32" LCD HDTV
With Built-in DVD Player
DTV-323-D
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTV-323-D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mintek DTV-323-D

Summary of Contents for Mintek DTV-323-D

  • Page 1 32" LCD HDTV With Built-in DVD Player DTV-323-D OWNER'S MANUAL...

  • Page 2: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS • If an outside antenna is connected to the television equipment, be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, Iocation of antenna-discharge unit, connection to grounding electrodes,and requirements for the grounding electrode.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS (FOR TV TUNER) IMPORTANT INFORMATION IMPORTANT SAFETY PRECAUTIONS SUPPLIED ACCESSORIES PREPARATION INSERTING BATTERIES INTO THE REMOTE CONTROL ● USING THE REMOTE CONTROL UNIT ● CAUTIONS REGARDING REMOTE CONTROL UNIT ● DISPLAY FRONT VIEW ● REAR VIEW ●...
  • Page 4 TABLE OF CONTENTS (FOR DVD PLAYER) BASIC OPERATIONS PLAY DISCS ● PAUSE ● ● VOLUME CONTROL ● DVD MENU PLAY ● SELECT WITH NUMBER BUTTONS ● PLAY DISCS IN VARIOUS WAYS AUDIO MODE ● MUTE ● FAST PLAY ● REPEAT PLAY ●...

  • Page 5: Important Information

    ● Correct the equipment into an outlet on a circuit different from that to which the receiver ● is connected. Consult the dealer or an experienced radio, TV technical for help. ● Only shielded interface cable should be used. ●...

  • Page 6: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS The present set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in the present unit will protect you if you observe the following procedures in installing, using and servicing. The present unit is fully transistorized and does not contain any element that can be repaired by the user.
  • Page 7 17. Water and moisture - Do not use this product near water such as bathtub, washbasin, kitchen sink and laundry tub, swimming pool and in a wet basement. TV set shall not be exposed to dripping or slashing and no objects filled with liquid, such as vases, shall be placed on the TV set.

  • Page 8: Supplied Accessories

    A. MODE RETURN VIEW MODE VIEW MODE RC-175C Remote control It also include: ①batteries (2) ②Warranty card Component Video Cable or Audio cable for PC input page4 Y/Pb/Pr cable 32" LCD HDTV With Built-in DVD Player DTV-323-D OWNER'S MANUAL User guide...

  • Page 9: Preparation

    TV. Objects between the remote control and the sensor may disrupt operation. Effective range is 20 feet but is dependant on what your ● viewing angle is. Range can also be affected by direct sunlight on the TV’s ● sensor. page5...

  • Page 10: Display

    5) MENU: Use to bring up the TV menu. 6) VOLUME+/-: Use to adjust the volume. 7) CH+/-: To skip to the previous/next channel; in other mode, press it to shift to TV mode. 8) Power Button: Use to turn the unit on or off.

  • Page 11: Rear View

    DISPLAY REAR VIEW HDMI INPUT INPUT 1) HDMI Input 2) DVI Input 3) AUDIO (DVI Input) 4) AV2 IN (Component Video(Y、P 5) AUDIO OUT 6) AV1 IN ( Composite Video, S-Video and Audio In) 7) RS-232 Terminal 8) Antenna In 9) AC INPUT AUDIO AUDIO...

  • Page 12: Remote Control

    4) Number Buttons: Use to set the channel numbers. Dot Button: In Digital TV mode, there can be several TV programs in a channel, use the number buttons and the dot button to enter. Example: press the number button 5, the dot button, and then the number button 2 to enter the TV program 5-2.
  • Page 13 REMOTE CONTROL 5) MTS/SAP: Use to select the MTS/SAP stereo mode. 6) VOL +/-: Use to adjust the volume. 7) TV MENU: Use to bring up the TV menu. 8) Cursor Buttons ( 9) OK: Use to confirm your selections.

  • Page 14: Connections

    CONNECTIONS HDMI INPUT AUDIO DV I AUDIO AV 2 I N INPUT DVI INPUT page10 VIDEO AUDIO S-VIDEO AUDIO R S 2 3 2 A N T. I N AUDIO AV 1 I N...

