Dyon LIVE 43 PRO X Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Content
1
Important Safety Instructions ................................................................ 2
2
Support Information .............................................................................. 7
3
Appropriate use .................................................................................... 8
4
Notes on energy efficiency .................................................................... 9
5
Conformity .......................................................................................... 11
6
Montage ............................................................................................. 12
6.1
Stand mounting ......................................................................................... 12
6.2
Wall mounting ........................................................................................... 13
7
Controls and connections ................................................................... 14
7.1
The Device ................................................................................................ 14
7.2
Connections .............................................................................................. 15
7.3
CI/CI+ Slot ................................................................................................ 16
7.4
Remote Key Function ............................................................................... 18
7.5
Antenna Connection ................................................................................. 20
8
Initial setup ......................................................................................... 22
8.1
Basic Settings ........................................................................................... 22
8.2
Channel Search ........................................................................................ 23
9
Menu-Settings .................................................................................... 27
9.1
Channel Menu .......................................................................................... 27
9.2
Picture Menu ............................................................................................. 32
9.3
Sound Menu ............................................................................................. 34
9.4
Time Menu ................................................................................................ 35
9.5
Lock Menu ................................................................................................ 36
9.6
Setup Menu .............................................................................................. 37
10 Hotel Mode ......................................................................................... 40
11 EPG (Electronic Program Guide) ........................................................ 42
12 CI+ Information ................................................................................... 43
13 TELETEXT ......................................................................................... 45
14 Selecting the Source........................................................................... 46
15 USB Devices ...................................................................................... 47
15.1 Connect USB Device ................................................................................ 47
15.2 Photo Playback ......................................................................................... 48
15.3 Music Playback ......................................................................................... 49
15.4 Video Playback ......................................................................................... 49
16 Troubleshooting .................................................................................. 50
16.1 No sound /No Picture................................................................................ 50
16.2 Error Notes................................................................................................ 51
17 Specifications ..................................................................................... 53
18 Glossar ............................................................................................... 56
19 Warranty Condition ............................................................................. 57
DYON LIVE 43 PRO X
V1.0.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIVE 43 PRO X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dyon LIVE 43 PRO X

Summary of Contents for Dyon LIVE 43 PRO X

  • Page 1: Table Of Contents

    DYON LIVE 43 PRO X V1.0.0 Content Important Safety Instructions ..............2 Support Information ................7 Appropriate use ..................8 Notes on energy efficiency ..............9 Conformity ..................11 Montage ..................... 12 Stand mounting ..................12 Wall mounting ................... 13 Controls and connections ..............

  • Page 2: Important Safety Instructions

    DYON LIVE 43 PRO X Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings, install in accordance with the instructions.
  • Page 3 DYON LIVE 43 PRO X 13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 4 DYON LIVE 43 PRO X The symbol indicates that dangerous voltages constituting a risk of electric shock are present within this unit. The symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. Warning High voltages are used in the operation of this television receiver.
  • Page 5 DYON LIVE 43 PRO X Caution Do not trap the power supply cord under the television. Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall.
  • Page 6 DYON LIVE 43 PRO X Tips regarding environmental protection At the end of its operating life, this product may not be disposed of by way of your normal household waste. Instead it must be delivered to a collection point for recycling electrical and electronic equipment.

  • Page 7: Support Information

    DYON LIVE 43 PRO X Support Information URL: https://www.dyonhilfe.de See our website for the latest information on this device, on other products by our company and on our company itself. If you have questions or problems, please read the FAQs on our website or contact our customer support service.

  • Page 8: Appropriate Use

    Moreover, it will result in the immediate loss of guarantee. The manufacturer does not bear any liability for damages caused due to improper use. Enjoy more high definition channels with DYON TV!

  • Page 9: Notes On Energy Efficiency

    DYON LIVE 43 PRO X Notes on energy efficiency The device has facilities for reducing the energy requirement. Make the appropriate settings as required. Tune mode During initial installation and via the menu: MENU button – Setup - Environment Adapted illuminance for home use.
  • Page 10 DYON LIVE 43 PRO X Important! The device switches to standby mode independently after 4 hours without operations. Please note, this is NOT a defect. It is a legal requirement. A note occurs shortly before the device turn in the off- mode.

