MiLAN MIL-100FXC Installation Manual

Re g u l a to r y A pp ro v als
• FCC Class A
• UL 1950
• CSA C22.2 No. 950
• EN60950
• CE
EN55022
– Class B
– EN50082-1
Ca na d ia n E M I N ot i ce
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du
Canada.
E u ro p ea n N ot i c e
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low V oltage
Directive (73/23/EEC) issued by the commission of the European Community . Compliance with these directives
implies conformity to the following European Norms:
• EN55022 (CISPR 22) - Radio Frequency Interference
• EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity
• EN60950 (IEC950) - Product Safety
Five-Year Limited Warranty
MiLAN Technology warrants to the original consumer or purchaser that each of its products, and
all components thereof, will be free from defects in material and/or workmanship for a period of
five years from the original factory shipment date. Any warranty hereunder is extended to the
original consumer or purchaser and is not assignable.
MiLAN Technology makes no express or implied warranties including, but not limited to, any
implied warranty of merchantability or fitness for a particular purpose, except as expressly set
forth in this warranty. In no event shall MiLAN Technology be liable for incidental or
consequential damages, costs, or expenses arising out of or in connection with the performance
of the product delivered hereunder. MiLAN Technology will in no case cover damages arising
out of the product being used in a negligent fashion or manner.
Tra d em a rks
© 2000 MiLAN, the MiLAN logo, and MiLAN Technology are either trademarks or registered trademarks of
Digi International, Inc. in the United States and/or other countries. All other trademarks are the property of
their respective holders.
To Cont a c t M i L A N Te ch no l og y
For prompt response when calling for service information, have the following information ready:
• Product serial number and rev.
• Date of purchase
• Vendor or place of purchase
You can reach MiLAN Technology technical support at:
E-mail: support@milan.com
Telephone: +1.408.744.2751
Fax: +1.408.744.2771
MiLAN Technology
1299 Orleans Drive
Sunnyvale, CA 94089-1138
United States of America
Telephone: +1.408.744.2775
Fax: +1.408.744.2793
http://www.milan.com
info@milan.com
® Copyright 2001 MiLAN Technology Printed in USA P/N: 90000130 Rev. C
Installation Guide: MIL-100FXT/MIL-100FXC
MIL-100FXT and MIL-100FXC
Fast Ethernet Transceivers

Installation Guide

MIL-100FXT and MIL-100FXC
This guide includes the following information:
• "Introduction" on page 2
• "Installation" on page 3
• "Configuration" on page 3
• "Slide Switches" on page 4
• "Indicators" on page 5
