet side to the outlet side can tear the Filters and they will have to be replaced. 3-36 | Model 933 UV Analyzer...
  • Page 81 Close the valve on the Vent Line (or remove the Vent Line and cap the Vent Outlet). If the Sample Line is connected to the analyzer, disconnect it from the Sample Inlet fitting and connect Zero gas to the Sample Inlet fitting. 4.
  • Page 82 Software, power down the computer, and disconnect the serial cable from the analyzer’s Communications Port. Close the Communications Port cover and tighten the screw to secure it in place. The procedure is complete and the analyzer is ready to analyze sample gas. 3-38 | Model 933 UV Analyzer...

  • Page 83: Sample Conditioning System Optimization

    The first UV-absorbing gas species that elute through the chromato- graphic columns are hydrogen sulfide (H S), carbonyl sulfide (COS), and methyl mercaptan (MeSH). Because the Model 933 Analyzer can measure the concentrations of all three of these species, COS and MeSH do not interfere with the H S measurement.
  • Page 84  If the X-axis time interval on the ColumnSetup.dyc needs to be ad- justed, right-click your mouse button on the graph, click Display and NOTE change the time period in the Minutes text field. 3-40 | Model 933 UV Analyzer...
  • Page 85 Figure 3-20. Column Profile. Installation and Start-Up | 3-41...
  • Page 86 To change the Switch Interval, view the Column Timing dialog box and enter a new time. Click OK then Apply. Save the change to EEPROM.  Setup (tab) Column Timing Figure 3-21. Column Timing dialog box. 3-42 | Model 933 UV Analyzer...
  • Page 87 6. If the analyzer is configured with only the standard H S output, then it is likely that the factory default Switch Interval setting will be correct for the application. Check that the H S concentration has stabilized into a plateau before the columns switch. If the columns are switching before the H S concentration has stabilized, the Switch Interval is too short and should be increased.

  • Page 88: Hold Time Optimization

    Column Switch Interval has been adjusted, the MeSH Hold Time will also need to be adjusted. Take the new Switch Interval, subtract 2 seconds from it, and use that as the new MeSH Hold Time. 3-44 | Model 933 UV Analyzer...
  • Page 89 To change the Hold Time: 1. From the Output Setup dialog box (Figure 3-16), click Alarm Disable.  Click OK. Setup (tab)Output  2. View the Column Timing dialog box (Figure 3-21) and enter the new Setup (tab) Hold Time for the species of interest. Click OK then Apply. Save the Column Timing change to EEPROM.
  • Page 90 This page intentionally left blank. 3-46 | Model 933 UV Analyzer...

  • Page 91: Chapter 4 Controller / User Interface

    CONTROLLER / USER INTERFACE This chapter contains information about the following topics: • An overview of the Model 933 Analyzer System 200 Configurator Soft- ware. • How to work and navigate through the software. • How to view analyzer data, configure analyzer settings, and perform analyzer functions.

  • Page 92: System 200 Configurator Software Overview - Getting Started

    Press this butto n to navigate to the computer’s hard drive to locate files, such as the Configurator file (“LampSetup.dyc”). Press this button to print scanned data (such as Measure/Reference PMT signals) from the analyzer. 4-2 | Model 933 UV Analyzer...
  • Page 93   Reminder icon: Example: These reminders indicate related information about the topic, AMETEK recommends installing the software and certain actions that are necessary before continuing with the program icons in the default current procedure, or information that is recommended by directory.

  • Page 94: Starting The Configurator Software And Establishing Communication Between The Analyzer And Computer

    1. Connect a serial cable between the computer and the analyzer ’s Com- munications Port. Power up the analyzer and computer, and start the Configurator Software using one of two methods: • Click M933 Configurator from the Start\Programs\AMETEK\933 Configurator menu. • Click the M933 Configurator icon on the computer’s desktop.

  • Page 95: Closing The Configurator Software

    3. Confirm or configure communication settings by clicking Setup to view the Serial Port Configuration dialog box. Enter or select the ap- propriate communication parameters (see “PC Communication Setup” in this chapter). After configuring analyzer communication parameters, click OK to initiate communication with the analyzer.

  • Page 96: Configurator Software Troubleshooting

    “Wrong Device” is displayed on the Devices & Log window. Corrective Action Check the analyzer markings to ensure it is a Model 933 Analyzer (the Con- figurator Software cannot communicate with other analyzer models). The COM Port Parameter Settings may be incorrect. Review the settings in the Serial Port Configuration dialog box and verify or change them to the proper settings.
  • Page 97 Corrective Action Enable Device Enabled, if necessary, to establish communication. Check the analyzer markings to ensure it is a Model 933 Analyzer (the Con- figurator Software cannot communicate with other analyzer models). Problem Encountered The Device Properties command under the Edit menu is greyed out (access to the M933 Properties dialog box is not available).

  • Page 98: General Tab

    Number or location in the plant. This can be useful if using a Multi-Drop system, where multiple analyzers are wired together on the same line. In this case, you can assign different names and descriptions for each analyzer. 4-8 | Model 933 UV Analyzer...
  • Page 99 Save Configuration Saves the current analyzer configuration parameters to a file that can be used later to restore analyzer settings. See “Saving Analyzer Configuration Parameters” in this chapter. Restore Configuration Retrieves previously saved analyzer configuration parameters from a “.dev” file on the computer. See “Restoring Analyzer Con- figuration Parameters”...

  • Page 100: Pc Communication Setup

    1. Start the Configurator Software. The M933 Properties dialog box (General tab) will appear. 2. Click Setup to view the Serial Port Configuration dialog box. 4-10 | Model 933 UV Analyzer...
  • Page 101 3. Choose the communications information: Settings Port Select the computer COM port used to communicate with the analyzer. See also “Digital Communication” in Chapter 3.  To set up the analyzer to communicate via the Remote Service Port, configure the settings on the Device Communication tab first, then NOTE return to this dialog box and select RS-485 Port.