  • Page 11: Conformity

    DYON LIVE 43 PRO X Conformity We, Axdia International GmbH, hereby declare that this device corresponds to the basic requirements and relevant regulations outlined in guidelines 2014/53/EU, 2011/65/EU, 2014/30/EU, 2014/35/EU and 2009/125/EC. The CE declaration of conformity for this product may be found on the following link: https://www.dyonhilfe.de/konform...

  • Page 12: Montage

    DYON LIVE 43 PRO X Montage 6.1 Stand mounting Fix the feet in the device as described in the picture and fix them with the enclosed mounting screws...

  • Page 13: Wall Mounting

    DYON LIVE 43 PRO X 6.2 Wall mounting Fasten your wall bracket to the threads on the back and observe the hole spacing.

  • Page 14: Controls And Connections

    DYON LIVE 43 PRO X Controls and connections 7.1 The Device Remote Sensor and Status indicator In Standby Mode, the status indicator lights up red.

  • Page 15: Connections

    DYON LIVE 43 PRO X 7.2 Connections 1. AV-IN 6. HDMI 2 2. COAXIAL 7. USB 2.0 3. LNB IN (Satellite) 8. Earphone output 4. RF(C/T2) DVB-C/-T2 9. CI Input Antenna connection 5. HDMI 1 (ARC)

  • Page 16: Ci/Ci+ Slot

    DYON LIVE 43 PRO X 7.3 CI/CI+ Slot Note according the CI Slot Please take care to insert the CI-Module (CAM) in the correct way. The Top side of the module must face against the wall behind. This device is equipped with a CI+ slot for use with CAM modules and Smart cards which allow for the viewing of encrypted Pay-TV channels.
  • Page 17 DYON LIVE 43 PRO X   Please note Module and Smart card are not including. Install the CI+ module after the channel scan has been accomplished and all other settings have been set. The activation of the card may take several minutes for the first time it is used.

  • Page 18: Remote Key Function

    DYON LIVE 43 PRO X 7.4 Remote Key Function POWER: Standby turn on and off / Play/pause with media playback : Stop the playback and return to file list MUTE: Mute sound SLEEP: Turn on/off and change sleep timer ASPECT: Change aspect ratio AUDIO: Select TV audio mode TV/R.: Select TV or Radio...
  • Page 19 DYON LIVE 43 PRO X Notes on batteries If the remote control is not used for a long period of time, please remove the battery from the compartment. Do not heat batteries or dispose of them in fires. Do not dismantle, deform or modify batteries.

  • Page 20: Antenna Connection

    DYON LIVE 43 PRO X 7.5 Antenna Connection Connection for DVB-T2 reception or cable TV Connect the signal cable (e.g. the antenna cable) to the antenna input (RF) on the back of the device. After connection, switch on the device. Perform the initial installation or press SOURCE, select DVB-T/C and perform the station search.
  • Page 21 DYON LIVE 43 PRO X Connection to the satellite receiver Connect the signal cable to the LNB IN input on the rear panel. After connection, switch on the device. Perform the initial installation or press SOURCE, select SATELLITE and perform...

  • Page 22: Initial Setup

    DYON LIVE 43 PRO X Initial setup Note Before you proceed, please make sure that the receiver/antenna cable is connected. 8.1 Basic Settings This screen is only displayed, when the TV is turned on for the first time or reset to the factory default setting.

  • Page 23: Channel Search

    DYON LIVE 43 PRO X 8.2 Channel Search Note If you receive television for private use, DTV is usually the right choice for the type of reception. Then select the reception mode available to you. Other settings are usually not necessary.
  • Page 24 DYON LIVE 43 PRO X Digital Type Then select the reception path depending on how TV channels are received by you. If you want to watch cable television, please select the DVB-C option for RECEPTION DVB-C (Cable WAY using the arrow keys.
  • Page 25 DYON LIVE 43 PRO X For TV reception via a satellite dish on the roof, please select the option Satellite using the arrow keys for RECEIPTION PATH. Further settings are usually not necessary. Satellit Confirm with OK to start the channel search.
  • Page 26 DYON LIVE 43 PRO X ATTENTION! Press the EXIT or MENU button to cancel the channel scan. Please note that if you cancel, no stations may be stored and therefore no station picture is displayed. FIRST AID! No station is displayed after the initial installation Check that the antenna cable is correctly connected to both the junction box and the device.

