Token Ring Multi-Media Repeater
Technical Specifications
Standards
IEEE 802.5
Physical Dimensions
1.7"
10.2"
9.3"
(42 mm
x
x
Input Power
Universal Power Supply
Input Range:
85 to 265 VAC at 47 to 63 Hz.
(Rated at 40 watts maximum.)
MTBF:
135,000 hours
Environment
Temperature:
0-50°C (32° to 122° F )
Humidity
10-90%, non condensing
Altitude
0-10,000 feet
Warranty
5 years
25
259 mm
235 mm)
x
x
Token Ring 2-Port
Multi-Media Repeater
(TR-MMR-2)
For assistance in installing, using, or
maintaining the TRANSITION Networks
Token Ring Multi-Media Repeater,
contact TRANSITION Networks
Technical Support at:
(800) 260-1312
or contact your local distributor.
7363.C
Advertisement
Table of Contents
Related Manuals for Transition Networks TR-MMR-2
Summary of Contents for Transition Networks TR-MMR-2
-
Page 1: Technical Specifications
10-90%, non condensing Altitude 0-10,000 feet Warranty 5 years 235 mm) Token Ring 2-Port Multi-Media Repeater (TR-MMR-2) 7363.C For assistance in installing, using, or maintaining the TRANSITION Networks Token Ring Multi-Media Repeater, contact TRANSITION Networks Technical Support at: (800) 260-1312... - Page 2 CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in damage to the public telephone network. Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen...
-
Page 3: Table Of Contents
Token Ring Cable Specifications Maximum Cable Distance (Determined by Cable and Token Ring Speed) SPEED: 16Mbps Cable Max-Lobe Length* Max-RI\RO Length* UTP Category 3 150 meters (500 feet) 150 meters (500 feet) UTP Category 5 350 meters (1140 feet) 350 meters (1140 feet) STP Category 5 400 meters (1310 feet) 400 meters (1310 feet) -
Page 4: Introduction
The Token Ring Multi-Media Repeater The TRANSITION Networks Token Ring 2-Port Multi-Media Repeater (TR-MMR-2), is a small, multi-purpose active retiming Token Ring repeater that is site-configurable, using Slide In Card (SIC) connections, for ring extension and/or for port extension over selectable media. -
Page 5: Networking The Token Ring Multi-Media Repeater
IBM Type 1, multimode fiber, and standard 100 ohm shielded twisted pair (STP) or unshielded twisted pair (UTP). As shown, the Token Ring Multi-Media Repeaters with installed cable can be used both for ring extension (#1) and for lobe extension (#2). Ring Extension... -
Page 6: Connectors, Switches And Status Indicators
Connectors, Switches and Status Indicators Reset Switch Network Speed Switch RO/LO SIC Slot RI/LI SIC Slot Power Connector Ring In/Lobe In LED Power LED Connectors (AT BACK) Slide-In cards (SICs), when installed, provide IBM Data Connectors, fiber connectors, and/or RJ-45 connectors. An external power connector also is located at the Token Ring Multi-Media Repeater back. -
Page 7: Operation
4. OPERATION The Multi-Media Repeater requires no intervention beyond occasionally monitoring the Power and Status LEDs. Monitoring Power LED When the green Power LED is illuminated, the Token Ring Multi- Media Repeater is connected to power. Monitoring Status LEDs When the Ring In/Lobe In LED is illuminated, the Token Ring Multi- Media Repeater is connected to an active ring or lobe input. -
Page 8: Site Considerations
2. SITE CONSIDERATIONS The site for the Token Ring Multi-Media Repeater must provide: • AC power outlet for each Token Ring Multi-Media Repeater • Adequate ventilation • Standard environmental conditions • Isolation from electrical noise, including radio transmitters and broadband amplifiers, motors, high power electrical lines, or fluorescent light fixtures. -
Page 9: Setting Configuration Switches
Token Ring Twisted Pair Network Considerations Twisted pair cables between passive MAUs and Token Ring Multi- Media Repeaters must be short (patch cables). The patch cables can be either Type 1 (150 ) twisted pair or Category 5 (100 ) twisted pair. -
Page 10: Token Ring Rj-45 Twisted Pair Configuration
Token Ring RJ-45 Twisted Pair Configuration If twisted pair cable is used, the twisted pair cable and RJ-45 jacks must be configured as straight through. The two active pairs in a Token Ring network are pins 4 & 5 and pins 3 &... -
Page 11: Installation
Connect cable to SIC connectors Set configuration switches Power the Multi-Media Repeater. Item Part Number Token Ring Multi-Media Repeater TR-MMR-2 Power Cord 3344, 3347, 3348, 3349, or 3523, (depending upon power configuration in country where installed) User’s Guide 7363 Item... -
Page 12: Installing Multi-Media Repeater On Flat Surface
Installing Multi-Media Repeater on Flat Surface To install the Multi-Media Repeater on a table, shelf, or other flat surface: 1. Carefully turn Token Ring Multi-Media Repeater to side. 2. Install four (4) rubber feet: • Remove protective paper from adhesive surface of rubber foot. -
Page 13: Fiber Connection
Ring Out/Lobe Out TR-FI-SIC The fiber slide-in cards TR-FI-SIC and TR-FO-SIC can be installed in two separate Token Ring Multi-Media Repeaters and used in pairs to extend the Token Ring network by 2000 meters (6600 feet). FIBER CONNECTOR RING EXTENSION... -
Page 14: Connecting Cable To Sic Connectors
Connecting Cable to SIC Connectors Data Connector Connection The slide-in card TR-DC-SIC can be used for connecting the Token Ring Multi- TR-DC-SIC Media Repeater to a shielded 150 ohm Active Token Ring network, using Data Connectors. Passive The TR-DC-SIC data connector installation can be used for active or passive ring extension and/or for lobe extension DATA CONNECTOR ACTIVE RING EXTENSION If the data connector slide-in card is installed in a Token Ring Multi-...