  • Page 102: Device Communication Tab

    2. From the Device Communication tab, enter the analyzer address (0–239) in the RS-485 Address text box. The baud rate is fixed at 9600. Click Apply. For the changes to take effect, save the settings to EEPROM. 4-12 | Model 933 UV Analyzer...
  • Page 103 3. From the Serial Port Configuration dialog box, verify the Address en-  tered in the Device Communication tab matches the Address in this General (tab)Setup dialog box. Click RS-485 Port to enable the Remote Service Port. Click OK to save this change.

  • Page 104: User Interface

    Contains icons used to save data files (not discussed in this manual). • Status Bar Displays system messages. • Devices & Log window This window is a system event log that lists all devices and their status (see “Viewing Device Activities”). 4-14 | Model 933 UV Analyzer...

  • Page 105: Viewing Device Activities

    Viewing Device Activities The Devices & Log window displays the status of all active devices (ana- lyzers), plus a system event log of all analyzer operations. This window, which is displayed within the M933 Configurator main window (Figures 4-4 and 4-5), can help you diagnose problems with the analyzer. Figure 4-5.

  • Page 106: Saving Analyzer Configuration Parameters

    EEPROM?”. During the parameters restoration, the analyzer will temporarily go “OFFLINE”. After the restoration is complete, the Name and Descrip- tion will change to reflect those of the saved parameters. 4-16 | Model 933 UV Analyzer...

  • Page 107: Modifying Analyzer Device Settings

    Modifying Analyzer Device Settings The M933 Properties dialog box – your primary interface with the ana- lyzer – contains several tabs that allow you to set up analyzer-computer communications and to modify analyzer configuration and calibration parameters. Working with the software is also necessary while performing maintenance and troubleshooting the analyzer.

  • Page 108: Saving Analyzer Configuration Parameters To An Ascii File

    Save. The file will be saved with a “.dmp” AMETEK recommends saving and storing these files extension and stored in C:\AMETEK\M933\data. in C:\AMETEK\M933\data. Figure 4-7. Save As dialog box (Print to File button). 4-18 | Model 933 UV Analyzer...

  • Page 109: Printing Analyzer Configuration Parameters

    Printing Analyzer Configuration Parameters To print the current analyzer configuration parameters, select Print (Setup  tab). From the Print dialog box, click OK. A printer must be connected directly to the PC or via a network. Figure 4-8. Print dialog box (Print button).

  • Page 110: Setting Gas Calibration Parameters

    The analyzer span factors are adjusted automatically based on the average reading during the Cal Int Time (seconds) period after click- ing each Span button. The span gas must be introduced manually (see Chapter 5). 4-20 | Model 933 UV Analyzer...
  • Page 111 Flow Control The analyzer gas flow control can operate in one of six “sample” modes. Normal analyzer operation is “Auto” mode. Auto The analyzer is under automatic control. Sample gas is continuously switched through Column A and Col- umn B, respectively, when the analyzer is operating normally.
  • Page 112 Cal Int Time period. The Zero gas must be introduced manually (see Chap- ter 5). Cancel Cal Cancels the calibration sequence (Manual Zero, Auto-Zero, Span). 4-22 | Model 933 UV Analyzer...

  • Page 113: Modbus Settings

    Modbus Settings The Modbus dialog box contains operational parameters for the Customer  Data Acquisition port. Setup (tab)Modbus Certain parameters need to be set up using the Configurator Software  to enable the Modbus port to establish communication with the Modbus See also “Digital Communication”...

  • Page 114: Temperature Control

    The proportional term of the PI temperature control algorithm for each zone. Ti (sec) The integral term of the PI temperature control algorithm for each zone. Startup (%) The duty cycle used on start-up for each temperature zone. 4-24 | Model 933 UV Analyzer...

  • Page 115: Optical Bench Temperature Control

    Too Cold (°C) This is an alarm temperature setpoint for each temperature zone. If the current temperature of the zone falls below its Too Cold setpoint, it will cause the analyzer to default to an alarm state. Too Hot (°C) This is an alarm temperature setpoint for each temperature zone.

  • Page 116: Measuring Cell Temperature Control

    (JP300, Micro-Interface board) Temperature Range Jumper Position Measuring Range A (default) -3 °C to 65 °C  Other ranges are available but AMETEK does not recommend chang- ing the range or the jumpers. NOTE 4-26 | Model 933 UV Analyzer...

  • Page 117: Column Block Temperature Control

    Column Block Temperature Control The Column Block temperature (measuring range is from 0 °C to 120 °C) is controlled by an RTD and heater so that it maintains consistent elution time. The operation of the Columns is optimal at 40 °C. As the tempera- ture is increased from 40 °C to 50 °C, the Columns will have to be switched more frequently.

  • Page 118: Output Setup

    Current High Scale setpoint corresponding to 20 mA . For ex- ample, if Scale 1 = 1000 PPM, Output 1 would read 20 mA at 1000 PPM and 4 mA at 0 PPM. Enter ‘0’ if an output is not used. 4-28 | Model 933 UV Analyzer...
  • Page 119 Iout Zero (mA) The measured current (mA) in the current output loop when the output is set to zero scale during the Zero calibration. Iout Span (mA) The measured full-scale current (mA) in the current output loop when the output is set to full-scale during the Span calibration. Vout Vout Assignment Voltage output assignment with and without Track and Hold...
  • Page 120 Alarm Disable once, followed by Alarm Enable (Output Setup dialog box). Not Checked The alarm will automatically return to the non-alarm state once the concentration falls below the Concentration Off value. 4-30 | Model 933 UV Analyzer...

