- Page 1 MIL-L100i Single-Port Power over Ethernet Injector USER GUIDE...
- Page 2 In no event shall MiLAN Technology be liable for incidental or consequential damages, costs, or expenses arising out of or in connection with the performance of the product delivered hereunder.
-
Page 3: Table Of Contents
Table of Contents 1. Introduction... 1 ... 2 EATURES ... 2 ACKAGE ONTENTS 2. Hardware Description... 3 3. Installation... 4 4. Technical Specification... 5... -
Page 4: Introduction
Introduction Thank you for purchasing MiLAN’s MIL-L100i Single Port Power over Ethernet (PoE) Injector. The MIL-L100i provides data and AC power through the Ethernet cable to PoE enabled devices, such as AP, PoE splitter or other equipment supporting IEEE 802.3af. The injector is typically installed near the Ethernet hub. -
Page 5: Features
Plug-and-Play Package Contents Unpack the contents of the package and verify them against the checklist below. One MIL-L100i Power over Ethernet Injector Power Cord User Manual Warranty Card If any item is missing or damaged, please contact your local dealer for... -
Page 6: Hardware Description
Hardware Description The Power over Ethernet Injector has three connection ports and one LED indicator. Data In port: RJ-45 Ethernet interface port for data transmitting from the switch to the PoE Injector. Figure 2-1. Data In and PowerIn ports Power In port: The Power In port is for supplying the power to the Injector. -
Page 7: Installation
Installation To install the Power over Ethernet Injector, please follow these steps. 1. Use RJ-45 cable from the Data in port on the Power over Ethernet Injector to the Switch/HUB. 2. Use RJ-45 cable from the Data out port on the Power over Ethernet Injector to the PoE Splitter, PD (Such as Router, Access Point…etc.) or PoE Hub. -
Page 8: Technical Specification
Technical Specification The following table provides the technical specification of the Power over Ethernet Injector. Standard Connector Network Cable Power Input Output Power Operating environment Operating Humidity Storage Temperature Dimension EMI & Safety IEEE802.3/3u 10BASE-T/100BASE-TX IEEE802.3af Power over Ethernet DC out: Power pin: 4,5(V+), 7,8(V-) 10BASE-T: 2-pair UTP/STP Cat.3, 4,5 cable EIA/TIA-568 100-ohm (100m) 100BASE-TX: 2-pair UTP/STP Cat.5 cable... - Page 9 90000430 Rev B...
