- Page 1 MReX-MB1 Transmitter User Manual v3.16 Firmware MReX-MB1 MINI POCSAG & DMR MESSAGING TRANSMITTER User Manual Page 1 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
-
Page 2: Table Of Contents
Firmware Upgrade Utility......26 *CH_BUSY.........13 Firmware Upgrade Process.......27 Base Commands........14 Disclaimer............28 *CONFIG..........14 Manufacturing marking and labels....29 *SAVE..........14 Maintenance..........29 *DEFAULTS........14 Product End Of Life........30 Input Commands........15 Product Warranty...........31 *IN_CONFIG_L........15 Specification..........32 Page 2 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 3: Introduction
MReX-MB1 Transmitter User Manual v3.16 Firmware Introduction Thank you for choosing the MReX-MB1. The MReX-MB1 is a table mountable, single button POCSAG and DMR messaging transceiver. MReX-MB1 Features • Sends 512, 1200 POCSAG paging messages. • Transmits DMR Tier 1 text messages. -
Page 4: Safety Information
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury NOTICE NOTICE is used to address practices not related to physical injury. Page 4 of 34 © WTE Limited, 2021 – Christchurch New Zealand... - Page 5 System control paths may include communication links. Consideration must be given to the implications of anticipated transmission delays or failures of the link. Failure to follow these instructions can result in death or serious injury Page 5 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
- Page 6 • Although this product is designed to be rugged, it will not survive excessive shock or vibration abuse. • The MReX-MB1 IP rating is IP-62. This product should not be submerged or subjected to spraying water. Page 6 of 34...
- Page 7 For more information about where you can drop off your waste equipment for recycling, contact the dealer from whom you originally purchased the product. Page 7 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
-
Page 8: Operation
The MReX-MB1 will illuminate the red LED when the button is pressed and remain lit until the programmed transmission has been sent. If the button is pressed, and held until after the red LED turns off, the MReX-MB1 will begin to flash on and off for 5 seconds, allowing the unit to accept configuration commands. -
Page 9: Dmr Messaging
MReX-MB1 Transmitter User Manual v3.16 Firmware DMR Messaging The MReX-MB1 supports the transmission of short Digital Mobile Radio text messages, allowing direct messaging to many brands of DMR radios. The MReX has a partial implementation of the ETSI TS 102 361-1 DMR standard allowing for DMR “Tier 1”... -
Page 10: Configuration
Start-up operation is always at 9600:8-N-1. The MReX-MB1 integrates the MReX-460 module, therefore has available the MReX-460 command set. However, only a subset of those commands are relevant to the MReX-MB1. Relevant commands are listed below. All configuration commands always start with the asterisk ‘*’ character. -
Page 11: Transmit Commands
TT is the time in seconds between transmissions (60-65536. 0 disables the feature). MMMM is the periodic message to transmit (up to 50 characters). E.g. *TX_PERIODIC=10,WT1234560A10 Test_Message<CR> Page 11 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 12: Tx_Pwr
25mW. This power level can be increased as an option. Being able to set the periodic message at a lower level means that if the MReX-MB1 is used as a pendant, a frequent low power transmission could be used to determine if someone is in proximity to a location of interest. -
Page 13: Busy
BB is the signal level from 0 to -130 (in dBm). In this example the channel will be considered “busy” if signal strength is above -80dBm. Typical usage: *CH_BUSY=-80<CR> Page 13 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 14: Base Commands
*SAVE *SAVE saves all configuration settings (all config changes are restored on start-up). Usage: *SAVE <CR> *DEFAULTS *DEFAULTS forces to reset temporary to factory default settings. Usage: *DEFAULTS<CR> Page 14 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 15: Input Commands
Example. Configure input 1 to send two message after input is debounced by 300 milliseconds and repeat/retransmit this message 4 times. *IN_CONFIG_L=1:2,3,4<CR> *IN_MSG_L *IN_MSG_L specifies the low level message that will be transmitted if configured. E.g. *IN_MSG_L=1:WT1234560A10 IN_1_LOW<CR> Page 15 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 16: Wt Protocol
MReX-MB1 Transmitter User Manual v3.16 Firmware WT Protocol The WT Protocol is the default protocol used by WTE products. It allows for a variety of over the air transport methods (such as POCSAG paging) to be used and a variety of baud rates. -
Page 17: Support For Multiple Messages