  • Page 121: Analyzer Information

    Analyzer Information Before proceeding, test the area around the analyzer for explosive gases and proceed only when the area is found to be safe. WARNING Do not reset the analyzer if there is an explosive gas atmosphere pres- ent. The Information dialog box contains Microcontroller and Host Control- ...

  • Page 122: Optical Bench

    Reference PMT for each filter after an Auto-Setup is complete. These values are updated automatically by an Auto-Setup. ALC On ALC (Automatic Lamp Control) automatically becomes active at the completion of an Auto-Setup. Checked The ALC is active. Not Checked The ALC is disabled. 4-32 | Model 933 UV Analyzer...
  • Page 123 Lamp Conserve Mode The lamps are not pulsed during the time period between a column switch and 2 seconds before the first concentration output is tracked. The default (recommended) setting is the disabled state. Checked Lamp Conserve Mode is active. Not Checked Lamp Conserve Mode is disabled.
  • Page 124 PMTs have been installed or replaced. The process requires approximately three minutes. To determine when an Auto-Setup is needed, refer to Chapter 6. Cancel Auto-Setup Click this button to cancel the Auto-Setup. 4-34 | Model 933 UV Analyzer...

  • Page 125: Matrix

    Matrix The Matrix dialog box displays information that is responsible for partially  calculating the concentration output and negating the effects of cross-talk Setup (tab)Matrix by interfering gas species. These parameters should only be modified by a trained technician on advice from the factory.

  • Page 126: Column Timing

    A user-adjustable parameter in which the output is held after Column switching occurs. This will allow the output signal to appear steady. The time must be between ‘0’ (zero) seconds and the Column Switch Interval. 4-36 | Model 933 UV Analyzer...

  • Page 127: Compensation Parameters

    Gas 3 to Gas 1 Comp Effects of Gas 3 on Gas 1 are mathematically negated. For a standard Model 933 Analyzer, Gas 3 is MeSH and Gas 1 is H S. Gas 2 is COS. Gas 3 to Gas 2 Comp Effects of Gas 3 on Gas 2 are mathematically negated.
  • Page 128 5.0 V . See “0–100 PSIA Pressure Transducer” chart below. 0–100 PSIA Pressure Transducer Chart: Jumper Settings, Customer I/O Board PSIA mmHg JP301 JP302 0–100 0–5171.5 0–33 0–1706.6 33–66 1706.6–3413.2 66–100 3413.2–5171.5 4-38 | Model 933 UV Analyzer...
  • Page 129 While the 0–30 PSIA pressure transducer can not be re-scaled, its jumper settings are listed in the “0–30 PSIA Pressure Transducer” chart. 0–30 PSIA Pressure Transducer Chart: Jumper Settings, Customer I/O Board PSIA Pressure Range JP301 JP302 0–30 0–1552 mmHg ...

  • Page 130: Advanced Options

    The activated fault alarm relay will latch (will not clear) until you disable the Fault alarm by disabling this parameter. Not Checked The relay will automatically return to its non-alarm state once the fault condition has been corrected. 4-40 | Model 933 UV Analyzer...

  • Page 131: Custom Output (Custom Setup)

    Custom Output (Custom Setup) The Custom Output dialog box contains units information and configura-  tion parameters for custom setup. Setup (tab)Custom Setup Figure 4-19. Custom Output dialog box. Conversion Factors The units of measurement used for gas species concentrations (PPMV is equal to 1).

  • Page 132: Viewing Analyzer Data

    Fault alarms are also indicated by the Fault relay being de-ener- gized. See Chapter 6 for all system Warning and Fault alarms and the correc- tive action to take to clear and reset them. 4-42 | Model 933 UV Analyzer...
  • Page 133 Host Runtime The length of time the Host Controller has been operational. Micro Runtime The length of time the Microcontroller has been operational. Micro Wheel Speed The current Optical Bench Chopper (Filter) Wheel speed in rotations per minute (RPM). Micro State This displays messages that indicate which step of the Auto-Setup sequence is currently being performed: •...

  • Page 134: Optical Bench Data Tab

    The signal from the Reference PMT for each filter location. Absorbance The absorbance value for each filter location. ALC Lamp Pulse (mV) The real-time lamp pulse control of the Automatic Lamp Control func- tion, for each filter location. 4-44 | Model 933 UV Analyzer...

  • Page 135: Analyzer Data Tab

    Analyzer Data Tab The Analyzer Data tab displays live data from the Model 933 Analyzer. Figure 4-22. Analyzer Data tab. Concentration Displays each gas species being measured and their current values. Analog Output Concentration Values V-Output The concentration value at each analog voltage output channel.
  • Page 136 Digital Input Isolation Power Supply Power Supply JP401 Position Customer +15V to +24V 2-3 (default) Analyzer +24V Solenoid Displays energized solenoids (Zero, Column A, Column B). Alarm Displays the type of any active alarms. 4-46 | Model 933 UV Analyzer...

  • Page 137: Chapter 5 Calibration

    CALIBRATION Hazardous Locations Before proceeding, test the area around the analyzer for explosive WARNING gases and proceed only when the area is found to be safe. Do not remove the cover of the Explosion-Proof Digital Communica- tions Port on the front of the Lower Enclosure, do not connect a serial cable to the Communications Port, do not open the Upper/Lower En- closures, and do not power up/down the analyzer or computer if there is an explosive gas atmosphere present.
  • Page 138 Built” drawings in the analyzer Documentation Package). NOTE 4. Adjust the Span Gas regulator to between 80 and 90 PSIG (or as listed on system drawings). The pressure must be less than the 1380 kPag (200 psig) maximum Cell Pressure. 5-2 | Model 933 UV Analyzer...
  • Page 139 5. Change the Flow Control setting to “Zero”. Click OK then Apply. Do not save the changes to EEPROM. 6. Change the Span concentration value of the gas species to be cali- brated to the actual Span gas value that is being used. Click OK then Apply.

