Summary of Contents for Addie Water Systems OXIDIZER PLUS
- Page 1 OXIDIZER PLUS Chemical Free Sulfur Reduction...
- Page 2 SPECIFICATIONS MAXIMUM SERVICE * PEAK* HYDROGEN BACKWASH RATE MODEL # TANK SIZE FLOW RATE FLOW RATE SULFIDE (GPM) (GPM) (GPM) REMOVAL AU-1054-NSSXT 10X54 12 PPM Au-1354-NSSXT 13X54 12 PPM 10.0 13.0 *Peak flow rates are non-continuous for residential use only.
-
Page 3: Installation
Plus removes hydrogen sulfide effectively and economically without the need for costly dangerous chemicals, troublesome pumps, or external air injectors. The Oxidizer Plus can be used whenever hydrogen sulfide is a problem. Years of field experience with the Oxidizer Plus have shown it will remove hydrogen... - Page 4 SYSTEM INSTALL AND START-UP 1. The Oxidizer Plus will normally be installed after supply lines to the outside(unless there is a reason to keep outside faucets smell free) and after neutralizing filter if needed(Calcite, Corosex) 2. All plumbing should be done in accordance with local plumbing codes.
-
Page 5: Setting The Control
Should you require the unit to regenerate at a time of day other than 12:30 A.M. it is important that no other unit, softener or filter, regenerates at the same time. This will interfere with the regeneration process of the Oxidizer Plus. -
Page 6: Setting The Time Of Day
In condition of high water usage and/or high level of hydrogen sulfide, the unit may need to regenerate more frequently than the standard three day cycle. The unit can be set for every other day regeneration or daily regeneration, as required. - Page 7 IRON GENIE MASTER PROGRAMMING GUIDE Press the Up or Down Arrow Buttons to enter the Time of Day Programming Mode, Set the Time of Day Display to 12:01 P.M. Press the Extra Cycle Button once to exit the Time of Day Programming Mode. With the Time of Day Display set to 12:01 P.M., Push and hold the Up and Down Arrow Buttons for 7 seconds.
-
Page 8: Troubleshooting
Troubleshooting Problem Possible Cause Solution No power at electric outlet Repair outlet or use working outlet Plug Power Adapter into outlet Control valve Power Adapter not No Display on PC Board plugged into outlet Defective Power adapter Replace Power Adapter Defective Circuit Board Replace Power Head Assembly Power Outage... - Page 9 Troubleshooting Error Error Code Type Cause Reset and Recovery The valve drive took Unplug the unit and examine the power head. Verify that all Sense longer than 6 minutes cam switches are connected to the circuit board and Error to advance to the functioning properly.
- Page 10 Power Head Assembly...
- Page 11 Valve Power Head Assembly, Continued Item No. Quantity Part No. Description ......1 ....26001-02 ....Housing, Control Valve Drive ......2 ....12473 ....Screw, Hex Wsh 10-24 x 5/8 ......1 ....19474 ....Harness, Power, 56SXT, Elect ......1 ....13299 ....Washer, Spring, 3/8 ......1 ....13017 ....Gear, Idler ......1 ....23045 ....Gear, Drive, 6700 ......1 ....13175 ....Plate, Motor Mounting ......4 ....13296 ....Screw, Hex Wsh, 6-20 x 1/2 ......1 ....16944 ....Motor, Drive, 24V 60 Hz 2 rpm...
-
Page 12: Control Valve Assembly
CONTROL VALVE ASSEMBLY... - Page 13 Control Valve Assembly, Continued Item No. Quantity Part No. Description 1......2......13255......Adapter Clip 2......5......18759......Seal, Low Drive Force 3......1......61400-12....Valve Body Assembly, 1 Dist. 4......1......13304......O-ring, Distributor Tube, 1 5......1......12281......O-ring, Top of Tank 7......4......14241......Spacer 8......1......17218-OXPL....Piston, Proprietary 9......1......10696......Piston Pin 10......1......13001-04....Rod, Piston, 56SXT/6700 11......1......14309......Retainer, Piston Rod 12......1......13446-41....Plug, End, 56SXT/6700, Green 14......2......13315......Screw, Injector Mounting 15......1......19228-01....Adapter Assy,Coupling,5600,w/O-ring 16......4......13305......O-ring, Adapter Coupling...
-
Page 14: Bypass Valve Assembly
BYPASS VALVE ASSEMBLY Item No. Quantity Part No. Description ......1 ......17290 ....Bypass Valve Body, 3/4” ......1 ......13399 ....Bypass Valve Body, 1” ......1 ......14105 ....Seal, Bypass ......1 ......11972 ....Plug, Bypass ......1 ......11978 ....Side Cover ......1 ......13604-01 ....Label ......8 ......15727 ....Screw ......1 ......11986 ....Side Cover ......1 ......11979 ....Lever, Bypass ......1 ......11989 ....Screw, Hex Head, ¼-14... - Page 15 RECOMMENDED IRON FILTER SERVICE KIT 13001-04 Piston Rod Assembly 13446-41 End Plug Assembly, Green 60125-02 Seal and Spacer Kit, Low Drive Force 10913-2 Injector Nozzle #2, Blue 10914-2 Injector Throat #2, Blue 10227 Screen 42933 Main Drive Gear 60032 Brine Valve 13302 O-ring, Brine Valve IOK Injector Body O-Ring Kit...
- Page 16 Service Instructions Power Head Replacement 1. Unplug Power Head from electrical outlet. 2. Remove the Power Head back cover. 3. Remove black screw and silver washer at drive yoke on piston rod. 4. Remove 2 silver timer mounting screws. 5. Lift off entire Power Head assembly. 6.
- Page 17 Brine Valve Replacement 1. Move the integral stainless steel bypass to the bypass position. 2. Relieve the water pressure in the Iron Genie by holding down the Extra Cycle button for 5 seconds. Once in the “BW” cycle pressure will be relieved. 3.
- Page 18 Piston Rod and End Plug/Seal and Spacer Replacement 1. Move the integral stainless steel bypass to the bypass position. 2. Relieve the water pressure in the Iron Genie by holding down the Extra Cycle button for 5 seconds. Once in the “BW” cycle pressure will be relieved. 3.
