Summary of Contents for S&S Precision LIFTR Series
- Page 1 LIFTR™ MODULAR FLOTATION LIFTR™ SPECIFICATIONS, CARRIER ATTACHMENT AND DRAEGER REBREATHER INSTRUCTIONS...
- Page 2 LIFTR™ SPECIFICATIONS...
- Page 3 LiftR-40 Modular Flotation The LiftR-40 is intended to be used in surface and subsurface operations. The LiftR-40 is attached to existing combat equipment by slipping it on and over the shoulder straps and cummerbund of the operator’s plate carrier. The LiftR-40 is self-packing and modular to fit most brand’s plate carriers.
- Page 4 LiftR-40 Modular Flotation Oral Inflation Tube CO2 Actuator Capped = Manual Inflation Uncapped = Automatic Inflation Manual Air Dump/ Over Inflation Valve Actuator Pull Handle Sensitive Business Document. Proprietary to S&S Precision...
- Page 5 LiftR-40 Attachments Harness Attachment System Expedient Attachment System Sensitive Business Document. Proprietary to S&S Precision...
- Page 6 LiftR-40 Attachments Plate Frame Attachment System Dräger Plate Frame Attachment System Sensitive Business Document. Proprietary to S&S Precision...
- Page 7 LiftR-40 with Alternative Plate Carriers Fits most brands’ plate carriers LBT 6094 CRYE PRECISION AVS CRYE PRECISION JPC Sensitive Business Document. Proprietary to S&S Precision...
- Page 8 LiftR-40 Collar Measurements 5” 8” 4” 29” 2.5” 4” 57” total length 2.3 lbs with cartridge Sensitive Business Document. Proprietary to S&S Precision...
- Page 9 LiftR-40 General Materials and Components Materials Acetal Nexcel Nexlon Nylon 6/6 Elastomeric Resin Components • Slide Corrosion Resistant Zippers & Zipper Slide • 1” Nylon Webbing 5000 Series • Nylon Velcro Loop and Hook • Oral Valve Halkey • 3/8” Detonator •...
- Page 10 PF-M™ INSTRUCTIONS...
- Page 11 LiftR 40™ Attachment Instructions - PF-M™ (LR-0001BK) Step 1: LiftR 40™ Male Tri-glide Attachment Instructions The LiftR™ comes with a set of male and female tri-glides which should be attached to the back of the LiftR™ and to the back of the carrier first before attaching the LiftR™...
- Page 12 LiftR 40™ Attachment Instructions - PF-M™ (LR-0001BK) READ BEFORE USE The LiftR™ is an inflatable flotation system used in surface and subsurface operations, providing the appropriate amount of lift necessary to bring a diver/swimmer to the surface and float them in a face-up orientation.
-
Page 13: Attachment Instructions
LBT 6094 CARRIER ATTACHMENT INSTRUCTIONS... - Page 14 LiftR 40™ Attachment Instructions - LBT 6094 (LR-0001BK) Step 1: LiftR 40™ Male Buckle Attachment Instructions The LiftR™ comes with a set of male and female buckles which should be attached to the back of the LiftR™ and to the back of the carrier fi rst before attaching the LiftR™...
- Page 15 LiftR 40™ Attachment Instructions - LBT 6094 (LR-0001BK) Step 2: LiftR 40™ LBT 6094 Attachment Instructions The LiftR™ is an infl atable fl otation system used in surface and subsurface operations, providing the appropriate amount of lift necessary to bring a diver/swimmer to the surface and fl oat them in a face-up orientation.
- Page 16 CRYE PRECISION AVS CARRIER ATTACHMENT INSTRUCTIONS...
- Page 17 LiftR 40™ Attachment Instructions - Crye PrecisionAVS (LR-0001BK) Step 1: LiftR 40™ Male Tri-glide Attachment Instructions The LiftR™ comes with a set of male and female tri-glides which should be attached to the back of the LiftR™ and to the back of the carrier fi rst before attaching the LiftR™...
- Page 18 LiftR 40™ Attachment Instructions - Crye PrecisionAVS (LR-0001BK) READ BEFORE USE The LiftR™ is an infl atable fl otation system used in surface and subsurface operations, providing the appropriate amount of lift necessary to bring a diver/swimmer to the surface and fl oat them in a face-up orientation.
- Page 19 CRYE PRECISION JPC CARRIER ATTACHMENT INSTRUCTIONS...
- Page 20 LiftR 40™ Attachment Instructions - Crye PrecisionJPC (LR-0001BK) Step 1: LiftR 40™ Male Tri-glide Attachment Instructions The LiftR™ comes with a set of male and female tri-glides which should be attached to the back of the LiftR™ and to the back of the carrier fi rst before attaching the LiftR™...
- Page 21 LiftR 40™ Attachment Instructions - Crye PrecisionJPC (LR-0001BK) READ BEFORE USE The LiftR™ is an infl atable fl otation system used in surface and subsurface operations, providing the appropriate amount of lift necessary to bring a diver/swimmer to the surface and fl oat them in a face-up orientation.
- Page 22 DRAEGER REBREATHER ATTACHMENT SYSTEM INSTRUCTIONS...
- Page 23 Rebreather Attachment System READ BEFORE USE 5.) Place female release buckle of the 1.) Lay out the Rebreather attachment 2.) Weave PlateFrame shoulder 3.) Weave rear shoulder strap through 4.) Once shoulder strap is through straps Rebreather shoulder attachment and straps through LiftR-40.
