Kidde Fire Systems Natura Owner's Manual

Inert gas fire suppression system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P/N 06-237620-001
June 2020, Rev. AB
Kidde Fire Systems
Natura™ Inert Gas
Fire Suppression System
Owner's Manual
with FM Approval and UL Listing
EXPORT INFORMATION (USA)
EXPORT INFORMATION (USA)
Jurisdiction: EAR
Jurisdiction: EAR
US ECCN: EAR99
US ECCN: EAR99
This document contains technical
This document contains technical
data subject to the EAR
data subject to the EAR

Advertisement

Table of Contents
loading

Related Manuals for Kidde Fire Systems Natura

Summary of Contents for Kidde Fire Systems Natura

  • Page 1 P/N 06-237620-001 June 2020, Rev. AB Kidde Fire Systems Natura™ Inert Gas Fire Suppression System Owner’s Manual with FM Approval and UL Listing EXPORT INFORMATION (USA) EXPORT INFORMATION (USA) Jurisdiction: EAR Jurisdiction: EAR US ECCN: EAR99 US ECCN: EAR99 This document contains technical...
  • Page 3 Fire Systems believes this data to be accurate, but it is published and presented without any guarantee or warranty whatsoever. Kidde Fire Systems disclaims any liability for any use that may be made of the data and information contained herein by any and all other parties.
  • Page 4 ATTENTION INSTALLERS This form must be signed by the system owner indicating that he/she has received a copy of this Owner’s Manual, P/N: 06-237620-001. Have the system installer fill in this form. Retain a copy of this form for your records.

  • Page 5: Safety Summary

    Hard copies of the Safety Data Sheets (SDS) are not included with this manual. The latest version of the SDS can also be found online at the Kidde Fire Systems website (www.kiddefiresystems.com). Use the built-in navigation links to view the desired sheet.
  • Page 6 THIS PAGE INTENTIONALLY LEFT BLANK. June 2020 P/N 06-237620-001...

  • Page 7: Table Of Contents

    Main and Reserve Systems..............2-3 Maintenance Procedures ............... 2-4 2-6.1 Preventative Maintenance Schedule ............2-4 Weekly ....................2-6 2-7.1 Check Natura IGS System Cylinder Pressure..........2-6 2-7.2 Check Nitrogen Pilot Cylinder Pressure ............ 2-6 2-7.3 Hazard and Enclosure Inspection............2-6 2-7.4 Pipework and Controls Inspection............

  • Page 8: Table Of Contents

    TABLE OF CONTENTS (CONT.) 2-8.3 Inspect Hoses ..................2-7 2-8.4 Inspect Release Units and Slave Gauge Assemblies ........2-7 2-8.5 Inspect Cylinder and Valve Assembly............2-7 2-8.6 Inspect Electric Control Heads on Nitrogen Pilot Cylinders......2-7 2-8.6.1 Inspect Brackets, Straps, Cradles and Mounting Hardware......2-7 2-8.7 Semi-Annual and Other Inspections............

  • Page 9: Chapter 1 General Information

    General Information CHAPTER 1 GENERAL INFORMATION INTRODUCTION This document is provided to instruct and familiarize the owner with the Kidde Fire Systems ™ Natura Inert Gas Fire Suppression System (Natura IGS system) with IG-100, IG-541, IG-55, or IG-01 or IG-55 (herein refer to collectively as the “Agent”). This manual covers: •...

  • Page 10: Safe Cylinder Handling Procedures

    Before handling Natura IGS products, all personnel must be trained in the safe handling of the containers as well as in the proper procedures for installation, removal, filling, and connection of other critical devices, such as flex hoses;...

  • Page 11: About The System

    Natura IGS agents are used at relatively high concentrations to extinguish fires, typically in the range of 40 to 50% agent in air, or more. At a Natura IGS agent concentration of 45%, the residual oxygen concentration is 11.5%, compared with 21% in normal air. The principal health risk from exposure to atmospheres having such low oxygen concentrations is "hypoxia,"...
  • Page 12 Note: The term "…sea level equivalent of oxygen…," used above, deserves some clarification. The allowed exposure limit to air diluted with Natura IGS agents relates to the residual oxygen concentration. At sea level the atmospheric pressure is 14.7 psi (101,325 Pa).

  • Page 13: 1-4.2 Ig-100 (Nitrogen)

    General Information 1-4.2 IG-100 Nitrogen) Natura IGS systems with IG-100 are fixed fire extinguishing systems that use the inert gas Nitrogen, UN number 1066. The purity of the Nitrogen shall be as follows: • Nitrogen greater than or equal to 99.7%.
  • Page 14 General Information Figure 1-3. IG-100 Pressure/Temperature Curve Isometric Diagram for 300 bar, U.S. Customary Units Figure 1-4. IG-100 Pressure/Temperature Curve Isometric Diagram for 300 bar, SI Units June 2020 P/N 06-237620-001...

