Installation And Testing - Concept Smoke Screen Sound Barrier Installation And Operator's Manual

DIP SWITCH SETTINGS
Dip switch setting control the following functions:
Duration of Sound:
Delay after Activation:
Disable Sounder:
Test / Normal Mode:
Note: Test mode enables the sounder to be tested without full tones and volume.

INSTALLATION AND TESTING

Remove end cap and mesh cover.
DISABLE SOUNDER
Switch Dip 7 to ON to prevent accidental activation.
MOUNT SOUNDER
Mount the S3B Sound Barrier in the desired location.
CONNECTIONS
Ensure the Battery Enable switch is OFF.
Make connections for the 12-volt external power supply.
Make connections for the alarm relay (normally closed opening in 'Alarm')
Make connections for Status Monitoring (optional).
SETTING THE SOUNDER TIMER
The S3B Sound Barrier will produce sound for a preset period. This can be from 30 seconds up to 8 minutes. The
timing is set using Dip switches 1 – 4.
Dip 1 Dip 2
OFF OFF
ON OFF
OFF ON
OFF OFF
OFF OFF
Dip 1, 2, 3, 4 30 / 60 / 120 / 240 / 480 seconds
Dip 5, 6 1 / 3 / 6 seconds
Dip 7 On = Disable Off = Operational
Dip 8 On = Test Off = Operational
Dip 3
OFF
OFF
OFF
ON
OFF
Dip 4 Time
OFF 30 seconds
OFF 60 seconds
OFF 120 seconds
OFF 240 seconds
ON 480 seconds
