Page 6
The drainage hose must be positioned to be less than 15 ft. above the unit. Failure to do so may cause water backup in the pump resulting in leakage. ON/OFF control Operating Indicator UP and DOWN humidity controls TIME control Humidity and Time Display PURGE control Purging Indicator...
Page 7
ON/OFF control: Press the ON/OFF control to turn the unit ON or OFF. Operating Indicator: The indicator light has 3 states: (1) off when power is not available, (2) flashing when power is available and unit is OFF, or when the control panel is locked and the unit in ON, and (3) on when unit is ON.
Page 8
A. Operations for general use: · To turn the unit ON, press the ON/OFF control. To protect the compressor, there is a 60 second startup delay when the unit is turned ON. · To set the desired humidity level, press and hold the UP and DOWN controls. ·...
Page 9
Air Filter 1. Remove the air filter as shown above. 2. Vacuum any debris from the air filter. 3. Using luke-warm water and a mild detergent, wash the air filter and allow to dry. 4. Once dry, reinstall the air filter. PAGE...
Maintenance Maintenance REPLACING THE BATTERY REPLACING THE BATTERY Remove the screws in the four corners of the control panel. Once the screws are removed, carefully lift the control panel to access the PCB. III. Refit the control panel onto the PCB. Refit the four screws.
Page 11
CODE ERROR FLASHES EVERY 30 SEC’S HUMIDITY SENSOR ERROR LOW OR NO REFRIGERANT WATER PUMP FAULT OR BLOCKAGE MESSAGE DISPLAY FLASHES EVERY 30 SEC’S FLASHES EVERY 30 SEC’S FLASHES CONTINUALLY FLASHES CONTINUALLY READING TIMED DEFROST MODE. 50% R.H DISPLAYED TURN POWER OFF. DEHUMIDIFIER WILL TURN OFF THE DEHUMIDIFIER IS CONTINUOUS MODE IN OPERATION...
SPECIFICATIONS MODEL PA-45-LGR PA-70-LGR POWER SUPPLY 115V/60Hz 115V/60Hz WATER REMOVAL @ SATURATED (90°F, 90% RH) 145 PINTS PER DAY 125 PINTS PER DAY WATER REMOVAL @ AHAM (80°F, 60% RH) 85 PINTS PER DAY 77 PINTS PER DAY RATED POWER...
Page 14
ITEM PART ITEM PART DESCRIPTION DESCRIPTION NUMBER NUMBER NUMBER NUMBER LGR45-01 INLET AIR DAMPER LGR45-16 AC MOTOR LGR45-02 SPONGE FILTER LGR45-17 FAN BLADE INLET AIR DAMPER LGR45-03 LGR45-18 FAN BLADE LGR45-04 TEMPERATURE SENSOR LGR45-19 GUIDE PLATE LGR45-05 EVAPORATOR LGR45-20 AIR OUTLET NET COVER LGR45-06 CONDENSER LGR45-21...
Page 15
28 29 ITEM PART ITEM PART DESCRIPTION DESCRIPTION NUMBER NUMBER NUMBER NUMBER LGR70-01 INLET AIR DAMPER LGR70-21 VOLUTE CASING LGR70-02 SPONGE FILTER LGR70-22 AC MOTOR FRONT CASING LGR70-03 LGR70-23 FOUR WAY VALVE / BRASS LGR70-04 FRONT CHASSIS LGR70-24 REAR CASING LGR70-05 WATER PUMP LGR70-25...
