Power Step PSA-EX3600-FRS Manual page 21

FOLDING RETRACTABLE STAIRWAY
To suit Hitachi EX3600 Excavator
Section 4-7 Hydraulic Cylinder Assembly
Parts List
See Drawing Page 20
CYLINDERS
Item Part No.
1 PS-63009-A
2 PS-63009-C
3 PS-63009-TP
4 PS-63009-P
5 CPS-M8x56ZP
- PS-63103-N
PLUMBING
Item Part No.
PS61160-KIT
6
PS-61159
7
PS-61157
8
PS-61154
9
PS-61149
10
PS-61148
11
PS-63201
12
PS-61158-5MM
13
PS-61160
14
PS-61147
15
PS-63202
16
PS-63202-B
17
PS-63202-C
18
PS-61163
19
PS-61006-1
20
PS-60051-2.8M
21
PS-61166
EX3600-FRS 3-8-15
Part Name
HYD CYLINDER 2 1/2"
CYLINDER-BUSH-CLEVIS
PIN-CYLINDER-TOP
PIN-CYL-BOTTOM+WASHER
SPLIT PIN - M8 - CLEVIS PIN-TOP
SEAL KIT
Part Name
HARD PLUMBING KIT
FITTING-ELBOW- 9/16"JIC x 1/4"BSPP
FITTING-O RING 1/4BSPP x 9/16"JIC
FITTING-ELBOW-O RING 1/4BSPP x 9/16"JIC
FITTING-TEE-9/16"JIC-M/M
FITTING-TEE-9/16"JIC / 1/4" BSPP
VALVE-PILOT OPERATED-LOCKING
FITTING-0.5mm RESTRICTION 90 DEG.
TUBES - 4off 110mm, 1 off 517mm
FERRULES
FLOW CONTROL VALVE
FITTING-JIC NIPPLE
FITTING-JIC SWIVEL
FITTING-REDUCER-3/4"UNO-1/4"BSPP
FITTING-GREASE NIPPLE-90
HOSE-HYDRAULIC (not shown)
'T' FITTING
PS-63009-ASSY
Qty
2
8
2
2
6
1
Qty
.
3
2
1
1
1
1
4
.
10
1
1
1
4
2
2
2
Pg21