  • Page 27: Menu-Settings

    DYON LIVE 43 PRO X Menu-Settings Press the MENU button and / to select the page. Press / to select the setting. 9.1 Channel Menu Note After the initial installation, only stations of the currently selected receiver source can be edited here.
  • Page 28 DYON LIVE 43 PRO X Auto Tuning Press the MENU button and 2x the OK button. Tuning Setup  UK Country DTV + ATV  Tune Type DVB-T Digital Type Scan Type Full Network ID Auto Frequency Auto Symbolrate Auto...
  • Page 29 DYON LIVE 43 PRO X Note All stored channels will be erased and overwritten during automatic channel search. After the automatic channel search, the first channel is displayed. If no signal is received for 15 minutes, the TV automatically enters the sleep mode.
  • Page 30 DYON LIVE 43 PRO X Edit Programs You can delete, move, skip, or add channels to your favorites. First, change to the reception mode DVB-T/C or Satellite, in which you want to edit the channel list and sort channels. Press the MENU button on the remote control.
  • Page 31 DYON LIVE 43 PRO X Signalinformation Use the /buttons to select the menu item Signal Information. To get signal information, press OK to confirm. Press the MENU button to return to the previous menu. Press the EXIT key to exit the menu.

  • Page 32: Picture Menu

    DYON LIVE 43 PRO X 9.2 Picture Menu You can adjust picture effect here, such as contrast, brightness, etc. (just if in picture mode personal has been selected) Press / to select the setting, press / to change the setting and press the OK button to confirm . Press the MENU button to step back to the previous menu.
  • Page 33 DYON LIVE 43 PRO X Description of the individual menu items Picture Mode Dynamic, Standard, Mild and Personal Contrast Setting 0 - 100 Brightness Setting 0 - 100 Colour Setting 0 - 100 Tint Setting 0 - 100 Sharpness Setting 0 - 100...

  • Page 34: Sound Menu

    DYON LIVE 43 PRO X 9.3 Sound Menu You can adjust the sound effect here such as treble, bass, balance etc. Press the / buttons to select the setting, press the / buttons to change the setting and press the OK button to confirm.

  • Page 35: Time Menu

    DYON LIVE 43 PRO X 9.4 Time Menu You can set the sleep timer, the auto standby, and the display time. Press the / buttons to select a setting, press the / buttons to change the value and the OK button to confirm.

  • Page 36: Lock Menu

    DYON LIVE 43 PRO X 9.5 Lock Menu System Lock Set Password Channel Lock LOCK Parental Guidance Key Lock Hotel Mode Move Return Menü Selectl EXIT Exit Description of the individual menu items System Lock Here you can lock the system, the...

  • Page 37: Setup Menu

    DYON LIVE 43 PRO X Note The default password is 0000. If the menu is completely locked, the hotel mode can be opened directly with the key combination MENU 4588 (without hyphens). This option is only available in the DVB-T and DVB-S modes 9.6 Setup Menu...
  • Page 38 DYON LIVE 43 PRO X Language English TT Language West Audio Languages Deutsch Subtitle Language Deutsch Hearing Impaired Aspect Ratio Auto Blue Screen SETUP First Time Installation Reset Software Update (USB) Environment Home Mode HDMI CEC Move Return MENU Select...
  • Page 39 DYON LIVE 43 PRO X Description of the individual menu items Language Select the menu language TT Language Select the videotext language Audio Languages Select Audio Language Subtitle Language Select Subtitle Language Hearing Impaired On / Off Aspect Ratio Select aspect ratio between:...

  • Page 40: Hotel Mode

    DYON LIVE 43 PRO X 10 Hotel Mode To enter the hotel mode, select "System Lock " under the menu item "LOCK". Confirm with the OK button and enter the / password (0000). Now this menu item is activated, press to change the setting (On / Off) and you can select "Hotel...
  • Page 41 DYON LIVE 43 PRO X Description of the individual menu items Enable or disable hotel mode Hotel Mode Lock source Lock individual sources (satellite, HDMI, etc.) Default Source Off, Satellite, DVB-T/C, ATV, AV, PC Default Prog Set channel at system start...

  • Page 42: Epg (Electronic Program Guide)

    DYON LIVE 43 PRO X 11 EPG (Electronic Program Guide) The EPG menu is used to look at what is being broadcasted on DTV or Radio channel in the day. To access the EPG menu, press the EPG button, the following menu will be displayed.

