- Page 1 Dr. DMX II USER'S MANUAL 24 – 004 – 1423 Rev 1.0 October 2004 Web site: www.elationlighting .com E-mail: info@elationlighting.com...
-
Page 2: General Information Introduction
This unit has been thoroughly tested and carefully packed. Please check contents and packing carefully to be sure that your product is not damaged and all accessories are accounted for. If your product happens to be damaged or missing parts, please do not use it. Please contact Elation Professional. Safety Instructions To r educe the risk of electric shock or fire when using this unit: Do not immense in or expose to water. - Page 3 3~5 hours, which can supply power to this unit for 6~8 hours. Switch the unit on, (the switch is on the back), and the LCD should display: < ==== Elation ==== Dr.DMX–II DMX TESTER REV1.1 >...
-
Page 4: Data Format
If there is no signal input and you have accessed each menu of Data format, Data timing, Data level (Volt) by the multi-selector wheel, the LCD window will display: < DMX packet test: Receive no signal ?” You may move the cursor to the “ for help. - Page 5 (Here the connected controller is a DMX Operator.) < Data timing: All the parameters can be shown here. BK: 135_ MaB: 016_ StartCode : 000 dec > Chan. Time: 053_ signal is good >” Select “ first and then press the multi-selector this will allow you to shift from the Chan. Time to Period Time.
-
Page 6: Barchart Display
< DMX data RX 1. Barchart display > 2. Value display > 3. Min/ max display > This DMX data--RX function can display the value of the signal input by the means of a Barchart, Value, or Min/max, complying with the display mode that can be adjusted in the System setup menu. There are two display modes: Normal and Hold Mode. -
Page 7: Value Display
2. Value display This option can display the value of the signal input by the means of decimal, hexadecimal and percent. Turn the multi-selector wheel forward to enter the Barchart display option. If there is no signal input, the LCD window will display: <... - Page 8 Supposed that you have set the percent display mode. If there is no signal input, the LCD window will display. < RX Channle : 000 Chan. min typ max > 001 --- --- --- % > Count at : xxxxx Sec 253 255 255 000 000 On the contrary, if the signal input is being received correctly, the LCD window will display the >...
- Page 9 >” To adjust the temporary value of the desired channel, first turn the multi-selector wheel to “ the third line. Then adjust the "Data" at the fourth line. The "Data" displays the value by the means of decimal and percent. You may turn the multi-selector to scroll to the next page.
- Page 10 The Speed can will only take effect when the mode is set to Auto On/Off or Ramping. In this case, the level of the desired channel is adjusted automatically by this unit. You can adjust the level by the fader when the mode is set to Fader Only or Fader Fine. However, there is only one channel level varied from the other 511 channel levels.
-
Page 11: Moving Light
The default start cue is cue 1. You can adjust the end cue No. and speed rate ( 1 -10 ) by using multi-selector wheel. ?” For more information, press “ for help. < 4. Run Cues(Scenes) From cue 1 to the end cue continually in speed rate Moving light... - Page 12 05 Focus 06 Frost 13 Pan 14 Pan fine fig.1 fig.2 16 Reset 07 Gobo 08 Gobo rot 15 Prism 18 Shutter 09 Inten'ty 10 Iris 17 Rot spel 20 Speed CG 11 Lamp 12 Magenta 19 Special 21 Speed P 22 Speed PT 29 --------- 30 --------...
-
Page 13: Cable Test
Save Cue ( Scene ) If there is DMX input signal present, the saved cue can be the received signal. However, if there is no signal input, activating the Save Cue function will save the previous received or running cue as new one. -
Page 14: System Setup
Otherwise, if the cable does not work normally, the LCD window displays: < Cable Test --- Result: -> Cable not OK MIDI data -- RX This option tests the MIDI data to find out whether there are some errors when transmitting. When the cable isn't connected normally and you have accessed this function, the LCD window will display: <... -
Page 15: Display Setting
operator, the channel value of the unit will change instantly, adjusting with the position of the fader. In the Hold display mode, when changing the value referring to the specific channel of the external operator, the channel value of the unit may not change temporarily. The display value is only the max. - Page 16 NOTE: If you don’t deactivate the backlight, it will automatically go out in 10 seconds so that it does not consume power. You can also change the value display in three modes, including decimal, hexadecimal and percent. >” To save what you have set, move the cursor to “ on the fourth line, confirm by pressing the <”...
