- Page 1 IRON GENIE Chemical Free Iron & Sulfur Reduction...
- Page 2 SPECIFICATIONS SERVICE * PEAK* MEDIA BACKWASH RATE MODEL # TANK SIZE FLOW RATE FLOW RATE CUBIC FEET (GPM) (GPM) (GPM) TIG56SXT-SI 10X54 TIG56SXT-SI-ECM 13X54 11.0 *Peak flow rates are non-continuous for residential use only. Flow rates are substantially higher when ZeoPrep filtering media is used.
-
Page 3: Installation
Iron Genie Operating & Service Manual The Iron Genie is an excellent way to remove iron and sulfur from your water. Based on a unique patent-protected (US Patent 5,919,373) process the Iron Genie removes iron effectively and economically without the need for costly dangerous chemicals, troublesome pumps, or external air injectors. - Page 4 SYSTEM INSTALL AND START-UP 1. The Iron Genie will normally be installed after supply lines to the outside(unless there is a reason to keep outside faucets iron-free) and after neutralizing filter if needed(Calcite, Corosex) 2. All plumbing should be done in accordance with local plumbing codes. 3.
-
Page 5: Setting The Control
SETTING THE CONTROL The Iron Genie uses the Fleck model SXT power head to manage the regeneration process. While in the “Service” position the display will alternate between time of day and days remaining till regeneration. The clock uses a standard 12 hour display. The regeneration cycle is preset to occur at 12:30A.M. -
Page 6: Setting The Time Of Day
In condition of high water usage and/or high levels of iron, the unit may need to regenerate more frequently than the standard three day cycle. The unit can be set for every other day regeneration or daily regeneration, as required. Do not set the regeneration frequency of longer than every three days as this risk fouling the filter medium and can, over time, render the unit inoperable. - Page 7 IRON GENIE MASTER PROGRAMMING GUIDE Press the Up or Down Arrow Buttons to enter the Time of Day Programming Mode, Set the Time of Day Display to 12:01 P.M. Press the Extra Cycle Button once to exit the Time of Day Programming Mode. With the Time of Day Display set to 12:01 P.M., Push and hold the Up and Down Arrow Buttons for 7 seconds.
-
Page 8: Troubleshooting
Troubleshooting Problem Possible Cause Solution No power at electric outlet Repair outlet or use working outlet Plug Power Adapter into outlet Control valve Power Adapter not No Display on PC Board plugged into outlet Defective Power adapter Replace Power Adapter Defective Circuit Board Replace Power Head Assembly Power Outage... - Page 9 Troubleshooting Error Error Code Type Cause Reset and Recovery The valve drive took Unplug the unit and examine the power head. Verify that all Sense longer than 6 minutes cam switches are connected to the circuit board and Error to advance to the functioning properly.
- Page 10 Power Head Assembly...
- Page 11 Valve Power Head Assembly, Continued Item No. Quantity Part No. Description ......1 ....26001-02 ....Housing, Control Valve Drive ......2 ....12473 ....Screw, Hex Wsh 10-24 x 5/8 ......1 ....19474 ....Harness, Power, 56SXT, Elect ......1 ....13299 ....Washer, Spring, 3/8 ......1 ....13017 ....Gear, Idler ......1 ....23045 ....Gear, Drive, 6700 ......1 ....13175 ....Plate, Motor Mounting ......4 ....13296 ....Screw, Hex Wsh, 6-20 x 1/2 ......1 ....16944 ....Motor, Drive, 24V 60 Hz 2 rpm...
-
Page 12: Control Valve Assembly
CONTROL VALVE ASSEMBLY... - Page 13 Control Valve Assembly, Continued Item No. Quantity Part No. Description 1......2......13255......Adapter Clip 2......5......18759......Seal, Low Drive Force 3......1......61400-12....Valve Body Assembly, 1 Dist. 4......1......13304......O-ring, Distributor Tube, 1 5......1......12281......O-ring, Top of Tank 7......4......14241......Spacer 8......1......17218-IG....Piston, Proprietary 9......1......10696......Piston Pin 10......1......13001-04....Rod, Piston, 56SXT/6700 11......1......14309......Retainer, Piston Rod 12......1......13446-41....Plug, End, 56SXT/6700, Green 14......2......13315......Screw, Injector Mounting 15......1......19228-01....Adapter Assy,Coupling,5600,w/O-ring 16......4......13305......O-ring, Adapter Coupling...
-
Page 14: Bypass Valve Assembly
BYPASS VALVE ASSEMBLY Item No. Quantity Part No. Description ......1 ......17290 ....Bypass Valve Body, 3/4” ......1 ......13399 ....Bypass Valve Body, 1” ......1 ......14105 ....Seal, Bypass ......1 ......11972 ....Plug, Bypass ......1 ......11978 ....Side Cover ......1 ......13604-01 ....Label ......8 ......15727 ....Screw ......1 ......11986 ....Side Cover ......1 ......11979 ....Lever, Bypass ......1 ......11989 ....Screw, Hex Head, ¼-14... - Page 15 RECOMMENDED IRON FILTER SERVICE KIT 13001-04 Piston Rod Assembly 13446-41 End Plug Assembly, Green 60125-02 Seal and Spacer Kit, Low Drive Force 10913-2 Injector Nozzle #2, Blue 10914-2 Injector Throat #2, Blue 10227 Screen 42933 Main Drive Gear 60032 Brine Valve 13302 O-ring, Brine Valve IOK Injector Body O-Ring Kit...
- Page 16 Service Instructions Power Head Replacement 1. Unplug Power Head from electrical outlet. 2. Remove the Power Head back cover. 3. Remove black screw and silver washer at drive yoke on piston rod. 4. Remove 2 silver timer mounting screws. 5. Lift off entire Power Head assembly. 6.
- Page 17 Brine Valve Replacement 1. Move the integral stainless steel bypass to the bypass position. 2. Relieve the water pressure in the Iron Genie by holding down the Extra Cycle button for 5 seconds. Once in the “BW” cycle pressure will be relieved. 3.
- Page 18 Piston Rod and End Plug/Seal and Spacer Replacement 1. Move the integral stainless steel bypass to the bypass position. 2. Relieve the water pressure in the Iron Genie by holding down the Extra Cycle button for 5 seconds. Once in the “BW” cycle pressure will be relieved. 3.
