Page 19
All the contents of this Guide have been checked carefully. If there are any printing errors OR misunderstanding, please contact with Midea customer service team. NOTE: It will be compiled into the new version of the guide without any notice if involve the technical improvements.
• WARNING:If the door or door seals are damaged, the oven must not be operated and contact to Midea customer service team to reserve the service of checking and repair. IMPORTANT NOTICE: • Please read this guide carefully before start use the appliance.
• If the supply cord is damaged, please stop use the appliance immediately and contact to Midea customer service center to reserve the service of checking and repair. • When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
Page 22
• The microwave oven is intended for heating food and beverages. Except of food and beverages, please do not put other materials into the microwave oven, such as: Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth to risk of injury, ignition or fire.
Page 23
SAFETY WARNING This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
CLEANING Ensure to switch off the appliance and unplug the socket before cleaning the appliance. • Use a damp cloth to clean the oven cavity after used in every single time. • Clean the accessories with soapy water. • Use a damp cloth to clean the door frame and the parts. •...
Page 25
MATERIALS SUIT FOR THE MICROWAVE OVEN Utensils Remarks Follow manufacturer’s instructions. Browning dish The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or Dinnerware chipped dishes.
PRODUCT INTRODUCTION Control Panel Door Assembly Turntable Turntable Oven Cavity Observation Ring Assembly Shaft Window Glass Tray Safety Interlock System Grill Rack( Only be used in grill function and be placed on the glass tray ) TURNTABLE INSTALLATION Hub (underside) •...
INSTALLATION INSTRUCTIONS Remove all packing material and accessories. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface.
CONTROL PANEL Microwave / Grill / Combination Function Button Press to select microwave cooking and microwave power or select grill or com binat ion cooking. If not selected, 100% (high power) will be automatically selected. Defrost Function Button Press to defrost food by weight or by time. Clock / Pre-Set Button Press to set clock time or select auto-start.
OPERATION 1. Clock Setting When the microwave oven is electrified, 0:00 will be displayed and buzzer will ring once. • Press Clock/Pre-Set, the hour figure will flash; • Turn “ ” to adjust the hour figures (set time within 0-23). •...
Microwave Power Level Display P100 Microwave Power 100% 3. Grill Cooking • Press Micro/Grill/Combi button once, and P100 will be displayed. • Select grill power (LED displays“G”) by pressing Micro/Grill/Combi button or turn “ ” repeatedly. • Press Start/+30Sec./Confirm to confirm setting. •...
5.Quick Cooking • In standby mode, press Start/+30Sec./Confirm to start instant cooking with 100% power level for 30seconds. Each press on the same key can increase 30 seconds while cooking. (Maximum up to 95 minutes) • In standby mode, turn “ ”...
Page 32
8.Double Cooking Programs Set Up The oven is able to set up 2 cooking stages in maximum. If one of the stages is defrosting, please put in the first stage and the buzzer will ring once after 1st stage and the next stage will begin. Example: If you want to defrost the food for 5 minutes, then to cook with 80% microwave power for 7 minutes.
9.Pre-Set Function Clock must be set before operating Pre-Set function and maximum to set 2 stages cooking. (Defrosting is not applicable in Pre-Set function) Example: If you want to cook with 80% microwave power for 7 minutes at designated time. •...
Menu Weight(g) Display Power 100% Reheat 100% Vegetable Fish 100% Meat 50 (with water 450ml) Pasta 100 (with water 800ml) 100% Potato 100% Pizza Soup 11.Child Lock Function • Lock: In standby mode, press and hold Stop/Cancel 3 seconds, buzzer will ring once, denoting the child lock is in function.
13.Attention • When oven door is opened, unit will not start any cooking function by pressing Start/+30Sec. button unless the oven door is well closed. • When a cooking program has been set but no pressing Start/+30Sec. in 1 minute, the current setting will be cancelled. •...
TROUBLE SHOOTING Normal Radio and TV reception may be interfered when microwave oven Microwave oven interfering TV reception operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and electric fan. It is normal. In low power microwave cooking, oven light may become dim. It is Dim oven light normal.