To send the message “TEST” to RIC codes 1234560 and 1222222 as a 512 baud POCSAG message and also RIC codes 0201234 and 0005647 as a 1200 baud POCSAG message. WT1234560A1AWT1222222A1AWT0201234A1BWT0005647A1B<SPACE>TEST<CR> Page 17 of 34 © WTE Limited, 2021 – Christchurch New Zealand... - Page 18 MReX-MB1 Transmitter User Manual v3.16 Firmware 4 messages will be transmitted, batched in 2 transmissions, one for 512 baud messages and another transmission for the 1200 baud messages. Page 18 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
-
Page 19: Dmr Message Format
WT0001001D60<SPACE>TEST MESSAGE<CR> Example: To send a DMR message to individual ID 104, colour code 6 with payload of “TEST MESSAGE” and to a type ‘0’ radio (Hytera) WT00001041d60<SPACE>TEST MESSAGE<CR> Page 19 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 20: Input Handling
MReX-MB1 Transmitter User Manual v3.16 Firmware Input Handling The MReX-MB1 supports a single programmable input short message up to 50 characters in length. Input messages must always be formatted as WT Protocol. Commands relating to input handling: *IN_CONFIG_L specifies all input transition to low level configuration parameters. -
Page 21: Hardware And Configuration
MReX-MB1 Transmitter User Manual v3.16 Firmware Hardware and Configuration In order to replace/install batteries and/or change the transmitter configuration remove the lid to access the battery compartment and programming header. Open Close Page 21 of 34 © WTE Limited, 2021 – Christchurch New Zealand... - Page 22 MReX-MB1 Transmitter User Manual v3.16 Firmware Page 22 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
-
Page 23: Battery Installation
MReX-MB1 Transmitter User Manual v3.16 Firmware Battery Installation Fit coin cell battery as shown below. Note: ESD precautions must be observed at all times when handling. Page 23 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 24: Loading Configuration
7. The MReX-MB1 red LED will slowly flash on and off to indicate that commands can be accepted. 8. Release the depressed button. - Page 25 10. Load configuration file if required. Select the configuration file that has been saved previously using the top right “Load Config” button. 11. After 60 seconds of serial port activity, the MReX-MB1 will exit its configuration mode and return to normal low power operation.
-
Page 26: Firmware Upgrading
3. An appropriate encrypted hex file supplied by WTE Limited. Note: Attempting to load a hex file not intended for use with the MReX will render the MReX inoperable. Uploading firmware should only be performed if instructed to do so by WTE Limited or an authorised agent. -
Page 27: Firmware Upgrade Process
MReX-MB1 Transmitter User Manual v3.16 Firmware Firmware Upgrade Process 1. Run the application WTEBoot.exe – this is the WTE Firmware Update Tool as shown above. 2. Ensure the coin cell battery has been removed. 3. MReX must be connected to a MReX-PROG USB programming adaptor, please refer to the “Loading Configuration”... -
Page 28: Disclaimer
It is the users responsibility to ensure local regulations are adhered to. In no event shall WTE Limited be liable for any incidental, special, indirect or consequential damages, harm to any person, lost profits or lost data, harm to your equipment, cost of procurement of substitute goods, technology or services, any claims by third parties (including but not limited to any defence thereof), any claims for indemnity or contribution, or other similar costs. -
Page 29: Manufacturing Marking And Labels
Maintenance No User-Serviceable Components. Servicing is only to be performed by WTE Limited, or agent appointed by WTE Limited. Servicing outside of the warranty period is at the discretion of WTE Limited. Page 29 of 34... -
Page 30: Product End Of Life
For more information about where you can drop off your waste equipment for recycling contact your local dealer or city council Please recycle this device responsibly. Page 30 of 34 © WTE Limited, 2021 – Christchurch New Zealand... -
Page 31: Product Warranty
The MReX-MB1 can be damaged through improper handling and system integration. ESD handling precautions must be observed. Use in any system or product without the inclusion of ESD or over voltage devices or exposure to any condition outside the operating limits of the MReX-MB1 will invalidate the warranty. -
Page 32: Specification
• Field upgradable. Physical Dimensions: (L x W x H) • 102mm x 51mm x 28mm Serial Output: • Serial 9600:8-N-1 baud, 3.3V TTL. • WTE protocol format. Page 32 of 34 © WTE Limited, 2021 – Christchurch New Zealand... - Page 33 AS/NZ 4769 Laboratory Test Results • Base and mobile station compliant. Testing completed March 2020. This product incorporates the WTE MReX-460 Telemetry Transceiver Module, upon which compliance is based. Page 33 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
- Page 34 MReX-MB1 Transmitter User Manual v3.16 Firmware Page 34 of 34 © WTE Limited, 2021 – Christchurch New Zealand...
