Gracie Dining Bench
Banc Gracie
Assembly Instructions / Instructions d'assemblage
PARTS INCLUDED/ PIÈCES INCLUSES
(A) Bench Top (x1)
(A) Dessus du banc (x 1)
HARDWARE INCLUDED/ MATÉRIEL INCLUS
1 - Allen Bolt M8*60 mm (x8)
1 - Boulon Allen M8*60 mm (x 8)
4 – Allen Key (x1 piece)
4 - Clé Allen (x 1)
ASSEMBLY INSTRUCTIONS/ INSTRUCTIONS D'ASSEMBLAGE
1. Carefully unpack the parts from the carton.
1. Déballer soigneusement le contenu de la boîte.
2. Gently place the Bench Top (A) upside down on a flat protected surface (shown in Figure 1).
2. Déposer délicatement le dessus du banc (A) à l'envers sur une surface plane couverte de matériel de
protection (tissu, carton).
(B) Round Leg (x4)
(B) Patte (x 4)
2 – Lock Washer (x8)
2 - Rondelle d'arrêt (x 8)
A
Protective material/ Matériel de protection
Figure 1/ Image 1
Page 1 of 2/ Page 1 de 2
3 – Flat Washer (x8)
3 - Rondelle plate (x 8)
