- Page 1 Master Programming Manual for Sanitizer Plus Models Effective February 2019...
- Page 2 Button appearance and position may be different than actual valve Cycle times, sequences, and settings in this guide are only examples of how your system may be programmed. Actual settings are determined by the manufacturer. Please contact them if more information is needed. Important button sequences to note: –...
-
Page 3: Service Alarm
Installer/User Screens Accessed by pressing and holding simultaneously for three seconds. NEXT Returns to general display after five minutes of inactivity. Set water hardness with + or — buttons WATER HARDNESS Adjustable from 1-150 grains, within limits determined by capacity settings as to not override gallons capacity setting. Default setting is 20 grains. -
Page 4: Call For Service
Service Alarm Settings Accessed by pressing and holding buttons simultaneously for three seconds on the REGEN TIME HOUR screen. CLOCK Returns to general display after five minutes of inactivity. The service alarm feature is used to warn Turn service alarm by gallons ON or OFF with + or — buttons SERVICE ALARM the owner that the unit currently needs Default setting is OFF. -
Page 5: Set Cycle
Service/OEM SOFTENING Screens – Accessed by pressing and holding simultaneously for three seconds. NEXT Returns to general display after five minutes of inactivity. Select SOFTENING or FILTERING with + or — buttons SOFTENING TYPE If you have selected FILTERING, please refer to “Service/OEM FILTERING screens”, page 7-8. Set system’s grains of capacity with + or —... - Page 6 Service/OEM SOFTENING Screens – Accessed by pressing and holding simultaneously for three seconds. NEXT Returns to general display after five minutes of inactivity. continued from previous page Set fourth cycle position with + or — buttons REGENERANT DRAW DN CYCLE 4 Set draw time with + or —...
- Page 7 Configuration Screens – Accessed by pressing and holding NEXT simultaneously for three seconds. – Once screen changes, press and hold simultaneously again for three seconds. NEXT Select meter size with + or — buttons VALVE TYPE Set to 1”, 1.25”, 1.5”, 2” or 1.0T (for twin units). Upflow brining will not be an option if set to anything other than 1” or 1.0T. With 1.0T set: •Meter calibration will be fixed with a different value for each tank.
- Page 8 Configuration Screens cont’d – Accessed by pressing and holding simultaneously for three seconds. NEXT – Once screen changes, press and hold simultaneously again for three seconds. NEXT continued from previous page Set first relay trigger with + button. Press + to reach desired triggering event. RELAY 1 TRIGGER If not using a relay, make sure OFF is selected and press NEXT.
- Page 9 Configuration Screens cont’d – Accessed by pressing and holding simultaneously for three seconds. NEXT – Once screen changes, press and hold simultaneously again for three seconds. NEXT continued from previous page Set relay trigger with + or — buttons RELAY 1 TRIGGER REGEN GALLONS indicates that relay will be energized after a specified number of gal- REGEN lons are expended during service and regen.
- Page 10 First Level History Screens – Accessed by pressing and holding simultaneously for three seconds. Returns to general display after five minutes of inactivity. Displays number of days since last regen DAYS SINCE REGEN Displays number of gallons since last regen VOLUME SINCE REGEN Displays reserve capacity RESERVE FOR...
- Page 11 First Level History Screens cont’d – Accessed by pressing and holding simultaneously for three seconds. Returns to general display after five minutes of inactivity. continued from previous page Displays peak flow rate history MAX FLOW HISTORY – buttons to scroll through last 7 days to view peak flow rate for that day.
- Page 12 Second Level History Screens – Accessed by pressing simultaneously for three seconds. – Once screen changes, press simultaneously again for three seconds. Non-resettable history. Displays total regens since startup Displays software version SOFTWARE VERSION TOTAL REGENS Displays total gallons used by Displays last ten valve errors that occurred TOTAL GALLONS TOTAL BRINE ERRORS...
- Page 13 Notes...
- Page 14 Notes...
- Page 15 Notes...
- Page 16 1900 Prospect Court • Appleton, WI 54914 Phone: 920-739-9401 • Fax: 920-739-9406 MAN-SAN PL MAST Rev A0219...
