P4BGA Quick Installation Guide
JAUDIO
1
Line in R
Line in L
3
MIC
5
7
N.C.
9
Line out R 10 GND
CD-ROM Audio Line in (SONY)
Left Line in
1
2
GND
3
GND
4
Right Line in
JIR
1
VCC
2
N.C
3
IRRXD
4
GND
5
IRRXD
2
GND
MIC
4
GND
6
8
Line out L
6
N.C
7
CIRRX
8
5VSB
9
N.C
10
N.C