  • Page 140: Analog Output Calibration

    Repeat this step for Output 2 (Pins 3 and 4), Output 3 (Pins 5 and 6), and Output 4 (Pins 7 and 8), recording the value for each output in the corresponding field. 5-4 | Model 933 UV Analyzer...
  • Page 141 c. Click Apply to save the changes. d. To test the accuracy of the output channels, click Mid-Scale to turn On this function. Verify the current outputs are 12 mA, ± 0.03 mA. e. Click Zero Cal to change its status to Off. 2.

  • Page 142: Voltage Calibration

    (Output 1). Repeat this step for Output 2 (Pins 3 and 4), Output 3 (Pins 5 and 6), and Output 4 (Pins 7 and 8), recording the value for each output in the corresponding field. 5-6 | Model 933 UV Analyzer...
  • Page 143 c. Click Apply to save the changes. d. To test the accuracy of the output channels, click Mid-Scale to turn On this function. Verify the voltage outputs are 3 V, ± 5 mV. e. Click Span Cal to change its status to Off. 3.
  • Page 144 This page intentionally left blank. 5-8 | Model 933 UV Analyzer...

  • Page 145: Chapter 6 Maintenance And Troubleshooting

    MAINTENANCE and TROUBLESHOOTING This chapter discusses preventive maintenance to keep the analyzer sample system operating at peak efficiency, how to check for plugging in the analyzer sample system, and how to replace internal parts. This chap- ter also discusses how to view alarms (errors) that can be used to diagnose and troubleshoot problems with the analyzer.

  • Page 146: Preventive Maintenance

    Most leaks are preventable with regular cleaning and replacement of the Measur- ing Cell o-rings. Leak check the analyzer’s sample system whenever it has been dis- mantled for maintenance. 6-2 | Model 933 UV Analyzer...

  • Page 147: Analyzer Preventive Maintenance Schedule

    If the analyzer sets alarms that indicate a faulty component requires replacement (see “Troubleshooting and Diagnostics” in this chapter), WARNING follow the corresponding replacement procedure in this chapter. For complex maintenance procedures not discussed in this manual, such as replacing heaters, RTDs, or electronic boards, contact AMETEK. Or, review Chapter 7 and then contact AMETEK for assistance with returning the assembly/analyzer to the factory for repair.
  • Page 148 0.1 mm (Group IIB) 0.04 mm (Group IIB+H2) • Heated Column Block and Column Block Flange joining surfaces. Maximum Flamepath Gap: 0.05 mm (Group IIB) 0.04 mm (Group IIB+H2) For flamepaths not mentioned here, contact AMETEK. 6-4 | Model 933 UV Analyzer...

  • Page 149: Preventing, Detecting, And Locating A Plug In The Sample System

    Preventing, Detecting, and Locating a Plug in the Sample System Preventing a plug in the sample system: While various factors can contribute to plugs in the sample system, plugs can be avoided in many cases by: • Maintaining the ambient temperature around the analyzer, and the operating temperatures for each analyzer temperature zone.

  • Page 150: Changing Out Replaceable Parts

    System 200 Configurator Software. Familiarize yourself with the software before working on the analyzer. See Chapter 4 for details on how to navigate through the software. Figure 6-1. Cell Window Housing and Overtemp switch location, Upper Enclosure. 6-6 | Model 933 UV Analyzer...

  • Page 151: Measuring Cell Maintenance

    Measuring Cell Maintenance This procedure discusses a Standard Range Measuring Cell (40 cm or smaller, Figure 6-3.1) and a Low Range/White Cell (81.2 cm, Figure 6-3.2). See also Figure 6-2 to locate and identify parts. Other types of Measuring Cells are discussed in Manual Supplements shipped with the analyzer. Replace/clean parts in the Measuring Cell: •...
  • Page 152 Hold the Measuring Cell vertically with the Reflector Block up- ward and remove the Reflector Block. Remove the o-ring. Remove the Window Mounting Plate from the Window Holder. Grasp the edge of the Window and carefully remove it. Remove the o-rings. 6-8 | Model 933 UV Analyzer...
  • Page 153 Figure 6-2. Optical Bench, with Standard Range Measuring Cell. Maintenance and Troubleshooting...
  • Page 154 Window does not slide out of position when the Reflector Block is placed against the Measuring Cell. Secure the Reflector Block to the Measuring Cell with (3) M4 x 35 screws. Tighten the screws evenly. 6-10 | Model 933 UV Analyzer...
  • Page 155 Low Range Install (1) new o-ring (P/N 300-9060) in the end of the Measuring Cell that connects to the Window Holder. Install (1) new o-ring (P/N 300 9060) in the Window Holder. Place the Window (P/N 300-0281) in the Window Holder. Secure the Window Mounting Plate to the Window Holder with (3) M3 x 10 screws.
  • Page 156 Figure 6-3.1. Standard Range Cell, 40 cm or smaller. 6-12 | Model 933 UV Analyzer...
  • Page 157 Figure 6-3.2. Low Range/White Cell, 81.2 cm. Maintenance and Troubleshooting 6-13...
  • Page 158 17. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws. Tighten the M10 screws to 9.0 Nm, ±1.0 Nm (80 in.-lb, ±9 in.- lb). The procedure is complete. 6-14 | Model 933 UV Analyzer...

