S&S Precision NavBoard ZipFlip User Instructions

END USER INSTRUCTIONS - READ BEFORE USE
PRODUCT NAME:
NavBoard
ADD-ON ACCESSORIES
ATTACHING CHEST HARNESS SYSTEM -
Neck and chest straps
1
come with 4 split buckle
attachments.
ATTACHING PTT WING TO ZIPFLIP™ -
HOOK SIDE
LOOP SIDE
PAGE 1 OF 2
COMPATIBLE WITH S&S PRECISION PLATEFRAME™, PF-M™, PF-R™, STANDARD MOLLE/PALS WEBBING SYSTEMS, AND PARACHUTE HARNESS STRAP
ZipFlip™ & FlipLite™
®
sold separately
BACK VIEW
NECK STRAP LOOPS
CHEST
STRAP
LOOPS
Locate 4 loops on the back
2
of the ZipFlip Pouch. Top 2
connect the neck strap and
the bottom 2 connect the
chest strap.
PART NUMBER: PFA-PTTW001
Locate Velcro pocket on
1
the back of the ZipFlip™.
Slide the first half of the TIP:
3
split buckle into the top squeeze loop if more pressure
loop. Squeeze the loop to is needed.
fit over the other side of
the split buckle. Repeat
with other 3 straps.
With the LOOP SIDE facing
2
upwards, push the PTT
Wings through the Velcro
pocket.
PART NUMBER:
NB-ZF01XX
NB-FL01XX
use small screwdriver to
4
BACK VIEW
3
FRONT VIEW
©2022 S&S Precision, LLC | 02112022
Attach strap buckles to
split buckles and adjust
to fit.
Secure the PTT
and cables with
integrated bungee.
