Coby Electronics Corp.
56-65 Rust Street
Maspeth, NY 11378
www.cobyusa.com
www.ecoby.com
USER'S MANUAL
DIGITAL AUDIO PLAYER W/ VOICE RECORDER
Please read manual before operation
Customer Service Hours
Monday-Friday 8:00 AM - 11:00 PM EST, 1-800-681-2629 or 718-416-3197
Monday-Friday 6:30 PM - 11:00 PM EST, 1-800-727-3592
Saturday-Sunday 9:00 AM - 11:00 PM EST, 1-800-727-3592
Or Send E-Mail to: Customerservice@cobyusa.com / techsupport@cobyusa.com
MPC541
Advertisement
Table of Contents
Related Manuals for Coby MPC541
Summary of Contents for Coby MPC541
- Page 1 Please read manual before operation Customer Service Hours Monday-Friday 8:00 AM - 11:00 PM EST, 1-800-681-2629 or 718-416-3197 Monday-Friday 6:30 PM - 11:00 PM EST, 1-800-727-3592 Saturday-Sunday 9:00 AM - 11:00 PM EST, 1-800-727-3592 Or Send E-Mail to: Customerservice@cobyusa.com / techsupport@cobyusa.com MPC541...
-
Page 2: Table Of Contents
Contents Getting Started Features ... Accessory... Safty Instructions ... Installing a battery ... Location of Control ... LCD Display ... MENU Table ... Connection to Computer USB Driver Installation ... Connecting the player to PC ... Downloading/ Uploading files ... Disconnection the USB ... -
Page 3: Features
128 MB Built-in Flash Memory MP3, WMA Playback Removable Storage Device (Music, Data and Pictures) Plug and Play (No installation software require for MP3 Player User's Manual Window 2000 / Window ME / Window XP) Voice Recording up to 9 Hours... -
Page 4: Safty Instructions
Safety Instructions 1. Do not expose the unit to high temperature or humidity. 2. Do not subject the unit to severe impact, or place heavy objects on it. 3. Do not use strong detergent or solvent to clean the unit. 4. -
Page 5: Location Of Control
Location of Control VOLUME + VOLUME - MENU POWER ON/OFF /ENTER Phone jack Neck Strap Hook USB Port Display PLAY/ REC/A-B PAUSE Button F.FWD STOP Hold Battery Compartment/ (SD/MMC Card Compartment) LCD Display Current T rack File T ype EQ Indicator Voice File Music File 020 NORM... -
Page 6: Menu Table
MENU T able Music Voice Play list MENU SD/MMC Card (Music) (Recording) EQ- Normal, Classic, Live, Pop, Rock Repeat Mode- Normal, One, All, Intro, Random Display- ID3 Tag, Lyric, Contrast, B-light Time, Auto Off- 30 Sec, 1 Min, 2 Min, 3 Min Recording- 1. -
Page 7: Connecting The Player To Pc
Connecting to PC Connecting the player to PC: 1. Make sure the player is turned off. 2. Connect the player with your computer by supplied USB cable. 3. PC will automatically detect the player as removable disk under MY COMPUTER. 4. -
Page 8: Power On/ Off
Power On/ Off Hold Function: Hold Off: Set the HOLD switch to opposite direction of arrow symbol to operate the player. Hold On: Slide HOLD switch to the arrow direction to disable all the functions. The screen displays hold symbol: 020 NORM HOLD KBPS... -
Page 9: Playing Music
Playing Music Playing Music using MSC Menu 1. Enter the MSC menu. 2. Press the joystick up for music playback. Adjust Tracks Press joystick to right to play next track and left move to and play previous track. Press and hold joystick right to move fast forward . -
Page 10: Searching For Music/ Voice Files
Searching for Music/ Voice files To search desired file using NAV menu 1. Enter NAV menu. 2. Select desired submenu from MUSIC/ VOICE/ PLAYLIST SD/MMC Card MUSIC : MP3 and WMA music files VOICE : Recorded voice files PLAYLIST : Playlist file SD/MMC Card: Files on SD/MMCcard. -
Page 11: Play/ Repeat Mode
Play/ Repeat Mode To setup Repeat mode using Main menu 1. Get to the "Repeat Mode" submenu by below steps. Main menu SYS menu 2. Press joystick to enter "Repeat Mode" 3. Press the joystick left/right play mode and press it to confirm. 4. -
Page 12: Delete/Format
"NO" and press joystick to confirm. It will skip to the next file. Formating Note: When formatting MMC Card, use this MP3 player to format, not with PC. Formating 1. Follow below steps to get to the "Format " submenu. -
Page 13: F/W Upgrade
F/W Upgrade Downloading F/W Upgrade When you upgrade firmware, make sure to use new battery because it take large amount of power when upgrading. If battery run out of power during upgrading, flash memory will get damaged. 1. Make sure the player is turned off. 2. -
Page 14: Specifications
Specification Power --------------------------------------------------------1xAAA Battery Memory-----------------------------------------------------------------128MB Size(WXHXD)-----------------------------------------------2.2"x2.87"x0.82" Interface---------------------------------------------------------USB Rev.1.1 Display-------------------------------------128x64 dots Dot-Matrix LCD Processor---------------------------------------------------------65MIPS DSP Audio Playback---------------------------------------------MP3 decode Voice Recording-----------------------------IMA-ADPCM encoding 9 hours recording Signal to Noise Ratio------------------------------------------------90dB Frequency Response---------------------------------------20Hz~20KHz Output------------------------------------------------>5mW(each output) Distortion Output-----------------------------------------------0.01%~0.1% Ports--------------------------------------------------------------------------USB WMA Format-----------------------------------------------------8-192Kbps MP3 Format--------------------------Bit Rate: 32 - 320Kbps,Optional SD/MMC Card--------------------------------------------Max size 512MB...