  • Page 159: Column Block Maintenance

    Column Block Maintenance The joining surface of the Column Block and Column Block Flange is a flamepath. CAUTION Take care to avoid damaging this flamepath when disassembling and reassembling the Column Block. Do not apply AC power to the analyzer if any of its flamepaths appear to be scratched, dented, or worn.
  • Page 160 Filters and they will have to be replaced. 5. Disconnect AC power to the analyzer and power down the computer before performing maintenance on the analyzer. 6. Disconnect the Column Block tubing. 6-16 | Model 933 UV Analyzer...
  • Page 161 Figure 6-4. Column Block assembly. Maintenance and Troubleshooting 6-17...
  • Page 162 If reusing the Columns, remove the #121 o-ring from each Column, clean the Columns, and install a new #121 o-ring (P/N 300-8719) in the o-ring groove on each Column. If using new Columns, the o-rings should come installed. 6-18 | Model 933 UV Analyzer...
  • Page 163 c. Clean the interior of the Column Block to remove contaminants. d. Insert (1) Filter Spool assembly in each Column, and gently push it all the way in. e. Replace both Column Assemblies in Column Block and hand- tighten. 9. Replace parts behind the Column Block Flange: a.
  • Page 164 18. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws. Tighten the M10 screws to 9.0 Nm, ±1.0 Nm (80 in.-lb, ±9 in.- lb). The procedure is complete. 6-20 | Model 933 UV Analyzer...

  • Page 165: Source Lamp Replacement

    Source Lamp Replacement The typical life span of the source lamps is approximately 9–12 months of continuous operation. However, a source lamp can exhibit signs of degra- dation after 5–6 months. When Do Source Lamps Need to be Replaced? Possible signs of degradation or indications of Source Lamp failures are: •...

  • Page 166: About The Source Lamps

    • New source lamps must be aligned to ensure optimal operation of the analyzer. • This procedure is based on the standard Model 933, bench code 8. Do not interchange the source lamps. Lamp 1 must be cadmium (Cd) – P/N 300-2070. Lamp 2 must be copper (Cu) – P/N 300-8707.
  • Page 167 3. Change the Flow Control setting to “Shut-In”. Click OK then Apply. Bleed down the sample system to atmospheric pressure (check gauge). Close the valve on the Vent Line (or cap the Vent outlet). To avoid tearing the Membrane Filters in the Filterblock, always bleed down the sample system pressure on the downstream (outlet) side of CAUTION the Filterblock.
  • Page 168 8. From the Output Setup dialog box, click Alarm Disable to disable  concentration alarms. Click OK. Setup (tab)Output  Setup (tab)Optical Perform an Auto-Setup. See “The Auto-Setup Sequence” in this chap- Bench<<Auto-Setup>> ter for more information. 6-24 | Model 933 UV Analyzer...
  • Page 169 9. From the Optical Bench dialog box, disable (turn off) Alc On (off = unchecked). Alc On must be disabled so the analyzer does not make automatic adjustments while you are setting the Measure and Reference signals to operate at optimum ratios to each other, as described below. Click OK then Apply.
  • Page 170 After the flow rate has been set, switch the Bypass Valve to the “BYPASS” position by turning it 180° (arrow facing upward). This will ensure no damage is done to the Rotameter during column switching. 6-26 | Model 933 UV Analyzer...

  • Page 171: When Is An Auto-Setup Required / Not Required

    18. Close the Configurator Software, power down the computer, and disconnect the serial cable from the analyzer’s Communications Port. Close the Communications Port cover and hand-tighten the screw to secure it in place. 19. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws.

  • Page 172: Pmt Level And Pmt Balance

    • Are the Measuring Cell Windows clean? • Are the PMT signals weak? • Are the PMTs in their original sockets (that is, is the higher gain PMT in the Measure path)? • Is the PMT Buffer board faulty? 6-28 | Model 933 UV Analyzer...

  • Page 173: Auto-Setup Fault Message And Corrective Action

    • Do the source lamps need replacement (weak lamps)? If not, are the source lamps aligned? • If the lamps were replaced, is the correct socket connected to the cor- rect lamp? Lamp 1 is the closest to the Optical Bench board. •...

  • Page 174: Cancel Auto-Setup

    PMT Balance should be between 2000–8000 mV. 6. If further adjustments are required, refer to “Manipulating the PMT Level and PMT Balance,” following this section. Cancel Auto-Setup To cancel the Auto-Setup, click Cancel Auto-Setup on the Optical Bench dialog box. 6-30 | Model 933 UV Analyzer...

  • Page 175: Manipulating The Pmt Level And Pmt Balance

    Manipulating the PMT Level and PMT Balance In certain situations (for example: degradation of PMTs or lamps, or the optics are contaminated), it may be necessary to change the P300 and P301 jumper settings on the Optical Bench board. Changing the jumper positions provides coarse gain adjustment of the Reference PMT and there- fore changes the PMT Level and PMT Balance.
  • Page 176 Balance Figure 6-9. Optical Bench board Lower PMT P300/P301 jumper Balance position vs PMT balance.  When changing jumpers, one must be present in one of the six posi- tions at all times. NOTE 6-32 | Model 933 UV Analyzer...

  • Page 177: Source Lamp Alignment

    Source Lamp Alignment If the Measure or Reference PMT voltage reaches 10 V at any time during the alignment manipulations (while rotating a lamp), decrease the PMT Level, allow the analyzer to stabilize for approximately 10 minutes, and perform an Auto-Setup to reset the PMT signals before continuing. To align the source lamps: 1.
  • Page 178 “Auto”. Click OK then Apply. Save the parameters to EEPROM. From the Output Setup dialog box, click Alarm Enable then OK. The lamp replacement and alignment process is complete and the ana- lyzer is ready to operate. 6-34 | Model 933 UV Analyzer...

  • Page 179: Natural Gas Filterblock Maintenance

    Natural Gas Filterblock Maintenance The Natural Gas Filterblock is used to filter pipeline natural gas for critical instrumentation applications. Under normal operating conditions, this gas often contains small quantities of liquids in the form of aerosol droplets or liquids travelling along the walls of the pipe. Depending on the processes upstream of the sample point, the liquids may be water, glycols, amines, alcohols, heavy process hydrocarbons, or compressor oils.

