Enabling Devices Peek-a-Boo 7508M User Manual page 2

Our Most Popular Adapted Therapeutic Toys Now Available On Mounts!
For the child who needs special visual placement, we've selected some of our most
popular adapted toys and created a system that allows you to easily mount them on a
wheelchair, tabletop, bedrail or tray. Purchase any of the four mountable toys with or
without the mounting arm. Size: 8 "L x 9 ¾ "W. Requires 6AA Batteries. Mounting
arm is adjustable up to 24".
1. The Peek-a-Boo Mirror requires 6 AA batteries (Not included). Alkaline
batteries are required. Do not use heavy duty or rechargeable batteries because
they supply lower voltage and the unit may not perform as well.
2. The battery compartments are located on the back of the unit. To remove the
battery compartment covers, unscrew the small Phillips Head screws then slide
the covers off. Install new batteries, being careful to observe proper (+) & (-)
battery polarity. Replace covers and screw.
3. Clamping Options: Our mounting clamp is designed for mounting to tubular
(wheelchair, bedrail, walker, etc.) or flat surfaces such as a table top or desk. For
flat surface mounting use the included wedge insert shoe stored in front of the
locking knob on the clamp (see Fig.1) Loosen locking knob slightly to remove
wedge, tighten knob once wedge has been removed.
Fig.1
4. At this point we recommend you place your mounting arm without the Peek-a-
Boo Mirror and do a rough setup, you can fine tune your adjustments after you
have placed the Peek-a-Boo Mirror on the arm. Do not force or try adjusting the
5. arm without first loosening the set knobs for that portion of the arm. Each
section of the arm has a set knob. Once you have the arm in the desired position
you can tighten the knobs to lock the arm in place.
6. Once the arm is in position you can now place your Peek-a-Boo Mirror on the
arm. First back off the set knob on the Peek-a-Boo Mirror until it is flush with
the inside of the opening. This is necessary to allow the holder to be pushed all
the way down on the mounting arm post. The post at the end of the arm also has
a flat spot, which needs to be lined up with the set screw on the Peek-a-Boo
Mirror's base. Once this is done you can tighten the set knob to lock the holder
to the arm. Please Note: Make sure to back the set screw enough to allow the
holder to be pushed all the way down on the post of the arm, failure to do so will
cause the Peek-a-Boo Mirror to fall off the mounting arm and a fall could cause
damage to your Peek-a-Boo Mirror. (See Fig. 2).
7. You can place the Bead Chain flat on a lapboard or tabletop by first removing
the mounting hub on the back of the unit. Simply remove the two Phillips head
screws holding the hub in place and lift off.
Tighten Set
Knob
Fig. 2
Rev 7/16/12
