Transition Networks 5250-CV-T-F/11 User Manual

Twinax to fiber 5250 repeater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
5250 Repeater Technical Specifications
Host Connection
IBM ® S/3x (System 34, 36, 38), AS/400™ Host or remote controllers
Physical Dimensions
6.5"
4.1"
1.6"
(165 mm
x
x
Input Power
Power Supply Adapter
AC Input:
TN PN Requirement
3500
120 volts, 60 hertz, 28 watts
3501
230 volts, 50 hertz, 28 watts
3508
100 volts, 50-60 hertz, 28 watts
3506
240 volts, 50 hertz, 28 watts
3510
240 volts, 50 hertz, 28 watts
DC Output:
12 volts at 1.5 A maximum
MTBF:
45655 hours
including power supply
525468 hours
NOT including power supply
Environment
Temperature:
0-50°C (32° to 122° F )
Humidity
10-90%, non condensing
Altitude
0-10,000 feet
Warranty
5 years
21
105 mm
41 mm)
x
x
Location
USA/Canada/Mexico
Europe
Japan
United Kingdom
Australia
Twinax to Fiber
5250 Repeater
(5250-CV-T-F/11)
For assistance in installing, using, or
maintaining the TRANSITION Networks
5250 Repeater, contact TRANSITION
Networks Technical Support at:
(800) 260-1312
or contact your local distributor.
7336.E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5250-CV-T-F/11 and is the answer not in the manual?

Questions and answers

Related Manuals for Transition Networks 5250-CV-T-F/11

Summary of Contents for Transition Networks 5250-CV-T-F/11

  • Page 1 41 mm) Location USA/Canada/Mexico Europe Japan United Kingdom Australia Twinax to Fiber 5250 Repeater (5250-CV-T-F/11) 7336.E For assistance in installing, using, or maintaining the TRANSITION Networks 5250 Repeater, contact TRANSITION Networks Technical Support at: (800) 260-1312 or contact your local distributor.
  • Page 2 CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in damage to the public telephone network. Der Anschluss dieses Gerätes an ein öffentlickes Telekommunika- tionsnetz in den EG-Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen einschliesslich der...

  • Page 3: Table Of Contents

    AS/400 & S/3x Cable Specifications Twisted Pair Cable and Connector Specifications The physical characteristics of the twisted pair cable must meet or exceed the following: Cable Characteristics: Category 3 wire or better is required; category 5 wire is recommended. Either shielded twisted pair (STP) or unshielded twisted pair (UTP) can be used.

  • Page 4: Introduction

    5250 Repeater. A working knowledge of local area network (LAN) operations, including familiarity with communications protocols used on interconnected LANs, is assumed. The 5250 Repeater The Twinax to Fiber 5250 Repeater (5250-CV-T-F/11) extends the signal distance between an AS/400™, S/3x, or 5x94 host and terminal equipment. •...

  • Page 5: Networking The 5250 Repeater

    Warranty Statement A. Five Year Warranty Transition Networks, Inc. (TN) warrants, for a period of five years, that TN products (with the exception of power supplies and fans that TN warrants for two years) will be free from defects in materials and workmanship, and will be in conformity with TN’s specifications. TN’s warranty on products manufactured by or assembled for TN in accordance with a customer’s specifications, is a five-year warranty that the goods conform to such specifications.

  • Page 6: Connectors, Switches And Status Indicators

    Connectors, Switches and Status Indicators 5250-CV-T-F/11 T R A N S I T I O N n e t w o r k s Mpls, MN 55344 Power OUT Power IN Connectors The Power OUT connector provides power to up to four connected 5250 Repeaters.

  • Page 7: Operation

    4. OPERATION The 5250 Repeater requires no intervention beyond occasionally monitoring the LEDs. Color Indication Power Illuminated when the 5250 Repeater is Green connected to external power. Sync: Flashes rapidly during reception of valid Fiber/UTP Green 5250 packet from fiber or UTP connection Sync: Flashes rapidly during reception of valid Twinax...

  • Page 8: Site Considerations

    5250 Repeater Power OUT receptacle. cascaded. supply adapter to the first 5250 Repeater Power IN receptacle. adapter to external AC power. 5250-CV-T-F/11 5250-CV-T-F/11 T R A N S I T I O N n e t w o r k s...

  • Page 9: Installation

    • • Direction is provided in the pages that follow. Unpacking the 5250 Repeater The 5250 Repeater packing contents should include the following: 5250-CV-T-F/11 Additionally, for unshielded twisted pair installations, the installation requires: Twinax to Fiber 5250 Repeater Unpack the 5250 Repeaters and equipment.

  • Page 10: Twinax Connection

    Connecting Host Signal to Host 5250 Repeater Connect the AS/400™, S/3X, or 5x94 host to the Host 5250 Repeater using either twinax cable or UTP cable and baluns. ALL cable connectioms to the 5250 Repeater MUST be AT LEAST 7.6 meters (25 feet) in length.

  • Page 11: Connecting Terminal 5250 Repeater To Terminal Equipment

    Connecting Terminal 5250 Repeater to Terminal Equipment Connect the Terminal 5250 Repeater to the the terminal equipment using either twinax cable or UTP cable with baluns. Twinax Connection To connect twinax cable between Terminal 5250 Repeater and terminal equipment: 1. Locate or build twinax cable that conform to cable specifications and...

  • Page 12: Fiber Connection

    Connecting Host 5250 Repeater to Terminal 5250 Repeater Connect the Host 5250 Repeater to the Terminal 5250 Repeater using fiber cable with optional UTP backup. ALL cable connectioms to the 5250 Repeater MUST be AT LEAST 7.6 meters (25 feet) in length. Fiber Connection NOTE: Fiber cables consist of two separately identified cables which may be color-coded.
