- Page 1 User manual 10” Slim Subwoofer...
-
Page 2: Table Of Contents
Serial connection Serial/Parallel connection Running-in time DLS support Welcome to DLS! Thank you for buying a DLS Reference RCS 10.D2 Enclosure info subwoofer. For us, it’s all about the sound experien- Sealed enclosures ce. We care deeply about sound and construction Vented enclosures quality. -
Page 3: Installation
Installation Wiring diagram Warning! Do not expose your amplifier to Your RCS 10.D2 subwoofer has a dual 2 ohm voice coil. How to connect the loads below the manufacturer’s recommen- subwoofer depends on what type of dations. Below you will find some examples amplifier you use and it´s optimum load. -
Page 4: Serial Connection
Parallel connection Serial connection Two 2 Ohm subwoofer = 0.5 Ohm load One 2 Ohm subwoofer = 4 Ohm load 4 Ohm 0.5 Ohm 2 Ohm 2 Ohm Two 2 Ohm subwoofer = 8 Ohm load 2 Ohm 2 Ohm 8 Ohm 2 Ohm 2 Ohm... -
Page 5: Serial/Parallel Connection
Serial connection Serial / Parallel connection Three 2 Ohm subwoofer = 12 Ohm load Two 2 Ohm subwoofer = 2 Ohm load 12 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm... - Page 6 Serial / Parallel connection Serial / Parallel connection Three 2 Ohm subwoofer = 1.33 Ohm load Three 2 Ohm subwoofer = 3 Ohm load 1.33 Ohm 3 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm 2 Ohm...
-
Page 7: Running-In Time
DLS support Note! RCS10.D2 has a design with “open voice coil” for improved cooling. This For technical assistance, ask your car construction gives the best sound perfor- audio dealer where the product was sold or mance. -
Page 8: Sealed Enclosures
40Hz), and at the expense of some control Sealed enclosures and power handling at the lowest frequen- cies ( below the ports tuning frequency). If Sealed enclosures constructions is straight you are using a small amplifier a vented forward and are easy to build. The size is box will provide more perceived bass not critical, but it can’t be too small. -
Page 9: Enclosure Placement
Note! The performance of the recommen- compartment is separated from the trunk, ded enclosures will vary from vehicle to one option is to install enclosure with the vehicle. It is more difficult to get a tight and subwoofer directed towards the rear seat. well defined bass in a SEDAN vehicle Some cars have an opening in the middle because of the separated space between... -
Page 10: Specifications
Specifications Art no CS-RCS10.D2 Electro-Acoustic Parameters Size: 10”/250mm 33Hz Impedance: 2 + 2 Ohm 3.8 (1.9+1.9) Ohm RMS power: 600W Qms: 6.37 MAX power: 1200W Qes: 0.51 Sensitivity: 85 dB 1W/1M Qts: 0.47 Voice coil size: 63.5 mm / 2.5”... -
Page 11: Product Markings
European Economic Area (EEA). DLS products complies with the relevant provisions of the RoHS Directive for the European Union. In common with all Electrical and Electronic Equipment (EEE) the product should not be disposed of as household waste.
