- Page 1 RAPID ELM - INSTALLATION AND OPERATORS MANUAL (v2011-1) CAN’T SEE IT? CAN’T STEAL IT!
- Page 2 IMPORTANT Please read this manual before commencing installation © Concept Smoke Screen Limited, 1-2 North End, Swineshead, Lincolnshire PE20 3LR Tel: +44 (01205) 821111 • Email: info@smoke-screen.co.uk • www.smoke-screen.co.uk...
- Page 3 Homes and smaller businesses can now easily benefit from the • Wall and ceiling mounting ultimate form of property protection. RAPID ELM DATA: • 34(H) x 14(D) x 33(W) cm • Weight 12 kg Can’t see it? Can’t steal it!
- Page 4 INSTALLATION AND OPERATING INSTRUCTIONS Before commencing installation of the Rapid security smoke system please ensure that you have all of the equipment required. Supplied in the box: • 1 x Rapid ELM XPU-CON security smoke generator. • 1 x Mounting Bracket. •...
-
Page 5: Standard Installation
STANDARD INSTALLATION A ‘standard’ installation is configured in the following way: Rapid Generator wall or ceiling mounted in the appropriate location. Status Monitoring is supplied by the Rapid in three ways: • Onboard LED – Green / Red / Amber (See ALERTS). •... - Page 6 THE RAPID GENERATOR The Rapid generator has two removable covers: the main cover on the front face of the machine and a top panel. The main cover is held in place by six screws (two on each side, one top, and one bottom).Once removed this allows access to the inside of the generator.
-
Page 7: Installation Procedure
INSTALLATION PROCEDURE Site the Rapid Generator – fix the bracket to the wall or ceiling (as required) as appropriate. (Wall mounting: leave minimum 150mm clearance to ceiling to allow access to the fluid compartment). Fasten the Rapid to the bracket and remove front cover. Make Connections to the Alarm Panel and Hold-off PIR. -
Page 8: Mains Power Failure
When the required run time setting is reached change Dip Switch 2 to ‘OFF’. If a mistake is made in programming the run time change Dip Switch 2 to ‘OFF’ and start again. 15 seconds of run time is equivalent to approximately 75 cubic metres of smoke. PROGRAMMING THE UPS MONITORING The Rapid can be set to monitor the UPS (if fitted) and enable the UPS relay output. - Page 9 FLUID TIMER The Fluid Level is monitored using an on-board timer. This measures the amount of fluid used by timing it. Each time the Bag Clamp is unfastened and the Fluid Bag removed the Micro switch is released resetting the timer. NOTE: Refilling must be done with the unit ‘Powered Up’.
- Page 10 CONDITION AUDIBLE Machine Overheating 1 Short Beep every 5 seconds 2 flashes every 2 seconds Cover is Open 1 Long Beep every 60 Seconds 1 flash every 2 seconds UPS Power Failure or UPS not connected 3 Short Beeps every 30 Seconds 2 flashes every 5 seconds AC Mains Power Fail (UPS fitted) 2 Short Beeps every 30 Seconds...
-
Page 11: Example Wiring Diagram
EXAMPLE WIRING DIAGRAM... - Page 12 Always ensure that the SMOKE SCREEN has sufficient fluid. If the SMOKE SCREEN has insufficient fluid no smoke will be produced. Concept Smoke Screen Limited 1-2 North End, Swineshead, Lincolnshire PE20 3LR Telephone: 01205 821002 Facsimile: 01205 820316 E-mail: info@smoke-screen.co.uk...
