Summary of Contents for Duroflame Batavia T4

  • Page 1 Manual Batavia T4 - Rembrand T3 - Carré T3 20.4...
  • Page 2 Page 2 from 37...

  • Page 3: Table Of Contents

    Introduction Warranty conditions and recommendations Warranty conditions Safety recommendations Operating recommendations Operation The fuel Installing the stove Precautions Stove location Connection Starting a pellet stove Starting up for the first time Switching on the pellet stove 4.2.1 Ignition Operation Button Controller Leds Button explained User manual...
  • Page 4 It gets too hot in the house Read and reset error Fault messages and solutions 9.1.1 ERROR 1 9.1.2 ERROR 5 9.1.3 ERROR 6 9.1.4 ERROR 8 9.1.5 ERROR 9 10 Parts Explanation parts 10.1.1 Circuit board 10.1.2 Control panel 10.1.3 Data cable 10.1.4...

  • Page 5: Introduction

    To get the most out of your Duroflame stove and use it as safely as possible, we recommend that you read this manual carefully before using the stove.
  • Page 6 • The previous paragraph does not apply to consumers. • In the event of a justified claim under the guarantee, Duroflame will - at its discretion - take care of repair or replacement of the goods free of charge, the correct execution of the agreed work or a refund or discount on the agreed price.

  • Page 7: Safety Recommendations

    Duroflame from all liability. • Any modification to the stove and replacement with non-original parts may compromise the safety of the user and exempts Duroflame from all liability. It is forbidden to apply these modifications and replacements without written permission.

  • Page 8: Operating Recommendations

    73/23 EEC & 93/98 EEC. • Incorrect installation or poor maintenance may cause damage to persons, animals or objects. In this case, Duroflame disclaims all liability. • The stove should be fully cleaned and serviced after every 1,200 hours of burning or after every year of use.

  • Page 9: Operation

    It is not permitted to burn any raw materials other than wood pellets in Duroflame pellet stoves, not even to light the stove. If this is done, the warranty will be voided and safety compromised.

  • Page 10: Installing The Stove

    3 Installing the stove Precautions Installation of the stove must be carried out by qualified personnel. The stove must only be installed in a suitable room, the room must: • Comply with the operating and environmental conditions (described in this manual).

  • Page 11: Connection

    Connection Electrical connection It is important that the stove is installed by qualified personnel. Connection to the mains is by means of the power cable provided. Ensure that the plug remains accessible at all times when the appliance is installed. Ensure a properly earthed socket.

  • Page 12: Starting A Pellet Stove

    (electric) extraction or heating systems in the same room (e.g. an extractor hood or wood stove). On all Duroflame pellet stoves it is possible to connect an external air inlet. By using this external air inlet, the pellet stove uses outside air for combustion. The combustion of the stove is then no longer influenced by the ventilation in the room.

  • Page 13: Switching On The Pellet Stove

    • Check that the burn pot is placed as far back as possible and that the glow plug is in front of the hole in the burn pot. • Check that the door is properly closed. Switching on the pellet stove You do this by using the power switch.

  • Page 14: Button Controller

    Button Controller -The controller consists of 1 button and 6 multicoloured LEDs. -The functions of each are explained below. Leds There are 6 LEDs near the Button. The first from the left is the STATE LED, which represents the working state of the device.
  • Page 15 LED STATUS The STATE LED changes colour and flashing pattern based on the current state of the stove. Table 1. Meaning of the LED status State Colour and pattern Normal operation Constant green Pulse green Adjust power level Cooling down Flashing blue Error Flashing red...

  • Page 16: Button Explained

    Button explained The button can be pressed clockwise or anti-clockwise. Table 3. Use of the button Description Turn clockwise Select a higher power level Turn anticlockwise Select a lower power level Press once Reset error - disable WiFi access point Long press (>5 seconds) Switch on WiFi access point 5 User manual...

  • Page 17: Read And Reset Error

    The STATE LED flashes for 3 seconds to wait for your final selection. After 3 seconds, it saves the selection and operates at the power level selected. Power level 4 Read and reset error The stove is equipped with a series of sensors and control mechanisms to ensure the safe operation of the unit.

  • Page 18: Periodic Maintenance

    6 Periodic maintenance General maintenance For a long service life of the stove, it is important to carry out regular maintenance and clean the stove as described in the following paragraphs. For (fire) safety reasons, it is necessary to have a full service carried out by qualified personnel after every year of use, or every 1,200 burning hours.

  • Page 19: Cleaning The Pellet Tank

    6.1.5 Cleaning the pellet tank Clean the pellet reservoir every 3 months, depending on your pellets and consumption. If too much dust and sawdust accumulates at the bottom of the reservoir, the auger may not be able to load enough pellets or the auger may even jam and cause damage.
  • Page 20 Batavia T4 Figure 11-Exploded view Figure 2- Combustion Pot Figure 3- Vermiculite Lining Page 20 from 37...
  • Page 21 Figure 4- Igniter Removal Figure 5- Fan Removal b. Rembrand T3 Figure 1- Exploded view Page 21 from 37...
  • Page 22 Figure 3- Vermiculite Lining Figure 2- Combustion Pot Figure 5- Fan removal Figure 4- Igniter Removal Page 22 from 37...
  • Page 23 c. Carré T3 Figure 1- Exploded view Figure 3- Vermiculite Lining Figure 2- Combustion Pot Page 23 from 37...