  • Page 15: System Connections

    DTV-323-D. Use the VIDEO button and the signal source to HDMI . f. Using the DVI connector: Connect a PC computer to the DTV-323-D through the DVI socket on DTV-323-D. The Mini-plugged is for audio associated with this type of signal. Use the VIDEO button and the buttons to set the DTV-323-D’s signal source to "Composite".

  • Page 16: Basic Operations

    MENU TURN ON THE POWER 1. Press POWER button on the front panel to turn on the TV set. The POWER indicator lights up green. 2. If the STANDBY indicator still lights up red, press POWER on the remote control to turn the TV set on.

  • Page 17: Watching Tv

    WATCHING TV TURN ON THE POWER 1. Press POWER button on the front panel to turn on the TV set. The POWER indicator lights up green. 2. If the STANDBY indicator still lights up red, press POWER on the remote control to turn the TV set on.

  • Page 18: Number Buttons

    WATCHING TV Using number buttons on the remote unit NUMBER BUTTONS Select the channels directly by pressing the number buttons. EXAMPLE: To select a 1-digit channel (e.g. channel 2): Press 2 . ● To select a 2-digit channel (e.g. channel 12): Press 1 ,followed by 2 .

  • Page 19: Simple Button Operation For Changing Volume/Sound

    WATCHING TV SIMPLE BUTTON OPERATION FOR CHANGING VOLUME/SOUND Changing the volume You can change the volume by pressing VOL +/- button. VOL+/- SOURCE MENU 1. Press VOL+ to increase the volume. 2. Press VOL- to decrease the volume. Using MUTE on the remote control Press MUTE to mute the current sound output.

  • Page 20: Watching Tv

    This feature is called Multi-channel Television Sound (MTS). The System with MTS can receive mono sound, stereo sound and Secondary Audio Programs (SAP). The SAP feature allows a TV station to broadcast other information, which could be audio in another language or something completely different like weather information.

  • Page 21: Basic Adjustment Settings

    You can get the satisfied picture by adjusting the following Video menu. Press the VIEDO button to select various signal modes. Press the TV MENU button to enter LCD menu. Press to select "VIDEO MENU", and then press OK or Brightness 1.
  • Page 22 2. Press to select a Temperature Mode among: Cool, Normal, Warm, and User. When "User" is selected, the screen shows: 3. Press to select "Temperature (R)", "Temperature (G)", "Temperature (B)", and press adjust. 4. Press TV MENU to exit. page18...

  • Page 23: Audio Menu

    AUDIO MENU Adjust the quality of the sound through the following Audio menu. Press the VIDEO button to select various signal modes. Press the TV MENU button to enter LCD menu. Press to select "AUDIO MENU", and then press OK or Treble 1.

  • Page 24: Screen Menu

    2. Press OK to enter the Horizontal Position menu. 3. Press to adjust the horizontal position of the playback picture. 4. Press OK to return; press TV MENU to exit. Vertical Position 1. Press to select "Vertical Position" in "Screen" menu.

  • Page 25: Channel Menu

    4. Press TV MENU to exit. Example: 1. In analog TV mode, it is need to select Favorite Mode Off by pressing FAVORITE button and then enter into the channel menu after searching all the TV program. 2. Press OK or to select ANALOG in Favorite Channel .
  • Page 26 2. Press OK to enter the "Fine Tune" menu. 3. Press to adjust the current channel clearer as your desired. 4. Press OK to return; press TV MENU to exit. NOTE: "Fine Tune" only works on Analog TV channels. page22...

  • Page 27: Setup Menu

    BASIC ADJUSTMENT SETTINGS SETUP MENU 1. Press the TV MENU button to enter LCD menu. 2. Press to select "SETUP MENU", and then press OK or Language 1. Press to select "Language" in "Setup" menu. 2. Press to select a language.

  • Page 28: Closed Caption Menu

    3. Press TV MENU to exit. Note: a. Only in Digital TV mode, digital CC is available. b. In digital TV mode, the "Analog CC" is preferential. If you want to view "Digital CC", only set "Analog CC" to "OFF" in CLOSED CAPTION MENU.
  • Page 29 "Font Style" in "Closed Caption" menu. 2. Press to select a font style among: Default, Style1, Style2, Style3, Style4, Style5, Style6 and Style7. 3. Press TV MENU to exit. Foreground Color 1. Press to select "Foreground Color" in "Closed Caption" menu.