  • Page 180: Filtration Stages

    Vent Flow • The total vent flow in the Model 933 Analyzer is the sum of the flow through the analyzer plus the flow from the drain Flow Restrictors in the three filter stages.

  • Page 181: Replacing Parts In The Filterblock

    Replacing Parts in the Filterblock Replace/clean parts in the Filterblock: • Every year (see Note*).  See Chapter 7 for  * In natural gas streams that are extremely dirty, the Flow Restrictor spare part ordering numbers. in the first filter stage (and possibly the second filter stage) may need NOTE to be changed more often because it removes most of the liquids and particulate from the gas.
  • Page 182 If previous sample gas flow rates suggest possible plugging of the Fil- terblock Flow Restrictors, replace them with new ones. If there was an NOTE excessive amount of liquid in the first membrane filter stage, replace the first Flow Restrictor. 6-38 | Model 933 UV Analyzer...
  • Page 183 9. Clean all metal parts in the assembly by immersing them in a cleaning solvent (Isopropanol or reagent-grade acetone are both acceptable solvents). The solvent must not attack aluminum or stainless steel. Allow all parts to dry thoroughly before reassembling them. 10.
  • Page 184 Figure 6-10. Filterblock Assembly (100-1782). 6-40 | Model 933 UV Analyzer...
  • Page 185 16. Install the Filterblock Assembly on its mounting screws and tighten them. Reconnect the sample tubing to the Filterblock. 17. Power up the analyzer and computer. 18. Allow the analyzer to warm up then perform a leak check on the sample system fittings that were disconnected.

  • Page 186: Chopper Assembly Maintenance

    1. Connect a serial cable between the computer and the analyzer ’s  Communications Port. Using the Configurator Software, change the Setup (tab) Gas Calibration<<Flow Flow Control setting to “Zero”. Click OK then Apply. Do not save the Control>> changes to EEPROM. 6-42 | Model 933 UV Analyzer...
  • Page 187 2. If the analyzer uses Measured Pressure Compensations, change it to  Fixed mode so that a “Fault Sample Pres Lo” alarm does not occur. Setup (tab) Compensations Close the sample inlet valve. Backpurge the analyzer sample system with Zero gas for 2–3 minutes. 3.
  • Page 188 Upper Enclosure to the Opti- cal Bench. d. Optional: If your analyzer uses the Optical Bench Purge, discon- nect the purge line (black tube) from the Optical Bench Purge Fitting (Figure 6-12). 6-44 | Model 933 UV Analyzer...
  • Page 189 e. With one hand, grasp the upper portion of the Optical Bench to support it and, with the other hand, use a 4 mm ball driver to ro- tate the Lower Cam Pin clockwise and the Upper Cam Pin coun- ter-clockwise until they are in the “LOOSE”...
  • Page 190 The lined groove on the head of each Cam NOTE Pin must be parallel to the Measuring Cell until the Optical Bench is in place. b. Connect the terminals of the green/yellow ground wire. 6-46 | Model 933 UV Analyzer...
  • Page 191 Figure 6-12. Optical Bench Chopper Assembly Maintenance diagram (100-2313-1A). Maintenance and Troubleshooting 6-47...
  • Page 192 After the flow rate has been set, switch the Bypass Valve to the “BYPASS” position by turning it 180° (arrow facing upward). This will ensure no damage is done to the Rotameter during column switching. 6-48 | Model 933 UV Analyzer...
  • Page 193 15. Close the Configurator Software, power down the computer, and disconnect the serial cable from the analyzer’s Communications Port. Close the Communications Port cover and hand-tighten the screw to secure it in place. 16. Using a soft, nonabrasive cloth, gently clean the joining areas (flame- path) of the Upper Enclosure and its door and replace the (24) M10 screws.

  • Page 194: Examining And Caring For The Flamepaths

    Lower Electronics Enclosure and all threaded parts CAUTION on or in the Solenoid Junction Box, Solenoid Block, Heated Column Block, and optional Display assemblies. Clean, defect-free threads are essential to ensure a flameproof connection. 6-50 | Model 933 UV Analyzer...

  • Page 195: Upper/Lower Electronics Enclosure Flamepaths (Joining Surfaces)

    When performing equipment maintenance in hazardous areas, all safety standards and procedures must be followed, as specified by the WARNING Owner Company, local electrical-inspection authority, and National/ EU regulations. Do not apply AC power to the analyzer if any of its flamepaths appear to be scratched, dented, or worn.

  • Page 196: Troubleshooting And Diagnostics

    The Model 933 Analyzer has a built-in alarm detection system that con- tinuously monitors the operation of key parameters. An alarm can be detected by either the Host Controller or the Microcontroller and can be of two types: Fault and Warning.
  • Page 197 A Warning indicates the analyzer may require service and the data may be suspect. Though all Warning alarms cause the Warning Status relay to de- energize, the Warning Status relay can also indicate one of these analyzer operating conditions: • Performing a gas calibration (Auto-Zero, Zero, Span).

