AGPtek MP021-F10 Instructions

MP021-F10
Instructions
Dear customers:
Thanks for purchasing the product. Before using this
player, please read the "instructions" carefully, We are not
responsible for any damage for the hardware,program, file
and system of the player caused by improper use.
Please keep the manual as reference.
Front and Rear panel
1. USB interface: Supports external HDD or U disk
2. SD card interface: Supports SD card.
3. IR receiver.
4. HDMI: Through this interface it can get high-definition 720
or 1080P video output.
5. AV: Composite video and audio signal output.
6. YUV: YUV signal output.
7. DC: Input 5.2V/1.5A power.
Remote Control
page3of16
Notes
Please pay attention to the following notes before using it.
1.To prevent the fire or electric shock accident; do not expose
this player in the rain or humid environment.
2.In order to reduce fire, electric shock or damage the product, do
do not let the machine be affected with damp or splash water
drops.
3.Safety guide:
. Please use with the enclosed adapters, May not be able to
●
share with other adapter.
. Please do not let the cable or the plug for the adapter near
●
the heat source equipment.
. Please do not put heavy object on top of the adapter.
●
Please do not overhaul the adapter and the power cord.
.
●
Do not open the machine in order to safety, please contact
.
●
the professional staff for repairing.
4 Maintenance Tips
. Non-professionals shall not open the machine in case to
●
damage the complex machine.
. Users shall not open the machine and remove any parts
●
otherwise the warranty expired.
. If you need maintenance, please contact your local
●
department to arrange for repairing.
●.
If you need to replace components or accessories, it must
be replaced with the original parts by manufacturer.
page2of16
1. <POWER>: on/off key. When power off, the
system goes to standby model. It has to be
unplugged to cut the power.
2.<MUTE>: Press this key sound off, press
again sound on.
3.<Movie>, <Music>, <Photo>: Shortcut of
movie,music,and photo.
OK
4.<Setup>: Shortcut of setting options.
5.<GO-TO>: set up and view the playing time
for playing the Video file.
6.<Repeat>: Select the playback mode.
AV HDMI
VGA
VGA
7.<Ratio>: Set the full screen mode and
ROTATE
ROTATE
original ratio, this function is only applicable
to pictures.
8.<Zoom>: Zoom in the picture or video.
9.<SUB-T>: Select the right subtitle when the movie has multi
-subtitle.
10.<Audio>: Select the sound track( for multitrack movie filse)
11.<Ok>: Play or confirm key.
12.<OSD>: Press this key, the screen will display control
menu when playing movise, music or picture.
13.<Return>: Press this key to return back to previous menu.
14. <REV> <FWD>: backward or forward.
15.<PREV><NEXT>Previous or next.
16.<AV>: Select AV output.
17.<HDMI>: Select high-definition output
18.<VGA>: Select VGA output.
19. <Rotate>: Rotate the pictures.
20.<VOL-> and <VOL+>: Adjust the volume.
page4of16
