- Page 1 DVDO-Splitter-12-SE 1x2 HDMI 2.0 18Gbps Splitter with Scaler / Audio Extraction User Manual Version 1.0.0...
- Page 2 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
-
Page 3: Table Of Contents
Table of Contents 1. Introduction ..............3 2. Features ................3 3. Package Contents ............4 4. Specifications ..............4 5.Operation Controls and Functions ........6 5.1 Front Panel ............. 6 5.2 Rear Panel .............. 8 6. Application Example ............9... -
Page 4: Introduction
1. Introduction The 1x2 HDMI 2.0 Splitter simultaneously routes one HDMI source to two HDMI displays. It supports resolutions up to 4K2K@60Hz (4:4:4) and HDCP 2.2. This product supports audio extraction from HDMI source to optical and analog outputs. It can operate in COPY, AUTO modes for EDID setting. - Page 8 device with a HDMI cable. INPUT LED HDMI These blue LEDs will illuminate when the HDMI OUT port has connected an active OUTPUT display device with a HDMI cable. SERVICE Firmware update. (Manufacturer use only.) port EDID AUTO: Compare OUT 1 and OUT 2 displays EDID setting, then output the best resolution to source device, the source will transmit the signal again to all outputs.
-
Page 10: Application Example
