Verus Sports TG413 Assembly Instructions

1
2
4
1

End Upright Assembly

Insert the #1 Leg Bases and #4 Center Frame poles into the
4 Way End Connector. Then insert the #2 End Upright pole.
3
5
5

Center Frame Assembly

Using the remaining #5 Center Frame Long poles, connect
the End Upright and Center Upright.
ASSEMBLY & PLAY INSTRUCTIONS for ITEM'S TG413, TG415, TG417
4 Way End Connector
2 Pc
#4
Center
Frame
2 Pc
#2
End
Upright
2 Pc
Net
1 Pc
TG413 includes NET ONLY no paddles and balls.

To set up the game, follow the instructions below:

1
Make sure the push pins are engaged.
5
5
PICKLEBALL

Components

5 Way End Connector
1 Pc
#6
Short Leg
#3
#1
Base
Center
Leg
6 Pc
Frame
Base
Upright
4 Pc
1 Pc
Ball
3 Pcs
2
1
5
Center Upright Assemble
Insert the #1 Leg Bases and #5 Center Frame Long poles into
the 5 Way Center Connector. Then insert the #3 Center Upright
pole.
4

Net Assembly

With the frame fully assembled, slide the net over each upright.
Using the hook & loop connectors secure the net to the center frame.
This will prevent the net from sliding up.
If required, you can tighten the net by securing the hook & loop
material around the End Upright poles.
To disassemble the net, remove the net from the frame. Then depress
the push pins on each pole connector to remove.
#5
Center
Frame
Long
6 Pc
Paddle 4
Pcs
3
5
1