  • Page 43: Ci+ Information

    DYON LIVE 43 PRO X 12 CI+ Information The TV set contains a Common Interface CI+ Slot. Different CAM cards with Smart card reader can be found at local dealers for different Pay-TV provider. • Set in: Turn off the TV. Now insert the module.
  • Page 44 DYON LIVE 43 PRO X Important Menu options and existing setting points depend on the CI+ module you are using. The CI+ module (not included in the scope of delivery) is necessary to be able to receive encrypted stations using a Smart card (not supplied).

  • Page 45: Teletext

    DYON LIVE 43 PRO X 13 TELETEXT Teletext is an information system broadcast by certain channels which can be consulted like a newspaper. It also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.)

  • Page 46: Selecting The Source

    DYON LIVE 43 PRO X 14 Selecting the Source This unit includes a variety of input sources, which can be selected and selected using the SOURCE button on the remote control. Press the SOURCE button to enter the input source menu, the following screen appears.

  • Page 47: Usb Devices

    DYON LIVE 43 PRO X 15 USB Devices 15.1 Connect USB Device The Dyon Core has an USB Port to upgrade the software and playing media files. Please connect USB media directly to the USB interface of the device. If this is not possible, please use only connection cables that are not longer than 25cm.

  • Page 48: Photo Playback

    DYON LIVE 43 PRO X 15.2 Photo Playback / / buttons Use the to select a photo. A preview image is displayed. Press the OK button or Play button ► (at the bottom of the remote control) to display the photo in full screen mode.

  • Page 49: Music Playback

    DYON LIVE 43 PRO X 15.3 Music Playback / /buttons Use the to select a music file.An info file is displayed. Press the OK button or Play button ► (at the bottom of the remote control) to play the music file When the media file (photo, music, movie) is played, press the OK or INFO button to display the control bar.

  • Page 50: Troubleshooting

    DYON LIVE 43 PRO X 16 Troubleshooting 16.1 No sound /No Picture Trouble phenomenon Symptom Inspection Check Picture Audio antenna position, direction Snow Noise or connection antenna position, direction or connection Ghost Normal audio electronic equipment, car/motorcycle, fluorescent Interfere Noise...

  • Page 51: Error Notes

    DYON LIVE 43 PRO X Remote control The battery is exhausted Change new battery unit is not Remote control unit is not Adjust the way of holding workable in the right opposite of the remote control unit and front panel or too far from...
  • Page 52 DYON LIVE 43 PRO X Check the input source using the SOURCE button. The reception is Check the antenna disturbed, the antenna cable. cable is not In TV mode, press connected, an unused the OK button to No Signal reception path has...

  • Page 53: Specifications

    DYON LIVE 43 PRO X 17 Specifications Frequency Range 48.25MHz ~ 863.25MHz 75Ω Input impedance PAL, SECAM Video System Sound System BG, DK, I, L/L' NICAM/A2 (PAL, SECAM) 1000Pages Teletext Max. Number of 99CH channels VHF (50MHz ~ 230 MHz)
  • Page 54 DYON LIVE 43 PRO X The terms HDMI and HDMI High-Definition Multimedia Interface and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories.
  • Page 55 DYON LIVE 43 PRO X Product information about the energy efficiency of this device according to EU regulation (EU) 2019/2013 can be found on the following website of the European Union from 1 of March 2021. To open, please scan the following QR code with your cell phone.

  • Page 56: Glossar

    DYON LIVE 43 PRO X 18 Glossar DiSEqC Digital Satellite Equipment Control Digital system, with which the receiver can control different components of the external unit. It is especially used for selecting from multiple satellite positions (for example Astra and Eutelsat).

  • Page 57: Warranty Condition

    We offer a warranty on our products in accordance with the following conditions: DYON products are covered by a 12 month warranty. We will resolve damages or defects on DYON products free of charge within 12 months of the purchase date under the following warranty conditions.
  • Page 58 DYON LIVE 43 PRO X IMPORTANT: AXDIA will only accept parcels that have an RMA number. Please observe the following when sending the product: 1. Send the product suitably packaged with carriage and insurance paid. Do not enclose any accessories with the products (no cables, CD's, memory cards, manuals, etc.),...
