2 Microtek MTMA Installing and Getting Started
Place the template on the scanner glass
surface. The calibration window of the
template should point toward the front
of the scanner.
Press the template firmly on the scanner
glass bed to make sure it adheres to the
glass surface.
Template should fit snugly
within the scanner glass
area and should not overlap
with the vertical/horizontal
rulers on the scanner.
Place the transparent material to be scanned (face down) on the scanner glass surface
and within the template. Then put the 4 film stoppers on the corners of the film.
Stoppers
: To scan transparent or negative film, the template should always stay on
the scanning bed. If the template is removed or is incorrectly placed, your scanner will
not work properly. The calibration window or the slim rectangular opening is the color
calibration area. You must keep this area clear and free from any obstruction.
Otherwise, the quality of your scanned image may be adversely affected or cause the
scanner to malfunction.
Calibration
window
: Make sure that the anti-skid rubber part of all 4
stoppers are facing toward the glass surface.
The transparent material should not block,
obstruct, or overlap the calibration window
of the template in any way.