  • Page 198: Host Controller Board Alarm Conditions And Corrective Action

    • Check the Column Block RTD for a short or an open circuit. • Replace the Customer I/O board. Contact AMETEK to verify operation before removing this board. 6-54 | Model 933 UV Analyzer...
  • Page 199 Alarm Type / Alarm Condition Description and Suggested Corrective Action Warning Zero Drift This condition indicates excessive Zero Drift, such as when Zero gas transmission values attained after a Zero have exceeded user-specified values. Corrective Action: • Perform a Zero. See Chapter 5 for calibration information. •...
  • Page 200 • Check the connections of the cable between the Host Controller (J300) and Micro-Interface (J104) boards. Inspect it for damage (cuts, nicks, burn marks, etc.). • Replace the Microcontroller, Host Controller, and/or Micro-Interface Contact AMETEK to verify operation before removing any of boards. these boards. 6-56 | Model 933 UV Analyzer...
  • Page 201 Alarm Type / Alarm Condition Description and Suggested Corrective Action Fault Analytical Data This serious system Fault condition indicates the Host Controller board is not receiving analytical data from the Microcontroller board. Corrective Action: Take appropriate safety precautions and: • Cycle the analyzer AC power off for a minimum of 15 seconds before cycling it on again.
  • Page 202 • Check the Column Block RTD for a short or an open circuit (see “Column Block Maintenance” in this chapter). Replace the RTD, if necessary. Contact AMETEK to verify operation before removing this component. 6-58 | Model 933 UV Analyzer...
  • Page 203 Figure 6-14. AC Distribution board (P/N 100-1771). Maintenance and Troubleshooting 6-59...
  • Page 204 SW100 Figure 6-15. Host Controller board (P/N 100-1757). 6-60 | Model 933 UV Analyzer...
  • Page 205 SW400 Figure 6-16. Microcontroller board (P/N 100-1781). Maintenance and Troubleshooting 6-61...

  • Page 206: Microcontroller Board Alarm Conditions And Corrective Action

    • Replace the Optical Bench and/or PMT Buffer boards in the Optical Bench. Contact AMETEK to verify operation before removing these boards. 6-62 | Model 933 UV Analyzer...
  • Page 207 Alarm Type / Alarm Condition Description and Suggested Corrective Action Warning ALC One or both lamp pulse current-control signals has exceeded 9500 mV. The Lamp Maximum range is typically 4500–7800 mV. When this alarm occurs, the analyzer will initiate an Auto-Zero and then an Auto-Setup, to a maximum ...
  • Page 208 RTD (Upper Enclosure, see Figure 6-1) for a short or an open circuit. Replace the RTD, if necessary. Contact AMETEK to verify operation before removing this component. • Replace the Micro-Interface board. Contact AMETEK to verify operation before removing this board. 6-64 | Model 933 UV Analyzer...
  • Page 209 Alarm Type / Alarm Condition Description and Suggested Corrective Action Warning Bench Temp The Optical Bench temperature has exceeded its Too Hot setpoint or has fallen below its Too Cold setpoint, or the Optical Bench temperature range is not set properly. This alarm may occur during a cold start, but will clear after the temperature zone has stabilized within its normal operating range.
  • Page 210 Balance and PMT Level in relation to different jumper positions. • Ensure the Measuring Cell and its Windows are clean and not damaged. • Check and clean, if necessary, the Mirror in the PMT Block. Contact AMETEK to verify operation before checking. 6-66 | Model 933 UV Analyzer...
  • Page 211 Alarm Type / Alarm Condition Description and Suggested Corrective Action Fault Wheel Speed There is no signal from the Filter (Chopper) Wheel opto-interruptor, or the Chopper Wheel speed is outside the normal range of 240–600 RPM. Corrective Action: Take appropriate safety precautions, open the Upper Enclosure, and: •...
  • Page 212 • Check the connections of the cable between the Host Controller (J300) and Micro-Interface (J104) boards. Inspect it for damage (cuts, nicks, burn marks, etc.). • Replace the Microcontroller, Host Controller, and/or Micro-Interface boards. Contact AMETEK to verify operation before removing any of these boards. 6-68 | Model 933 UV Analyzer...
  • Page 213 Alarm Type / Alarm Condition Description and Suggested Corrective Action Fault Cell Temp The Measuring Cell temperature has exceeded its Too Hot setpoint or has fallen below its Too Cold setpoint, or the Measuring Cell temperature range is not set properly. This alarm may occur during a cold start, but will clear after the temperature zone has stabilized within its normal operating range.

  • Page 214: Analyzer Reset

    Host Controller CAUTION or Microcontroller boards have been replaced. In this case, it is neces- sary to shut down the analyzer. The analyzer will reset upon normal power-up. 6-70 | Model 933 UV Analyzer...

  • Page 215: Chapter 7 Service And Parts

    SERVICE and PARTS This chapter discusses what to do if you need technical support from AMETEK, or if you are returning parts for service. This chapter also lists the recommended spare parts to have on hand to ensure preventive maintenance is performed according to the schedule in Chapter 6. Technical Support AMETEK Western Research is committed to providing you the best tech- nical support in the industry.

  • Page 216: Returning Equipment

    To obtain a RMA number, contact your local or nearest AMETEK Service Centre and have the following information available: • Analyzer Model number. • Analyzer Serial number. • Purchase order number. • Billing address, shipping address, and telephone number. 7-2 | Model 933 UV Analyzer...

  • Page 217: Answers To Your Questions

    ?? ANSWERS TO YOUR QUESTIONS ?? The choice is yours... Whether by phone or in person, we can meet the needs required to keep your analyzer running at peak performance. Our factories are located in Calgary, Alberta and Newark, Delaware with a Sales & Service Centre in Houston, Texas.

  • Page 218: Recommended Preventive Maintenance Spare Parts

    Recommended Preventive Maintenance Spare Parts This section lists the recommended spare parts to have readily available for the Model 933 Analyzer to ensure the analyzer and its sample system operate at peak efficiency.  For drawings that illustrate the location of all spare parts in the analyzer, see “Preventive Maintenance”...
  • Page 219 Measuring Cell Spare Parts Part No. Description (1 Year) (2 Year) Standard Measuring Cells (5 cm, 10 cm, 15 cm, 20 cm, 40 cm, etc.) 300-0281 Cell Window, Fused Silica 100-2009 O-Ring, Size 125, Baked Aflas (See Note) Low Range (White) Cell (81.2 cm) 300-0281 Cell Window, Fused Silica...

  • Page 220: Spare Analyzer Fuses

    These fuses are located on the AC Distribution board in the Lower Enclosure (see Lower Enclosure Layout drawing (WX-14838) in Appendix A and the AC Distribution board drawing (P/N 100-1771) in the “Diagnostics and Troubleshoot- ing” section in Chapter 6. 7-6 | Model 933 UV Analyzer...