  • Page 24: Problems And Solutions

    Figure 4- Igniter Removal Figure 5- Fan removal 7 Problems and solutions No pellet supply The stove does not feed pellets. Possible causes: - One of the protection sensors is switched on, this can be the maximum thermostat (see component 10.1.7) or the pressure switch (see component (10.1.6).

  • Page 25: Pellet Stove Gets Too Hot

    the stove will show an error. This requires a distinction between ignition or no ignition. There is actually no ignition and no fire. Possible causes: • The glow plug is defective (see component 10.1.8) • Not enough oxygen. This can have several causes: o The stove is clogged and needs maintenance.

  • Page 26: It Gets Too Hot In The House

    It gets too hot in the house This can have several causes: The stove has too much power in P1. This is the cause in most cases, there is nothing wrong with the stove. This means that in a small and/or well-insulated room, the temperature will continue to rise as long as you leave the stove on.

  • Page 27: Error

    9.1.3 ERROR 6 This error message can have two causes: • Component pressure switcher (see 10.1.6) • Component maximum thermostat (see 10.1.7) 9.1.4 ERROR 8 This error message is given if power is cut when the stove is in the ignition, operating or cooling phase.

  • Page 28: Maximum Thermostat

    10.1.7 Maximum thermostat The maximum thermostat monitors the maximum temperature of the pellet tank. As soon as it gets too high, the thermostat will switch over and the stove will give a malfunction. The auger motor will then not receive power. You can reset the maximum thermostat by pressing the reset button.

  • Page 29: Technical Specifications

    11 Technical specifications Batavia T4 Room heater, Wood Pellet Stove Distance to combustible materials: Front: 80 cm Side: 40 cm Back: 5 cm Performance Nominal Minimum Output 7,6 kW 3,4 kW Efficiency 90.7% 90.8% Flue gas temp. 161 °C 86 °C Pellet consumption 1.72 kg...
  • Page 30 Rembrand T3 Carré T3 Room heater, Wood Pellet Stove Room heater, Wood Pellet Stove Distance to combustible materials: Distance to combustible materials: Front: 100 cm Sides: 5 cm Back: 5 cm Front: 100 cm Sides: 5 cm Back: 5 cm Performance Nominal Minimum...

  • Page 31: Electrical Diagram

    12 Electrical diagram Page 31 from 37...

  • Page 32: Declarations Of Conformity

    13 Declarations of conformity EU-CONFORMITEITSVERKLARING Product: Batavia T4 Fabrikant: Duroflame BV Verbindingsweg 17 9781 DA Bedum – Nederland Deze conformiteitsverklaring wordt verstrekt onder volledige verantwoordelijkheid van de fabrikant. Productomschrijving: Pelletkachel bestemd voor gebruik in huiselijke ruimtes. Het hierboven beschreven voorwerp is conform de...
  • Page 33 EU-CONFORMITEITSVERKLARING Product: Rembrand T3 Fabrikant: Duroflame BV Industrieweg 37 9781 AC Bedum – Nederland Deze conformiteitsverklaring wordt verstrekt onder volledige verantwoordelijkheid van de fabrikant. Productomschrijving: Pelletkachel bestemd voor gebruik in huiselijke ruimtes. Het hierboven beschreven voorwerp is conform de 2019/125/EG (betreffende de totstandkoming van een...
  • Page 34 EU-CONFORMITEITSVERKLARING Product: Carré T3 Fabrikant: Duroflame BV Industrieweg 37 9781 AC Bedum– Niederlande Deze conformiteitsverklaring wordt verstrekt onder volledige verantwoordelijkheid van de fabrikant. Productomschrijving: Pelletkachel bestemd voor gebruik in huiselijke ruimtes. Het hierboven beschreven voorwerp is conform 2019/125/EG (betreffende de totstandkoming van een kader...

  • Page 35: Performance Declaration

    14 Performance declaration PRESTATIEVERKLARING in overeenstemming met Verordening (EU) nr. 305/2011 Nr. 2000 Unieke identificatiecode van het producttype: Batavia T4 Beoogde gebruik: Huishoudelijke ruimteverwarmingstoestellen gestookt met houtpellets, zonder warmwaterproductie Fabrikant: Duroflame BV Verbindingsweg 17 9781 DA Bedum – Nederland Gemachtigde:...
  • Page 36 Unieke identificatiecode van het producttype: Carré T3 Beoogde gebruik: Huishoudelijke ruimteverwarmingstoestellen gestookt met houtpellets, zonder warmwaterproductie Fabrikant: Duroflame BV Verbindingsweg 17 9781 DA Bedum – Nederland Gemachtigde: Het systeem of de systemen voor de beoordeling en Systeem 3 verificatie van de prestatiebestendigheid:...
  • Page 37 Unieke identificatiecode van het producttype: Rembrand T3 Beoogde gebruik: Huishoudelijke ruimteverwarmingstoestellen gestookt met houtpellets, zonder warmwaterproductie Fabrikant: Duroflame BV Verbindingsweg 17 9781 DA Bedum – Nederland Gemachtigde: Het systeem of de systemen voor de beoordeling en Systeem 3 verificatie van de prestatiebestendigheid:...

This manual is also suitable for:

Rembrand t3Carre t3