  • Page 30: Parental Menu

    BASIC ADJUSTMENT SETTINGS PARENTAL MENU Only in Digital TV, Analog TV, Composite and S-Video mode, there is Parental menu. 1. Press the TV MENU button to enter LCD menu. 2. Press to select "PARENTAL MENU", and then press OK or The password menu displays.
  • Page 31 "Change Password" in "Parental" menu. 2. Press OK to display the Change Password menu. 3. Enter your new password with numbers, then input it again and press OK to confirm. 4. Press TV MENU to exit. MPAA (Movie Rating) 1. Press to select "MPAA"...

  • Page 32: Basic Adjustment Settings

    1. Press to select "TV Guidelines" in "Parental" menu. 2. Press OK to display the TV Guidelines menu. 3. Press to select desired US-TV position and press OK to confirm. 4. Press TV MENU to exit. Status 1. Press to select "Status" in "Parental" menu.

  • Page 33: Window Adjustment

    WINDOW ADJUSTMENT In PC mode you have to set the Windows system firstly as below. SVGA NOTE: If the PC resolution is set higher than what is listed on the chart, the monitor will display a black screen. The effect will be optimum when the freguency you selected is 60Hz. Setup your PC software…...
  • Page 34 WINDOW ADJUSTMENT 2. Click on "Control panel", the control panel screen appears. 3. Double click on "Display" and a display dialog box displays. 4. Navigate to the "Setting " tab on the display dialog box .Set the "Screen resolution" to "1024×768 pixel".

  • Page 35: Troubleshooting

    Reception. If so, change the mode to Mono. - Check if the batteries in the Remote control die. Remote control does - Check if any object between IR sensor of the TV and the Remote not work. control does not obstruct.

  • Page 36: Technical Specifications

    TECHNICAL SPECIFICATIONS PANEL RESOLUTION VIEWING ANGLE (H/V) CONTRAST RATIO BRIGHTNESS (cd/m2) EFFECTIVE PIXEL RATE WITH STAND (mm) DIMENSION WITHOUT STAND (mm) TV STANDARD TUNING SYSTEM FREQUENCY RANGE TV-FUNCTION CATV DIGITAL TERRESTRIAL BROADCAST (8VSB) ANALOG TERRESTRIAL INPUT POWER SOUND OUTPUT POWER CONSUMPTION...

  • Page 37: Basic Operations

    4. The unit begins to read the disc. 5. Press (PLAY) to play the disc. AFTER STEP 4 IS FINISHED: If playing a DVD, the TV screen shows DVD menu or ● title menu. If playing a CD, press (PLAY), and the unit plays ●...
  • Page 38 BASIC OPERATIONS (FOR DVD PLAYER) Remember, you can only access the Display when you're playing a disc. Also, the Display features are only available if the disc was created with that particular feature (i.e., if you select the Subtitle icon, you won't be able to change the subtitle language unless the author of the disc created the disc with subtitles).
  • Page 39 BASIC OPERATIONS (FOR DVD PLAYER) 1. When the disc is playing, press OSD on the remote to bring up the Display. 2. Press the buttons to highlight the Subtitle icon. 3. Press the buttons to scroll through the subtitle languages that are available on the disc until the subtitle language you want to use appears in the text box.

  • Page 40: Volume Control

    Repeat options until the Repeat option you want is displayed in the text box. 4. The selected repeat option will loop repeatedly until you turn Repeat off. Volume Control Press VOLUME on the TV or amplifier to adjust the ● volume. Press VOLUME on the remote control. ●...

  • Page 41: Select With Number Buttons

    BASIC OPERATIONS Select with Number Buttons Load a disc. Press number buttons to select tracks after the unit finishes reading the disc. 1. If the track number isn't over 10, just push buttons 1-10. Example: push 8 to select track 8. The screen shows: TRACK08/20 00:00...

  • Page 42: Play Discs In Various Ways

    PLAY DISCS IN VARIOUS WAYS To select audio channel option when for CD playback, press A.MODE . The screen will show the following in order: A.MODE MONO LEFT A.MODE MONO RIGHT A.MODE MIXED MONO A.MODE STEREO You may select one mode. Notes: Different discs differ in languages available.