  • Page 221: Replacement Boards

    (PDF) on a CD shipped with the analyzer. To order a hard copy of the Operator’s Guide and the entire Documentation Pack- age, use the Part Number below: Part No. Description 903-8735 Model 933 UV Analyzer Operator’s Guide Service and Parts...
  • Page 222 This page intentionally left blank. 7-8 | Model 933 UV Analyzer...

  • Page 223: Appendix A - Drawings

    APPENDIX A – DRAWINGS This appendix contains drawings that are not included in the main body of this manual.  If your Documentation Package includes Final “As-Built” (job- specific) drawings, use those for installation and maintenance/ NOTE diagnostic purposes in place of the installation/maintenance drawings in this manual.

  • Page 224: Block Diagram, North American Style

    Block Diagram, North American Style (WX-933NA-1) A-2 | Model 933 UV Analyzer...

  • Page 225: Block Diagram, European Style (Wx-933Atex-1

    Block Diagram, European Style (WX-933ATEX-1) Appendix A – Drawings...

  • Page 226: Sample Flow Diagram (Plumbing Schematic), North American Style

    Sample Flow Diagram (Plumbing Schematic), North American Style (WX-933NA-2) A-4 | Model 933 UV Analyzer...

  • Page 227: Backpan Dimensions, North American Style

    Backpan Dimensions, North American Style (WX-933NA-3) PROCESS INSTRUMENTS OPTIONAL WHITE CELL PLUMBING CONFIGURATION 62.78 SERIAL COMMUNICATIONS PORT DO NOT OPEN IF A HAZARDOUS GAS ATMOSPHERE IS PRESENT MAY NOT BE EXACTLY AS SHOWN Appendix A – Drawings REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179)

  • Page 228: Backpan Component Layout, North American Style (Wx-933Na-3A

    PROCESS INSTRUMENTS OPTIONAL 81.2cm CELL PLUMBING CONFIGURATION 62.78 SERIAL COMMUNICATIONS PORT DO NOT OPEN IF A HAZARDOUS GAS ATMOSPHERE IS PRESENT MAY NOT BE EXACTLY AS SHOWN REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179) A-6 | Model 933 UV Analyzer...

  • Page 229: Conduit Entries, I/O And Ac Power Connection Locations, North American Style (Wx-933Na-3B

    Conduit Entries, I/O and AC Power Connection Locations, North American Style (WX-933NA-3B) LOWER ENCLOSURE DETAIL A REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179) Appendix A – Drawings...

  • Page 230: Lower Enclosure Layout (Wx-14838) - North American (Csa)/European (Zone 1/Atex

    Lower Enclosure Layout (WX-14838) – North American (CSA)/ European (Zone 1/ATEX) A-8 | Model 933 UV Analyzer...

  • Page 231: Customer Connections Wiring Schematic, North American Style

    Customer Connections Wiring Schematic, North American Style (WX-933NA-4) I/O BOARD CUSTOMER CONNECTIONS 120VAC POWER TERMINATIONS ISOLATED DIGITAL INPUTS NOTES: FACTORY DEFAULT HC BOARD CUSTOMER CONNECTIONS REFERENCE: CERTIFICATE NO: CSA CERTIFICATE 1031027 (LR48179) Appendix A – Drawings...

  • Page 232: Communications Cable Connections (300-9480

    RS-232 Communications Cable Connections (300-9480) A-10 | Model 933 UV Analyzer...

  • Page 233: Analyzer Wiring Diagram (Wx-102860-1

    Analyzer Wiring Diagram (WX-102860-1) Appendix A – Drawings A-11...

  • Page 234: Optional Hmi And Ethernet Gateway Wiring Diagram (Wx-102860-4

    GATEWAY POWER RS232 HOST CONTROL Chassis GND J302 +24VDC TxD- DC GND TxD+ Relay RxD+ HOST 18AWG Relay RxD- WIRES CONTROLLER 301-4183 J302 COM1 CABLE 22AWG 100-1757 100-2712 DCPWR 4-COND (300-0473) (JP303 at 2-3) A-12 | Model 933 UV Analyzer...

  • Page 235: Sample Probe - North American (Csa)/European (Zone 1/Atex

    Sample Probe – North American (CSA)/European (Zone 1/ATEX) Appendix A – Drawings A-13 REFERENCE CERTIFICATION NO: CSA CERTIFICATE 1031027 (LR48179)

  • Page 236: Sample Probe, Recommended Mounting Details - North American (Csa)/ European (Zone 1/Atex

    Sample Probe, Recommended Mounting Details – North American (CSA)/European (Zone 1/ATEX) A-14 | Model 933 UV Analyzer...

  • Page 237: Optical Bench Board (P/N 100-1662

    Optical Bench Board (P/N 100-1662) Appendix A – Drawings A-15...

  • Page 238: Pmt Buffer Board (100-0140

    PMT Buffer Board (100-0140) A-16 | Model 933 UV Analyzer...

  • Page 239: Inlet And Vent Flame Arrestor Locations, Environmental Purge Option (100-1783-1A

    Inlet and Vent Flame Arrestor Locations, Environmental Purge Option (100-1783-1A) Appendix A – Drawings A-17...
  • Page 240 This page intentionally left blank. A-18 | Model 933 UV Analyzer...

  • Page 241: Supplemental Information

    • Signed Final QC (Quality Control) Document • Final As-Built drawings (if ordered). Note that these drawings are not typically included with standard-built Model 933 Analyzers. • Other customer-specific information may also be included (if applicable), such as Product Data Sheets, a Custom Spare Parts list, or analyzer Certificates.
  • Page 242 This page intentionally left blank. S-2 | Model 933 UV Analyzer...

Table of Contents
