R&M ControlMaster Edge Quick Installation Manual

QUICK INSTALLATION GUIDE
Frequency converter ControlMaster Edge
Disclaimer: Person conducting this work must be appropriately trained and familiar with product range and
related safety instructions. This quick guide only complements original instructions and does not replace them.

General information

A
RJ45
U /
Mains output
U/T1
V/T2
3-phase output
W/T3
B1 B2 Braking resistor
+ -
DC bus
Rating label
Current ratings and switching frequency
TDU00xE000
TDU
INPUT: 3PH, 380~480VAC, 50/60Hz
004
OUTPUT1: x.x A , x.x kVA
OUTPUT2: x.x A, x.x kVA
009
FREQUENCY RANGE: 0~320Hz
VERSION: x.x
017
EMC LEVEL MODIFIED
OPTION BOARD 028
045
Note: In case of product reclamation, include the following information:
Type, serial number, fault code (if applicable), application (hoist/travel), how problem appears (e.g. fault code
F001 during acceleration).
If any problems or malfunctions occur during commissioning, refer to the troubleshooting section in the
service instructions, to find out the reason. Make sure all problems are solved before you continue operation.
This document and the information contained herein, is the exclusive property of R&M Materials Handling Inc. and represents a non-public, confidential
and proprietary trade secret that may not be reproduced, disclosed to third parties, altered or otherwise employed in any manner whatsoever without the
express written consent of R&M Materials Handling Inc. Copyright 2021 © R&M Materials Handling Inc. All rights reserved.
R S
T
/ /
/
L1 L2
L3
STO
CAN CAN CAN CAN CAN
RA RC
GND L SHLD H V+
+
/
V / W /
B1 B2
T1 T2 T3
4 kHz 5 kHz 6 kHz 7 kHz 8 kHz 9 kHz 10 kHz 11 kHz 12 kHz 13 kHz 14 kHz 15 kHz
3.4 A 3.1 A 2.8 A
8.2 A 8.0 A 7.9 A
16.5 A 16.0 A 15.5 A 14.7 A 13.7 A 12.9 A 12.0 A 11.2 A 10.6 A 9.9 A
28.0 A 27.2 A 26.3 A 24.9 A 23.2 A 21.8 A 20.4 A 19.0 A 17.9 A 16.8 A 15.7 A 14.8 A
45.0 A 45.0 A 45.0 A 45.0 A 43.2 A 39.6 A 36.0 A 32.9 A 30.2 A 27.5 A 25.2 A 23.0 A
Mains input
R/L1
S/L2
3-phase input
T/L3
PE
Control signals
RJ45
STO
CAN
open
Relay
output
2.5 A 2.3 A 2.1 A 1.9 A
7.6 A 7.1 A 6.6 A 6.2 A
Signal LEDs
Drive ready
Drive running
Drive is not ready
CANopen not
connected
CANopen connected
Drive is not powered
Fault, code indicated
by blinking sequence
No active fault
Connection for Bluetooth
+24V Power supply for STO chnl. 1 and 2
S1 STO channel 1
S2 STO channel 2
DCM Digital signal common
CAN GND Ground
CAN L Dominant low
CAN SHLD CAN cable shield (optional)
CAN H Dominant high
CAN V+ Not in use
RA C (common)
RC NO (normally open)
1.7 A 1.6 A 1.5 A
5.7 A 5.3 A 5.0 A
1.4 A 1.3 A
4.7 A 4.4 A
9.2 A 8.7 A
