- Page 1 PORTABLE NEBULIZER Model: VocalMist 1st Gen Instruction Manual...
-
Page 2: Table Of Contents
CONTENTS Safety Notes........................... 3 Product Description ........................4 Charging............................7 Assembly And Use ........................8 Use Instructions ..........................9 Cleaning ............................10 Troubleshooting ..........................12 Maintenance And Storage ......................13 Precautions And Warnings ......................14 Symbol Index..........................15 Warranty............................16 Certificate Of Inspection........................ -
Page 3: Safety Notes
The illustrations contained in this user manual are schematic. Safety Notes ♦ VocalMist Portable Nebulizer is for use as a nebulizer only. Do not use this device for any other purpose. ♦ This product should not be used by children or persons with certain disabilities except under correct supervision and guidance. -
Page 4: Product Description
Product Description 1. Product Name: VocalMist Portable Nebulizer 2. Model No: VocalMist 1st Generation 3. Working Principles and Mechanism The working principle of the portable nebulizer is achieved by micro-metal mesh oscillation via the rapid oscillation of the circuit and piezoelectric ceramic transducer chip, which sends the liquid through the metal mesh at tiny particle sizes (3μm). - Page 5 Temperature 5°C ~40°C Working Environment Relative Humidity ≤80%R.H. Non-condensing state Atmospheric pressure (86.0~106.0)kPa Temperature -20°C ~55°C Storage/delivery Environment Relative Humidity ≤80%R.H. Non-condensing state Atmospheric pressure (70.0~106.0)kPa The remaining capacity keeps more than 80% of the initial capacity after 3000 Batteries Life cycles of use The median particle size in this nebulizer is measured with 0.9% physiological saline under conditions of a temperature of 25 ±3°C and a humidity of 60% ±5% R.H.
- Page 6 5. Product Contents Name Name Mouthpiece Saline Cup Mask Nebulizer Body Velvet Bag Spray Nozzle USB Cable Power Switch Warranty Card Slide Switch User Manual “Press” Button Note: Please refer to the configuration list Mini USB Interface 6. Age Restricted Use Applicable to saline nebulization for adults.
-
Page 7: Charging
♦ Do NOT dispose batteries in regular trash to avoid pollution. ♦ Do NOT attempt to dismantle or repair your nebulizer or any of its components. ♦ If your battery needs to be replaced, consult VocalMist LLC for instructions or replacement. Instruction Manual... -
Page 8: Assembly And Use
Prepare: Clean and disinfect all components as needed before use. Insert saline: Open the saline cup by turning the cap counterclockwise. Empty saline vial into the cup and replace the cap. Note: Do NOT fill past the max fill line. Assembly and Use 1) Remove the unit and all accessories from packaging. -
Page 9: Use Instructions
3) Power Supply a. VocalMist Portable Nebulizer does not include a power adapter. Use a regular standard adapter that complies with GB 9706.1-2 007 or IEC 60601-1 : 2012 requirements b. The technical parameters of the power adapter should conform with output DC 5.0V/1.0A c. -
Page 10: Cleaning
4. Your nebulizer will power off automatically after 10 minutes. If you need to continue use, press the Power Button again. Make sure there is enough liquid in the saline cup. 5. After nebulization, press the Power Button to turn off your nebulizer. Remove cap and pour out any leftover liquid and do not reuse. - Page 11 2. TO DISINFECT (as needed) 1. Clean the mouthpiece and mask as instructed above 2. Add 3-6ml of warm water to the saline cup followed by 2-3 drops of white distilled vinegar and nebulize. Do not inhale the vinegar solution. Ensure the mist does not come in contact with surfaces that may be damaged by vinegar.
-
Page 12: Troubleshooting
Troubleshooting Troubleshooting for VocalMist Portable Nebulizer Item Problem Possible cause/solution Device light does 1. Check to see if the nebulizer is charged. not power on 2. Check to see if the liquid cup is filled. 1. Confirm that the cup been filled only with saline. -
Page 13: Maintenance And Storage
“Product Description Section”). 2. Storage Instructions 2. Maintenance Instructions a. Your nebulizer will last for 5 years if stored VocalMist works best under the listed Normal as indicated. Working Conditions b. Your nebulizer should be promptly cleaned a. Keep your nebulizer away from any open and disinfected after each use. -
Page 14: Precautions And Warnings
♦ Refer to “Troubleshooting Section” if you experience any malfunctions or issues. Do not attempt to repair the device. Contact VocalMist LLC if you continue to experience problems. ♦ Completely dry the saline cup and accessories after each use. - Page 15 ♦ Do not use a microwave oven to dry or disinfect the unit; this may cause fire. ♦ Keep your VocalMist out of reach of children and infants. ♦ Do not touch the metal disk in the saline nozzle with hands or any sharp objects as this may cause damage.
-
Page 16: Symbol Index
6 months from the date of purchase when used in accordance with the instructions provided with the device. VocalMist LLC will, at our option, repair or replace without charge. Any repair service out of the scope of warranty will be charged accordingly. -
Page 17: Certificate Of Inspection
Certificate of Inspection Feellife Medical Inc. Product: Portable mesh nebulizer Model: mini Air 360 Inspection date: Inspector: Instruction Manual PAGE... - Page 18 PORTABLE NEBULIZER Model: VocalMist 1st Gen...