  • Page 15: Ig541 (Nitrogen, Argon, And Carbon Dioxide)

    1-4.3 IG541 (Nitrogen, Argon, and Carbon Dioxide) Natura IGS systems with IG-541 are fixed fire extinguishing systems that use an inert gaseous mixture of 52% Nitrogen, 40% Argon, and 8% Carbon Dioxide (IG-541), UN number 1956. Specification for IG-541 is a Nitrogen/Argon/Carbon Dioxide 52%/40%/8% ratio by volume.
  • Page 16 General Information Figure 1-6. IG-541 Pressure/Temperature Curve Isometric Diagram for 200 bar, SI Units Figure 1-7. IG-541 Pressure/Temperature Curve Isometric Diagram for 300 bar, U.S. Customary Units June 2020 P/N 06-237620-001...
  • Page 17 General Information Figure 1-8. IG-541 Pressure/Temperature Curve Isometric Diagram for 300 bar, SI Units P/N 06-237620-001 June 2020...

  • Page 18: 1-4.4 Ig-55 (Nitrogen And Argon)

    General Information 1-4.4 IG-55 (Nitrogen and Argon) Natura IGS systems with IG-55 are fixed fire extinguishing systems that use an inert, gaseous ® mixture of 50% Nitrogen and 50% Argon known as Argonite , UN number of 1956. Specification for IG-55 is an Argon/Nitrogen 50%/50% ratio by volume. Tolerance of mixture in air is as follows: •...
  • Page 19 General Information Figure 1-10. IG-55 Pressure/Temperature Curve Isometric Diagram for 200 bar, SI Units Figure 1-11. IG-55 Pressure/Temperature Curve Isometric Diagram for 300 bar, U.S. Customary Units P/N 06-237620-001 1-11 June 2020...
  • Page 20 General Information Figure 1-12. IG-55 Pressure/Temperature Curve Isometric Diagram for 300 bar, SI Units June 2020 1-12 P/N 06-237620-001...

  • Page 21: Argon)

    1-4.5 IG-01 Argon) Natura IGS systems with IG-01 are fixed fire extinguishing systems that use the inert gas Ar- gon, UN number 1006. The purity of the Argon shall be as follows: • Argon greater than or equal to 99.99% •...
  • Page 22 General Information Figure 1-15. IG-01 Pressure/Temperature Curve Isometric Diagram for 300 bar, U.S. Customary Units Figure 1-16. IG-01 Pressure/Temperature Curve Isometric Diagram for 300 bar, SI Units June 2020 1-14 P/N 06-237620-001...

  • Page 23: Chapter 2 Installation And Maintenance

    If the system has a control panel, refer to the appropriate control panel manual, as applicable. INSTALLATION The Natura IGS must be installed only by an authorized Kidde Fire Systems distributor. The system must be installed using genuine Kidde Fire Systems components and installation materials in accordance with the Natura IGS DIOM, P/N 06-237619-001.

  • Page 24: Agent Storage Cylinders

    3. Attach the handle to nut on the selector valve, and turn the valve open. 1. Proceed to appropriate Natura IGS master cylinder release unit for the hazard. 2. Remove the safety pull pin from the cylinder release unit. This will also break the tamper proof seal.

  • Page 25: Post-Fire Operation

    4. Immediately contact a Kidde Fire Systems distributor for service. If the system is not equipped with reserve cylinders, contact an Authorized Kidde Fire Systems Distributor for refilling or replacement of the cylinders. Until the cylinders are refilled and installed, arrange for fire watch to protect the hazard during this time.

  • Page 26: Maintenance Procedures

    C-1, C-6 and P-1. CGA pamphlets my be obtained from the Compressed Gas Association website: http://www.cganet.com. A program of systematic maintenance is essential for continuous, proper operation of all Natura IGS Systems. Follow a periodic maintenance schedule as outlined in Table 2-1. Additionally, have an Authorized Natura IGS Systems Distributor perform preventative maintenance as outlined in Table 2-2.
  • Page 27 Installation and Maintenance Have an Authorized Kidde Fire Systems Natura IGS Systems Distributor, perform periodic preventative maintenance per Table 2-2. Table 2-2. Authorized Kidde Fire Systems Distributor Preventive Maintenance Schedule Schedule Requirement Semi-Annual Perform Monthly inspection and the following additional tasks:...

  • Page 28: Weekly

    2-7.1 Check Natura IGS System Cylinder Pressure Check the Natura IGS System cylinder pressure gauges for proper operating pressure (refer to Section 1-4). If the pressure gauge indicates a pressure loss (adjusted for temperature) of more than 5%, contact an Authorized Kidde Fire Systems Distributor to have the cylinder replaced.

  • Page 29: 2-8.1.3 Inspect Pressure Switches

    Inspect actuation and discharge hoses for loose fittings, damaged threads, cracks, distortion, cuts, dirt, and frayed wire braid. Inspect the adapters, couplings and tees at the Natura IGS cylinder pilot outlets for tightness. Contact an Authorized Kidde Fire Systems Distributor if replacements or repairs are needed.
  • Page 30 Installation and Maintenance ADDITIONAL REQUIREMENTS Portable fire extinguishers are required in addition to the Natura IGS systems and for areas not protected by the system. Consult with the insurance carrier, local Authorities Having Jurisdiction, and the portable fire extinguisher distributor for sizes, types, spacing and location requirements.
  • Page 32 KIDDE-FENWAL, INC. assumes no re- sponsibility for the product's suitability for a particular application. The fire suppression system design, installation, maintenance, service and troubleshooting must be performed by trained, authorized Kidde Fire Systems distributors 400 Main Street for the product to work correctly.