  • Page 43: Repeat Play

    PLAY DISCS IN VARIOUS WAYS Repeat Play This function can be used to repeatedly play a title, chapter, track, or a whole disc. DVD TITLE DVD MENU PREV NEXT ZOOM SETUP AUDIO REPEAT PLAY MODE SUBTITLE A. MODE RETURN VIEW MODE VIEW MODE RC-175C You can repeat a title or chapter.

  • Page 44: Select Subtitles

    PLAY DISCS IN VARIOUS WAYS Select Subtitles This operation works only with discs with multiple subtitle languages recorded. DVD TITLE DVD MENU PREV NEXT ZOOM SETUP AUDIO REPEAT PLAY MODE SUBTITLE A. MODE RETURN VIEW MODE VIEW MODE RC-175C 1. Press SUBTITLE repeatedly until the desired language is selected.

  • Page 45: Program Play

    PLAY DISCS IN VARIOUS WAYS 1. Press P.MODE until the screen shows: PROGRAM: TRACK (01-20) 01 _ _ 06 _ _ 02 _ _ 07 _ _ 03 _ _ 08 _ _ 04 _ _ 09 _ _ 05 _ _ 10 _ _ EXIT NEXT...

  • Page 46: Menu Setting

    MENU SETTING According to the recorded information and external equipment, set the following functions for the player to obtain the best playing status. DVD TITLE DVD MENU PREV NEXT ZOOM SETUP AUDIO REPEAT PLAY MODE SUBTITLE A. MODE RETURN VIEW MODE VIEW MODE RC 175C 1.Press SETUP to set options in the main menu.

  • Page 47: General Setup

    Wide-screen images are shown on the screen, but with some parts cut automatically. 2. NORMAL/LB This is selected when the unit is connected to a normal TV. Wide-screen images are shown on the screen with black bars on the top and bottom of the screen. 3. WIDE This is selected when the unit is connected to a wide-screen TV.

  • Page 48: Audio Setup

    SCREEN SAVER The screen saver image appears when the unit stops or the image is frozen for a few minutes. The screen saver prevents damage to the TV screen. ON: Start the screen saver. ● OFF: Remove the screen saver.

  • Page 49: Password Setup

    MENU SETTING ■ 3D PROCESSING The setting structure is: - - 3D Processing Page - - V SURR Reverb Mode Concert Living Room Hall Bathroom Cave Arena Church Audio Setup V SURR ● Use to turn the above function off. REVERB MODE ●...

  • Page 50: Preferences

    OFF when the unit is in stop mode. MP3 OPERATIONS SELECT TRACKS WITH ■ NUMBER BUTTONS 1. Insert a disc, the unit will search disc information. The TV screen displays main menu. 00:00 00:00 001/012 FOLDER CD01 CD02 CD03...

  • Page 51: Kodak Picture Cd Playback

    You can select any of the nine displayed thumbnails by using the Arrow Keys and pressing the "PLAY" key. The thumbnail will be enlarged to fit the TV screen and the slide show will start. If you desire to display an image indefinitely, press the PAUSE key.

  • Page 52: Digital Card Play Operation

    MEMORY CARD PLAY OPERATION MEMORY CARD (MMC/SD /Memory Stick card ) can memory MP3 songs and digital pictures . How to select MEMORY CARD to play 1. Turn on the power. 2. Insert MMC/SD/Memory Stick card to the "3 in 1 DIGITAL CARD" Slot. 3.

  • Page 53: Troubleshooting

    If you experience the following problems while using the unit, this troubleshooting guide can help you. No sound Check if the unit is connected securely. ● Make sure the TV or amplifier is working properly. ● Make sure the amplifier is set to receive DVD signal ●...

  • Page 54: Technical Specifications

    TECHNICAL SPECIFICATIONS Laser Video system Frequency response Signal/noise ratio Audio distortion + noise Channel separation Dynamic range Audio out (analog audio) Output Video out Power supply Power Consumption This manual is only for your reference, any change to the design and specifications will not be advised. Wavelength 650nm NTSC 20Hz ~ 20KHz±2.5dB...
