Verus Sports BM300 Assembly And Playing Instructions

1
. pOlE aSSEMblY
Squeeze the push button ends together
and insert the push buttons into the top
and middle pole sections. Make sure
the buttons protrude through the holes
as shown in Figure 1, Detail A.
NOTE: Insert the smaller push button
into the top pole section and the larger
push button into the middle section.
assemble the pole as follows:
a. Insert the top pole section into the
middle pole and the middle pole
into the bottom pole by aligning
the holes and push buttons. See
b. Depress each push button and
slide poles together until the but-
ton
snaps through the hole in its mat-
ing pole section.
TIp: Don't put plastic caps on top
pole sections until after net has
been attached.
TIp: Don't use pole anchors on
poles until step 5 of instructions
is begun.
5
. NET SET Up
Stretch assembled net and poles across playing area until net is
taught. Press pole anchors into ground where poles touch ground.
Slip poles onto anchors. Holding poles in vertical position, press guide
rope stakes into ground at 45º angle, 3' to 5' from pole and 3' to 5'
apart. Make sure hooks on stakes are facing away from poles. See
Figures 4 and 5.
Top
Guide
Ropes
Figure 4
bottom
Guide
Ropes
3'- 5'
3'- 5'
TIp: After the net is completely assembled, you can adjust the net
tension by sliding the tension clips up or down along guide ropes.
aSSEMblY and plaYING INSTRUCTIONS for ITEM bM300
ADVANCED SILVER BADMINTON SET
Plastic
2
Cap
. NET aTTaCHMENT
First
Slide the net sleeve
Hole
over the top section
Top
of assembled pole
Section
making sure the net
top with Connecting
Small
Loop is at the top
Push
end of the pole, see
Button
Figure 2.
Detail
Middle
A
Section
Connecting
loop
Large
Push
Button
Bottom
Section
Pole
Anchor
Figure 2
Figure 1
6
. bOTTOM GUIDE ROpE SET Up
Make loop on bottom guide rope
tension clip large enough to slip over
stake already in ground. Make
sure guide rope loop is placed
under stake hook as shown
in Figure 5.
Top
Guide
Rope
Ground
Stake
Hook
VERUS SpORTS • Fort Washington, PA 19034 • www.verussports.com
3
. TOp GUIDE ROpE aTTaCHMENT
Insert the eye bolt, with long guide rope
and pre-attached tension clips
and stakes through the hole
in the Top Pole Section as
shown in Figure 3. Secure
with wing nut. Rotate and
tighten the wing nut so
that the loop is posi-
tioned vertically as
shown in Figure 3.
Top
Pull the net
Guide
upward and hook Ropes
the connecting
Tension
cord loop onto
Clip
the lower wing
nut loop to
Stake
secure the net.
Plastic cap can
now be placed
on top pole.
Figure 3
Ground
Stakes
bottom Guide Rope
loop Figure 5
Wing Nut
Eyebolt
4
. bOTTOM GUIDE
ROpE aTTaCHMENT
Insert eyebolt, with short
guide rope and pre-
attached tension clips,
through hole in third pole
section and secure with
bottom
Guide Ropes wing nut.
7
. SCORING SYSTEM
After the net is set up, make sure the score marker guide
ropes are straight. If not, adjust the ropes by opening the
knots, pull the ropes taut and re-tie the knots. To adjust
the score, depress the score marker push button, slide the
marker to the desired number and release the push button.
Figure 6
Knot
push
button
Warning
Adult supervision is necessary whenever
children are playing. Being hit by a thrown
object can result in a serious injury.
plastic Cap
Connecting
Cord loop
Detail a
Guide Rope
